2-3
2-4. OPTICAL DEVICE (KHM-310AAA)
3 FMO-11 flexible board (CN103, 24P)
4 FMO-10 flexible board (CN104, 6P)
1 Four insulator screws
2 Four insulator
2 Four insulator
5 Optical device (KHM-310AAA)
Caution Point on the Laser Diode:
Laser Diode in the optical Device is very sensitive to Surge
Current or ElectroStatic Discharge (ESD):
After take-out FMO-24 Flexible cable from CN103 of
MV-044 board immediately ground FMO-24 Flexible cable
pattern using short clip. Metal paper clip can be used as
short clip.
