Sony RMT-809 - Page 154

6-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R834 1-208-719-11 RES,CHIP 33K 0.50% 1/16W
R835 1-218-973-11 RES,CHIP 47K 5% 1/16W
R836 1-218-965-11 RES,CHIP 10K 5% 1/16W
R837 1-208-699-11 RES,CHIP 4.7K 0.50% 1/16W
R838 1-218-969-11 RES,CHIP 22K 5% 1/16W
R839 1-218-969-11 RES,CHIP 22K 5% 1/16W
R840 1-218-971-11 RES,CHIP 33K 5% 1/16W
R841 1-218-966-11 RES,CHIP 12K 5% 1/16W
R842 1-208-703-11 RES,CHIP 6.8K 0.50% 1/16W
R843 1-208-689-11 RES,CHIP 1.8K 0.50% 1/16W
R844 1-218-849-11 RES,CHIP 3.3K 0.50% 1/16W
R845 1-218-955-11 RES,CHIP 1.5K 5% 1/16W
R846 1-218-949-11 RES,CHIP 470 5% 1/16W
R847 1-218-965-11 RES,CHIP 10K 5% 1/16W
R848 1-218-961-11 RES,CHIP 4.7K 5% 1/16W
R849 1-218-961-11 RES,CHIP 4.7K 5% 1/16W
R850 1-218-978-11 RES,CHIP 120K 5% 1/16W
R851 1-218-955-11 RES,CHIP 1.5K 5% 1/16W
R852 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R853 1-208-703-11 RES,CHIP 6.8K 0.50% 1/16W
R854 1-218-970-11 RES,CHIP 27K 0.50% 1/16W
R855 1-218-990-11 SHORT 0
R859 1-218-977-11 RES,CHIP 100K 5% 1/16W
R864 1-218-989-11 RES,CHIP 1M 5% 1/16W
R865 1-218-973-11 RES,CHIP 47K 5% 1/16W
R866 1-218-969-11 RES,CHIP 22K 5% 1/16W
R868 1-218-981-11 RES,CHIP 220K 5% 1/16W
R869 1-218-946-11 RES,CHIP 270 5% 1/16W
R870 1-218-989-11 RES,CHIP 1M 5% 1/16W
R871 1-218-989-11 RES,CHIP 1M 5% 1/16W
R872 1-218-977-11 RES,CHIP 100K 5% 1/16W
R873 1-218-973-11 RES,CHIP 47K 5% 1/16W
R874 1-218-989-11 RES,CHIP 1M 5% 1/16W
R875 1-218-981-11 RES,CHIP 220K 5% 1/16W
R876 1-218-977-11 RES,CHIP 100K 5% 1/16W
R878 1-218-989-11 RES,CHIP 1M 5% 1/16W
R879 1-218-969-11 RES,CHIP 22K 5% 1/16W
R880 1-218-978-11 RES,CHIP 120K 0.50% 1/16W
R881 1-218-990-11 SHORT 0
R882 1-208-943-11 RES,CHIP 220K 0.50% 1/16W
R883 1-218-973-11 RES,CHIP 47K 5% 1/16W
R884 1-218-977-11 RES,CHIP 100K 5% 1/16W
R885 1-218-977-11 RES,CHIP 100K 5% 1/16W
R887 1-218-981-11 RES,CHIP 220K 5% 1/16W
R888 1-218-977-11 RES,CHIP 100K 5% 1/16W
R890 1-218-977-11 RES,CHIP 100K 5% 1/16W
R891 1-208-935-11 RES,CHIP 100K 0.50% 1/16W
R892 1-208-943-11 RES,CHIP 220K 0.50% 1/16W
R893 1-208-711-11 RES,CHIP 15K 0.50% 1/16W
R894 1-208-941-11 RES,CHIP 180K 0.50% 1/16W
R895 1-218-969-11 RES,CHIP 22K 5% 1/16W
R896 1-208-943-11 RES,CHIP 220K 0.50% 1/16W
R897 1-208-931-11 RES,CHIP 68K 0.50% 1/16W
R898 1-208-942-11 RES,CHIP 200K 0.50% 1/16W
R899 1-208-719-11 RES,CHIP 33K 0.50% 1/16W
R900 1-208-931-11 RES,CHIP 68K 0.50% 1/16W
R901 1-218-886-11 RES,CHIP 43K 0.50% 1/16W
R902 1-208-699-11 RES,CHIP 4.7K 0.50% 1/16W
R903 1-218-977-11 RES,CHIP 100K 5% 1/16W
R904 1-218-981-11 RES,CHIP 220K 5% 1/16W
R905 1-208-941-11 RES,CHIP 180K 0.50% 1/16W
R906 1-208-699-11 RES,CHIP 4.7K 0.50% 1/16W
R907 1-208-943-11 RES,CHIP 220K 0.50% 1/16W
R908 1-218-973-11 RES,CHIP 47K 5% 1/16W
R910 1-218-965-11 RES,CHIP 10K 5% 1/16W
R911 1-208-711-11 RES,CHIP 15K 0.50% 1/16W
R912 1-208-715-11 RES,CHIP 22K 0.50% 1/16W
R914 1-218-977-11 RES,CHIP 100K 5% 1/16W
R3969 1-216-803-11 METAL CHIP 33 5% 1/16W
R3970 1-216-803-11 METAL CHIP 33 5% 1/16W
R3972 1-218-977-11 RES,CHIP 100K 5% 1/16W
R3973 1-218-971-11 RES,CHIP 33K 5% 1/16W
R3974 1-218-974-11 RES,CHIP 56K 5% 1/16W
< TRANSFORMER >
T801 1-429-565-21 TRANSFORMER, CONVERTER
************************************************************
A-7073-418-A FP-594 BOARD, COMPLETE
**********************
(Ref.No.: 2,000 Series)
< CONNECTOR >
CN901 1-784-723-11 PIN, CONNECTOR 4P
< DIODE >
D901 8-719-067-13 DIODE GL453K
< HOLE ELEMENT >
H901 8-719-061-28 DIODE HW-105C-FT-V (S REEL)
H902 8-719-061-28 DIODE HW-105C-FT-V (T REEL)
< TRANSISTOR >
Q901 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE END)
Q902 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE TOP)
< SWITCH >
S901 1-771-039-51 SWITCH, PUSH (C IN SW)
S902 1-572-719-32 SWITCH, PUSH (1 KEY) (REC PROOF)
S903 1-771-325-11 ENCODER, ROTARY (SWITCH)(MODE)
************************************************************
1-669-506-21 FP-647 FLEXIBLE BOARD
*********************
(Ref.No.: 3,000 Series)
< CONNECTOR >
CN1 1-779-369-11 JACK, DV (DV IN/OUT)
< JACK >
J1 1-778-040-11 JACK, AV (VIDEO/AUDIO)
J2 1-778-518-11 JACK, S (S VIDEO)
< RESISTOR >
R1 1-216-295-11 RES,CHIP 0 5% 1/10W
R2 1-216-295-11 RES,CHIP 0 5% 1/10W
************************************************************
DD-106 FP-594 FP-647
