Sony RMT-D166P - Settings and Adjustments; Settings for the Sound (AUDIO SETUP)

2-4
2-5. DC MOTOR and MS-203 BOARD
2-6. MV-044 BOARD
7
FMS-24 flexible (CN001, 5P)
8
MS-203 board
4
Pulley motor
5
DC motor (M001)
3
Tray
2
0
Belt
1
Two claws
7 FMD-11 flexible board(CN103, 24P)
9 MV-44 board
4 IM-065 harness(CN205, 4P)
3 PM-112 harness(CN771, 10P)
2 MD-102 harness
(CN771, 10P)
5 FMS-23 flexible
cable (CN101, 5P)
8 Five screws
(SUMITITE (B3)+BV)
1 Three screws
(SUMITITE (B3)+BV)
6 Connector
(CN201, 9P)
a
c
d
d
a
c
b
b
