Sony RM-VZ950T Service Manual

– 37 –
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JOG
REMOTE CONTROL
A-4541-208-A JOG BOARD, COMPLETE
********************
< CONNECTOR >
CN2 9-885-008-53 CONNECTOR 5P
< JOG ENCODER >
SW1 1-473-406-11 ENCODER, ED JOG (FUNCTION)
**************************************************************
* 1-679-852-11 REMOTE CONTROL BOARD
**********************
3-220-684-01 TERMINAL (A), BATTERY
3-220-685-01 TERMINAL (B), BATTERY
3-220-689-01 TERMIAL, ZEBRA
< CAPACITOR >
C1 1-126-607-21 ELECT CHIP 47uF 20% 4V
C2 1-126-204-21 ELECT CHIP 47uF 20% 16V
C3 1-128-008-21 ELECT CHIP 3.3uF 20% 35V
C4 1-128-008-21 ELECT CHIP 3.3uF 20% 35V
C5 1-128-008-21 ELECT CHIP 3.3uF 20% 35V
C6 1-128-008-21 ELECT CHIP 3.3uF 20% 35V
C7 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C8 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C9 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C10 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C11 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C12 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C13 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C14 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C15 1-164-361-11 CERAMIC CHIP 0.047uF 16V
C16 1-164-361-11 CERAMIC CHIP 0.047uF 16V
< CONNECTOR >
CN1 9-885-008-53 CONNECTOR 5P
< DIODE >
D1 9-885-008-55 DIODE TPS705 (HATA)
(REMOTE CONTROL SIGNAL RECEIVER)
D2 8-719-076-88 DIODE MA2Z720001S0
D3 1-807-851-11 LED SLR-931A
(REMOTE CONTROL SIGNAL TRANSMITTER)
D4 8-719-053-06 LED SLR-932A-7
(REMOTE CONTROL SIGNAL TRANSMITTER)
D5 8-719-058-69 LED LNJ308G8JRA (LCD BACK LIGHT)
D6 8-719-058-69 LED LNJ308G8JRA (LCD BACK LIGHT)
D7 8-719-058-69 LED LNJ308G8JRA (LCD BACK LIGHT)
D8 8-719-058-69 LED LNJ308G8JRA (LCD BACK LIGHT)
< IC >
IC1 8-759-699-74 IC uPD780058GK-A04-9EU
IC2 9-885-008-48 IC NJU6424FG1-T
IC3 9-885-008-49 IC HN58X24256FPI-T
IC4 8-759-530-29 IC TC4069UBFT (EL, N)
IC5 9-885-008-50 IC XC6372C361PR-T
IC6 8-759-479-03 IC S-80825ANNP-EDN-T2
IC7 8-759-665-49 IC S-80818ANNP-EDF-T2
IC8 9-885-008-51 IC XC62KN5002MR-T
< COIL >
L1 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q1 8-729-047-62 TRANSISTOR 2SC3440-T12-1F
Q2 9-885-008-52 TRANSISTOR 2SA1603A-T
< RESISTOR >
R1 1-218-867-11 METAL CHIP 6.8K 5% 1/16W
R2 1-216-833-11 METAL CHIP 10K 5% 1/16W
R3 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R5 1-218-726-11 METAL CHIP 27K 5% 1/16W
R6 1-216-840-11 METAL CHIP 39K 5% 1/16W
R7 1-216-818-11 METAL CHIP 560 5% 1/16W
R8 1-216-846-11 METAL CHIP 120K 5% 1/16W
R9 1-216-833-11 METAL CHIP 10K 5% 1/16W
R10 1-216-833-11 METAL CHIP 10K 5% 1/16W
R11 1-216-857-11 METAL CHIP 1M 5% 1/16W
R12 1-216-857-11 METAL CHIP 1M 5% 1/16W
R13 1-216-845-11 METAL CHIP 100K 5% 1/16W
R14 1-216-845-11 METAL CHIP 100K 5% 1/16W
R15 1-216-857-11 METAL CHIP 1M 5% 1/16W
R16 1-216-839-11 METAL CHIP 33K 5% 1/16W
R17 1-216-845-11 METAL CHIP 100K 5% 1/16W
R18 1-216-845-11 METAL CHIP 100K 5% 1/16W
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
