BDP-BX39/S390
7-16E
Drive Test
Outline
Activate Drive test
(Window 1) Select Drive test category
Operation
[LEFT] [RIGHT] Select Category
[DOWN][ENT] Activate the selected Category.
[RET] Return to Service Top Menu.
[1] Drive OP data Write
[2] Servo Parameter Check Menu (Not Used)
[3] Servo Signal Check Menu (Not Used)
[4] S-Curve Check Menu (Not Used)
[5] Readability Check Menu (Not Used)
[6] OP Position Check Menu (Not Used)
[7] OP Check Menu (Not Used)
[8] Load Eject Aging (Not Used)
[9] Spindle Control Check Menu (Not Used)
[10] FA Test Mode (Not Used)
(Window 2) To start OP data Write
Operation :
[ENT] Start
(Window 3) Show OP data Write result
Operation :
NG - USB is not find
NG – File(Budata.txt) is not find
OK – OP data write
>Drive Test:
For drive operating check. Service is only use Drive OP data write to re write
OP data after change of new OPU.
(window 1)
* Diag
[1] Drive OP data Write
[2] Servo Parameter Check Menu
[3] Servo Signal Check Menu
[4] S-Curve Check Menu
[5] Readability Check Menu
[6] OP Position Check Menu
[7] OP Check Menu
[8] Load Eject Aging
[9] Spindle Control Check Menu
[10] FA Test Mode
Help: [UP][DOWN][ENT][RET][(NUM)]
(Window 2)
* Drive OP data Write
Insert USB StorageDevice . . .
Remove DISC and Close tray.
Disc: Load
Mode: 1
[ENT] Start
HELP: [LEFT][RIGHT][UP][DOWN][ENT][RET]
(Window 3)
* Drive OP data Write
Insert USB StorageDevice . . .
Remove DISC and Close tray.
[ENT] Start
NG – USB is not find
OK – OP data write
HELP: [LEFT][RIGHT][UP][DOWN][ENT][RET]
To Next Page
