6-15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< IC >
IC801 8-759-384-78 IC SN104241PM-TEB
IC802 8-759-521-35 IC TL5001CDR
IC3902 8-759-447-75 IC S-81322HG-KW-T1
< COIL >
L801 1-416-668-11 COIL CHOKE 10uH
L802 1-416-668-11 COIL CHOKE 10uH
L803 1-416-668-11 COIL CHOKE 10uH
L804 1-412-056-11 INDUCTOR CHIP 4.7uH
L805 1-416-669-11 COIL CHOKE 22uH
L806 1-416-669-11 COIL CHOKE 22uH
L807 1-416-669-11 COIL CHOKE 22uH
L808 1-416-670-11 COIL CHOKE 33uH
L809 1-416-669-11 COIL CHOKE 22uH
L810 1-414-396-21 INDUCTOR 4.7uH
L811 1-414-396-21 INDUCTOR 4.7uH
L812 1-414-404-11 INDUCTOR 100uH
L813 1-414-430-11 INDUCTOR 4.7uH
L814 1-414-396-21 INDUCTOR 4.7uH
L815 1-414-396-21 INDUCTOR 4.7uH
L816 1-216-296-91 SHORT 0
L817 1-414-396-21 INDUCTOR 4.7uH
L818 1-414-400-11 INDUCTOR 22uH
L819 1-414-396-21 INDUCTOR 4.7uH
L820 1-416-669-11 COIL CHOKE 22uH
L3920 1-414-396-21 INDUCTOR 4.7uH
< IC LINK >
! PS801 1-533-760-21 FUSE (SMD) 1.4A
! PS802 1-533-760-21 FUSE (SMD) 1.4A
! PS803 1-533-760-21 FUSE (SMD) 1.4A
! PS804 1-533-760-21 FUSE (SMD) 1.4A
! PS805 1-533-760-21 FUSE (SMD) 1.4A
< TRANSISTOR >
Q806 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q807 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q808 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q809 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q810 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q811 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q812 8-729-041-24 TRANSISTOR NDS355AN
Q813 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q814 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q815 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q816 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q817 8-729-041-24 TRANSISTOR NDS355AN
Q818 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q819 8-729-043-94 TRANSISTOR CPH3106-PM-TL
Q820 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q821 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q822 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
Q823 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q824 8-729-042-56 TRANSISTOR MGSF3455VT1
Q826 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q827 8-729-037-61 TRANSISTOR UN9113J-(K8).SO
Q828 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q829 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q830 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q831 8-729-041-23 TRANSISTOR NDS356AP
Q832 8-729-041-23 TRANSISTOR NDS356AP
Q833 8-729-041-23 TRANSISTOR NDS356AP
Q834 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q835 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q836 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q837 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q838 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q839 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q840 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q841 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q842 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q843 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q844 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q845 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q846 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q847 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q848 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q849 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q850 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q852 8-729-017-61 TRANSISTOR 2SB1581-T1
Q853 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q854 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q855 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q856 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q3922 8-729-106-60 TRANSISTOR 2SB1132-T100-R
< RESISTOR >
R801 1-218-973-11 RES,CHIP 47K 5% 1/16W
R802 1-208-713-11 RES,CHIP 18K 0.50% 1/16W
R803 1-218-959-11 RES,CHIP 3.3K 5% 1/16W
R804 1-218-969-11 RES,CHIP 22K 5% 1/16W
R805 1-218-967-11 RES,CHIP 15K 5% 1/16W
R806 1-208-711-11 RES,CHIP 15K 0.50% 1/16W
R807 1-218-971-11 RES,CHIP 33K 5% 1/16W
R808 1-208-711-11 RES,CHIP 15K 0.50% 1/16W
R809 1-218-849-11 RES,CHIP 3.3K 0.50% 1/16W
R810 1-218-969-11 RES,CHIP 22K 5% 1/16W
R811 1-208-935-11 RES,CHIP 100K 0.50% 1/16W
R812 1-218-970-11 RES,CHIP 27K 0.50% 1/16W
R813 1-218-973-11 RES,CHIP 47K 5% 1/16W
R814 1-218-981-11 RES,CHIP 220K 5% 1/16W
R818 1-208-699-11 RES,CHIP 4.7K 0.50% 1/16W
R819 1-208-927-11 RES,CHIP 47K 0.50% 1/16W
R820 1-218-945-11 RES,CHIP 220 5% 1/16W
R821 1-208-715-11 RES,CHIP 22K 0.50% 1/16W
R822 1-218-981-11 RES,CHIP 220K 5% 1/16W
R823 1-218-965-11 RES,CHIP 10K 5% 1/16W
R824 1-218-969-11 RES,CHIP 22K 5% 1/16W
R829 1-218-965-11 RES,CHIP 10K 5% 1/16W
R830 1-208-719-11 RES,CHIP 33K 0.50% 1/16W
R831 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R833 1-218-971-11 RES,CHIP 33K 5% 1/16W
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
DD-106
