Sony RMT-V402 - Disassembly and Reassembly Guide; Component Identification Views; Main Deck Disassembly Steps

–
3 –
Œ
´
ˇ
¨
ˆ
Ø
Fig. 1-1 Top parts Location-1
ΠGEAR FL CAM
´ MOTOR LOADING ASS’Y
ˇ LEVER FL ARM ASS’Y
¨ HOLDER FL CASSETTE ASS’Y
ˆ LEVER FL DOOR
Ø SLIDER FL DRIVE
1. Disassembly and Reassembly
1-1 Deck Parts Locations
1-1-1 Top View
