Sony RMT-D166P - MV-044 BOARD (DRIVE, CPU, SERVO-DSP, AVDEC, VIDEO, AUDIO, PS THROUGH) PRINTED WIRING BOARD; MV-044 BOARD (DRIVE, CPU, SERVO-DSP, AVDEC, VIDEO, AUDIO, PS THROUGH) SCHEMATIC DIAGRAM

DVP-NS355/NS501P/NS507P/NS525P/NS575P/NS585P
IF-112 board
(SWITCH)
MV-44 board
(SERVO DRIVE &
SYSTEM CONTROL)
Power board
MS-203 board
(LOADING MOTOR)
G
F
E
D
C
B
A
1
2
5
4
3
MV-044 BOARD
A SIDE
IC101 A-2
IC102 D-2
IC151 B-3
IC201 B-4
IC202 A-3
IC204 A-3
IC205 B-5
IC206 C-5
IC207 D-3
IC209 A-3
IC503 E-1
IC601 D-3
IC602 E-3
IC604 F-5
IC605 G-4
Q168 C-1
Q170 C-1
Q171 C-1
Q201 B-3
Q504 E-1
Q505 F-2
Q507 F-1
Q508 F-2
Q571 F-2
Q572 E-1
Q573 F-1
Q574 E-1
Q601 E-4
Q602 F-3
Q603 E-4
Q604 F-3
Q605 E-3
Q606 E-4
Q609 E-3
Q610 E-3
Q611 F-4
Q613 E-3
Q614 E-1
Q616 E-4
Q617 E-1
Q772 E-4
Q773 E-4
Q777 D-4
Q778 D-4
D165 B-1
D201 C-5
D202 A-3
D510 E-2
D601 F-4
D602 F-3
D603 F-4
D604 F-4
D605 E-3
D771 E-5
F
E
D
C
B
A
1
2
5
4
3
B SIDE
IC208 D-3
IC502 E-4
IC603 D-2
IC774 E-1
Q607 F-3
Q608 F-3
D508 F-4
D509 F-4
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
For printed wiring board
DRIVE, CPU, SERVO-DSP, AVDEC, VIDEO, AUDIO, PS THROUGH
MV-044
MV-044 (DRIVE, CPU, SERVO-DSP, AVDEC, VIDEO, AUDIO, PS THROUGH) PRINTED WIRING BOARD
• : Uses unleaded solder.
MV-044 BOARD SIDE A MV-044 BOARD SIDE B
4-5
