2-1. CASE (LOWER)
2-2. REMOTE CONTROL BOARD
Note: Follow the disassembly procedure in the numerical order given.
SECTION 2
DISASSEMBLY
• This set can be disassemble in the order shown below.
Set
Case (Lower) Remote Control Board Case, Inne
r
2 two hexagon socket bolts
(2.6
× 5)
4 three claws
3 two screws
(P2
× 6)
4 two claws
4 three claws
5 case (lower)
1 Remote the
battery case lid
in the direction
of arrow
A .
A
1 filter
2 Rotate two brackets
to remove.
4 Remove the remote control boar
d
in the direction of arrow A .
3 wire
A
