Sony RMT-D166P - 5-1. SYSTEM CONTROL PIN FUNCTION (MV-044 BOARD IC201)

5-6
Pin No. Pin name Type Function
146 RD17 Inout DRAM data 17 /
2~16MA, SR Videoin Data PortA 1
PU/PD, SMT
147 RD16 Inout DRAM data 16 /
2~16MA, SR Videoin Data PortA 0
PU/PD, SMT
148 ABCK Output Audio bit clock
4MA
149 ALRCK Inout (1) Audio left/right channel clock
4MA, (2) Trap value in power-on reset :
PD, SMT 1 : use external 373 0 : use internal 373
150 DVDD3 Power 3.3V power pin for internal digital circuitry
151 ACLK Inout Audio DAC master clock (384/256 audio sample frequency)
4MA
152 MC_DATA Input Microphone serial input
153 SPDIF Output SPDIF output
2~16MA,
SR : ON/OFF
154 ASDATA0 Inout (1) Audio serial data 0 (left/right channel)
4MA (2) Trap value in power-on reset :
PD SMT 1 : manufactory test mode 0 : normal operation
155 ASDATA1 Inout (1) Audio serial data 1 (surround left/surround right channel)
4MA (2) Trap value in power-on reset :
PD SMT 1 : manufactory test mode 0 : normal operation
156 ASDATA2 Inout (1) Audio serial data 2 (center/left channel)
4MA (2) Trap value in power-on reset :
PD SMT 1 : manufactory test mode 0 : normal operation
157 ASDATA3 Inout (1) Audio serial data 3 (surround left/surround right channel)
4MA (2) Trap value in power-on reset :
PD SMT 1 : manufactory test mode 0 : normal operation
OR Videoin Data PortB 1
158 ASDATA4 Inout (1) Audio serial data 4 (center/left channel)
4MA (2) Trap value in power-on reset :
PD SMT 1 : manufactory test mode 0 : normal operation
159 DACVDDC Power 3.3V power pin for VIDEO DAC circuitry
160 VREF Analog input Bandgap reference voltage
161 FS Analog output Full scale adjustment
162 YUV0/CIN Output Video data output bit 0 /
4MA, SR Compensation capacitor
163 DACVSSC Ground Ground pin for VIDEO DAC circuitry
164 YUV1/C Output Video data output bit 1 /
4MA, SR Analog chroma output
165 DACVDDB Power 3.3V power pin for VIDEO DAC circuitry
166 YUV2/Y Output Video data output bit 2 /
4MA, SR Analog Y output
167 DACVSSB Ground Ground pin for VIDEO DAC circuitry
168 YUV3/CVBS Output Video data output bit 3 /
4MA, SR Analog composite output
169 DACVDDA Power 3.3V power pin for VIDEO DAC circuitry
170 YUV4/G Output Video data output bit 4 /
4MA, SR Green or Y
171 DACVSSA Ground Ground pin for VIDEO DAC circuitry
172 YUV5/B Output Video data output bit 5 /
4MA, SR Blue or CB
173 YUV6/R Output Video data output bit 6 /
4MA, SR Red or CR
174 ICE Input Microcontroller ICE mode enable
PD, SMT
175 BLAN# Inout Video blank area, active low /
4MA, SR Videoin Field_601
SMT
