6-17
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1-669-508-21 FP-649 FLEXIBLE BOARD
*********************
(Ref.No.: 4,000 Series)
< SWITCH >
S1 1-572-288-11 SWITCH, ROTARY (OPEN/CLOSE)
S2 1-572-467-71 SWITCH, PUSH (REVERSE)
************************************************************
1-669-514-21 FP-657 FLEXIBLE BOARD
*********************
(Ref.No.: 5,000 Series)
< SWITCH >
SW1 1-762-851-21 SWITCH, PUSH (FADER)
SW2 1-762-851-21 SWITCH, PUSH (BACKLIGHT)
************************************************************
1-669-515-21 FP-676 FLEXIBLE BOARD
*********************
(Ref.No.: 6,000 Series)
< JACK >
J1 1-565-276-21 JACK, LANC (LANC)
J2 1-695-514-21 JACK, HP (HEADPHONES)
< RESISTOR >
R1 1-216-864-11 RES,CHIP 0 5% 1/16W
R2 1-216-864-11 RES,CHIP 0 5% 1/16W
R3 1-216-864-11 RES,CHIP 0 5% 1/16W
R4 1-216-864-11 RES,CHIP 0 5% 1/16W
R5 1-216-864-11 RES,CHIP 0 5% 1/16W
R6 1-216-864-11 RES,CHIP 0 5% 1/16W
R7 1-216-864-11 RES,CHIP 0 5% 1/16W
R8 1-216-864-11 RES,CHIP 0 5% 1/16W
< SWITCH >
S1 1-692-247-11 SWITCH, PUSH (PHOTO FREEZE/PHOTO REC)
************************************************************
A-7073-517-A KY-39 BOARD, COMPLETE
*********************
(Ref.No.: 40,000 Series)
< CONNECTOR >
CN7801 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN7802 1-573-365-21 CONNECTOR, FFC/FPC 25P
CN7803 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN7804 1-573-346-21 CONNECTOR, FFC/FPC 6P
CN7805 1-778-598-21 CONNECTOR, BOARD TO BOARD 60P
CN7806 1-784-420-11 CONNECTOR, FFC/FPC (ZIF) 21P
< DIODE >
D7802 8-719-420-14 DIODE MA8082-TX
< COIL >
L7801 1-412-056-11 INDUCTOR CHIP 4.7uH
L7802 1-216-295-91 SHORT 0
L7803 1-216-295-91 SHORT 0
L7804 1-216-295-91 SHORT 0
L7805 1-216-295-91 SHORT 0
L7806 1-414-754-11 INDUCTOR 10uH
L7807 1-216-295-91 SHORT 0
L7808 1-216-295-91 SHORT 0
L7809 1-414-754-11 INDUCTOR 10uH
L7810 1-216-295-91 SHORT 0
L7811 1-216-295-91 SHORT 0
L7812 1-216-295-91 SHORT 0
< RESISTOR >
R7822 1-216-838-11 METAL CHIP 27K 5% 1/16W
R7824 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R7825 1-216-838-11 METAL CHIP 27K 5% 1/16W
R7826 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R7827 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R7829 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R7830 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R7832 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R7833 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R7834 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
< SWITCH >
S7822 1-762-851-21 SWITCH, KEY BOARD (MENU)
S7823 1-692-605-11 SWITCH, SLIDE (START/STOP MODE)
S7825 1-762-851-21 SWITCH, KEY BOARD (TITLE)
S7827 1-762-851-21 SWITCH, KEY BOARD (END SEARCH)
S7828 1-762-851-21 SWITCH, KEY BOARD (DATA CODE)
S7829 1-762-851-21 SWITCH, KEY BOARD (PICTURE EFFECT)
S7831 1-762-851-21 SWITCH, KEY BOARD (ON SCREEN DISPLAY)
S7832 1-762-851-21 SWITCH, KEY BOARD (WIDE)
S7833 1-762-851-41 SWITCH, KEY BOARD (RESET)
************************************************************
A-7073-515-A LB-55 BOARD, COMPLETE
*********************
(Ref.No.: 60,000 Series)
< CAPACITOR >
C5201 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5202 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C5203 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C5204 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C5206 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C5207 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
C5208 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
< CONNECTOR >
CN5201 1-784-421-11 CONNECTOR, FFC/FPC (ZIF) 27P
CN5202 1-691-354-21 CONNECTOR, FFC/FPC (ZIF) 16P
< DIODE >
D5201 8-719-056-49 DIODE 1SS370(TE85L)
< COIL >
L5201 1-412-031-11 INDUCTOR CHIP 47uH
L5202 1-412-029-11 INDUCTOR CHIP 10uH
< FLUORESCENT INDICATOR >
ND5201 1-517-758-11 TUBE, FLUORESCENT (0.55 INCH)
FP-649 FP-657 FP-676 KY-39 LB-55
