2-2
RDR-GX220/GX330
2-1.
UPPER CASE
2-2.
TR
A
Y C
O
VER ASSEMBL
Y
Note:
Follow the disassembly procedure in the numerical order given.
1
T
wo tapping scre
ws
3
Upper case
2
Three tapping screws
(+BV3 (3-CR)) (3 x 8)
1
The stiff wire
Hole
4
T
ra
y cover assemb
ly
3
T
wo
claws
2
Open the tra
y
29
31
