Sony RMT-D166P - IF-112 MV-044; 8-2. ELECTRICAL PARTS LIST (continued)

8-5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MV-044IF-112
JR404 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR405 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR406 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR407 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR408 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR409 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR411 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR412 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR413 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JR414 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JS403 1-216-295-91 CONDUCTOR, CHIP (2012) 0
JS404 7-611-005-04 WIRE, TIN PLATING (NS-355:BR4)
<INDUCTOR>
L401 1-456-709-11 COIL, CHOKE 82UH %-3.3
<FLUORESCENT>
ND401 1-518-980-11 VACUUM FLUORESCENT DISPLAY
<TRANSISTOR>
Q401 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q402 8-729-056-46 TRANSISTOR 2SC5053T100Q
<RESISTOR>
R401 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R402 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R403 1-216-025-91 RES, CHIP 100 (2012) 1/10W 5%
R404 1-216-025-91 RES, CHIP 100 (2012) 1/10W 5%
R405 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R406 1-216-025-91 RES, CHIP 10K (2012) 1/10W 5%
R407 1-216-025-91 RES, CHIP 10K (2012) 1/10W 5%
R408 1-216-025-91 RES, CHIP 10K (2012) 1/10W 5%
R409 1-216-025-91 RES, CHIP 10K (2012) 1/10W 5%
R411 1-216-025-91 RES, CHIP 10K (2012) 1/10W 5%
R412 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(NS355:BR4/NS585P:ME2)
R413 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(NS355:BR4/NS585P:ME2)
R414 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(NS585P:ME2)
R415 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(EXCEPT NS585P:ME2)
R416 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R417 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R418 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R419 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R420 1-216-027-91 RES, CHIP 120 (2012) 1/10W 5%
R421 1-216-013-91 RES, CHIP 33 (2012) 1/10W 5%
R422 1-216-097-91 RES, CHIP 100K (2012) 1/10W 5%
R423 1-216-065-91 RES, CHIP 4.7K (2012) 1/10W 5%
R424 1-216-017-91 RES, CHIP 47 (2012) 1/10W 5%
R426 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R427 1-216-083-91 RES, CHIP 27K (2012) 1/10W 5%
R429 1-216-071-91 RES, CHIP 8.2K (2012) 1/10W 5%
R430 1-216-063-91 RES, CHIP 3.9K (2012) 1/10W 5%
R431 1-216-059-91 RES, CHIP 2.7K (2012) 1/10W 5%
R432 1-216-019-91 RES, CHIP 56 (2012) 1/10W 5%
(EXCEPT NS355:BR4)
R433 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(EXCEPT NS575P:CA2/PX3)
R434 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(EXCEPT NS575P:CA2/PX3)
R435 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
R436 1-216-081-91 RES, CHIP 22K (2012) 1/10W 5%
(NS575P:ME5)
R436 1-216-057-91 RES, CHIP 2.2K (2012) 1/10W 5%
(NS575P:ME2/EA4/NS585P:ME2)
R436 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(NS355:BR4/NS575P:CA2/PX3/MX2/E32/AU2/BR4)
R436 1-216-089-91 RES, CHIP 47K (2012) 1/10W 5%
(NS507P/NS525P/NS575P/NS585P:CH)
R436 1-216-065-91 RES, CHIP 4.7K (2012) 1/10W 5%
(NS575P:SP6/TW1/HK2/KR2)
R437 1-216-073-91 RES, CHIP 10K (2012) 1/10W 5%
(NS575P:CA2/PX3/SP6/TW1/HK2/KR2)
R437 1-216-081-91 RES, CHIP 22K (2012) 1/10W
(NS575P:ME5)
R437 1-216-065-91 RES, CHIP 4.7K (2012) 1/10W 5%
(NS507P/NS525P/NS575P/NS585P:CH)
R437 1-216-057-91 RES, CHIP 2.2K (2012) 1/10W 5%
(NS355:BR4/NS575P:MX2/E32/AU2/BR4)
R440 1-216-295-91 CONDUCTOR, CHIP (2012) 0
R441 1-216-295-91 CONDUCTOR, CHIP (2012) 0
<SWITCH>
S401 1-771-874-11 SWITCH, TACTILE
S402 1-771-874-11 SWITCH, TACTILE
S403 1-771-874-11 SWITCH, TACTILE
S404 1-771-874-11 SWITCH, TACTILE
S405 1-771-874-11 SWITCH, TACTILE
S407 1-771-874-11 SWITCH, TACTILE
<TRANSFORMER>
T401 1-443-199-11 DC-DC CONVERTER TRANSFORMER
<VIBRATOR>
X401 1-781-472-21 VIBRATOR, CERAMIC
A-1062-844-A MV044 (MX2) BOARD,COMPLETE (NS575P: E,MX)
A-1062-846-A MV044 (AU2) BOARD,COMPLETE (NS575P: AUS)
A-1062-848-A MV044 (ME2) BOARD,COMPLETE
(NS575P: EA,IR,ME2 / NS585P: ME2)
A-1062-858-A MV044 (ME5) BOARD,COMPLETE (NS575P: ME5)
A-6071-780-A MV044 (U2) BOARD,COMPLETE (NS501P/ NS575P: US,CND,PX)
A-6071-799-A MV044 (SP6) BOARD, COMPLETE (NS575P: KR,HK,SP,TW)
A-6072-072-A MV044(CN) BOARD,COMPLETE
(NS507P:CH/NS525P:CH/NS575P:CH/NS585P:CH)
A-6072-189-A MV044 (BR)BOARD,COMPLETE (NS355:BR)
A-6072-182-A MV044 (PROGBR) BOARD,COMPLETE (NS575P: AR,BR)
