Step 4: Connecting to Your AV Amplifier (Receiver)
Select one of the following patterns A or B, according to the input jack on your AV amplifier (receiver).
This will enable you to listen to sound through your AV amplifier (receiver).
L
R
VIDEO
AUDIO
LINE OUT
VIDEO
Y
L
P
B
R
P
R
AUDIO
S VIDEO
LINE 1 IN AUDIO OUT
COMPONENT
VIDEO OUT
DIGITAL
AUDIO OUT
COAXIAL
HDMI OUT
SET TOP
BOX
CONTROL
AUDIO
INPUT
L
R
B
A
L
R
AUDIO OUT
DIGITAL
AUDIO OUT
COAXIAL
: Signal flow
AV amplifier (receiver)
(red)
(white)
Audio cord
(not supplied) (white)
(red)
VCR-DVD recorder to AUDIO OUT (L/R)
to DIGITAL AUDIO OUT
(COAXIAL)
Coaxial digital cord
(not supplied)
[Speakers]
Rear (L)
Front (L)
Center
to coaxial digital
input
[Speakers]
Rear (R)
Front (R)
Subwoofer
AV amplifier (receiver)
with a decoder
