Sony RDP-XA700iP User Manual

13
US
1 Prepare for the following
devices.
• This unit
•Mac or PC
• Wireless LAN router/access point
• Network (LAN) cable (not supplied) if
needed
2 Have your wireless network
name (SSID) and Security Key
(if applicable) available for
reference.
Refer to the operating instructions of the
wireless LAN router/access point.
3 Connect the unit and the Mac or
PC using a network (LAN) cable
(not supplied). Then turn this
unit on.
Wait for about 4 minutes until the LINK
indicator lights up amber.
Tip
You can also perform this procedure
wirelessly. See “To connect wirelessly”
(page 14).
4 Access the [Sony Network
Device Setting] screen.
For Mac
Start Safari and select [Bonjour] under
[Bookmarks], then select [RDP-
XA700iP].
For PC
Start the browser and input either of the
following URLs into the browser’s
address bar.
• When using a network (LAN) cable
• When connecting wirelessly
5 Select the desired language
when the [Language Setup]
screen appears.
6 Select [Network Settings] from
the menu.
Option 3: Wi-Fi Connection
using Access Point Scan
SSID (Wireless Network Name)
Security Key (WEP or WPA key)
Network Settings

Sony RDP-XA700iP Specifications

General

Product color	Black
Volume control	Digital
Indication light	Yes
Dimensions (WxDxH)	401 x 176 x 160 mm
Impedance	8 Ω
Driver diameter	48 mm
Frequency range	- Hz
RMS rated power	60 W
Audio output channels	2.1 channels
Bluetooth	No
Headphone connectivity	-
Apple docking compatibility	iPad, iPhone, iPod
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 Hz

Weight and Dimensions

Depth	160 mm
Width	401 mm
Height	176 mm
Weight	3300 g
