15
SA-FT3H/WFT3/SS-CNF3H/FRF3H
SECTION 4
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Abbreviation
CND : Canadian model
SP : Singapore model
MY : Malaysia model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
CONTROL
CONTROL BOARD
**************
< CONNECTOR >
* BC201 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* BC602 1-506-945-11 PIN, CONNECTOR 3P
< CAPACITOR >
C101 1-128-813-11 CERAMIC 220PF 5% 50V
C102 1-126-964-11 ELECT 10uF 20% 50V
C104 1-131-690-31 FILM 0.068uF 5% 50V
C105 1-131-698-31 FILM 0.33uF 5% 50V
C108 1-131-696-11 FILM 0.22uF 5% 50V
C109 1-131-696-11 FILM 0.22uF 5% 50V
C110 1-131-696-11 FILM 0.22uF 5% 50V
C111 1-131-696-11 FILM 0.22uF 5% 50V
C112 1-126-964-11 ELECT 10uF 20% 50V
C113 1-126-964-11 ELECT 10uF 20% 50V
C114 1-131-688-31 FILM 0.047uF 5% 50V
C115 1-131-688-31 FILM 0.047uF 5% 50V
C116 1-126-964-11 ELECT 10uF 20% 50V
C117 1-128-813-11 CERAMIC 220PF 5% 50V
C118 1-127-888-11 CERAMIC 0.1uF 10% 50V
C119 1-127-888-11 CERAMIC 0.1uF 10% 50V
C120 1-104-666-11 ELECT 220uF 20% 25V
C121 1-104-666-11 ELECT 220uF 20% 25V
C122 1-127-888-11 CERAMIC 0.1uF 10% 50V
C123 1-127-888-11 CERAMIC 0.1uF 10% 50V
C124 1-128-813-11 CERAMIC 220PF 5% 50V
C125 1-128-813-11 CERAMIC 220PF 5% 50V
C127 1-104-666-11 ELECT 220uF 20% 25V
C128 1-104-666-11 ELECT 220uF 20% 25V
0 C201 1-117-703-11 CERAMIC 0.0047uF 250V
< CONNECTOR >
CN101 1-785-088-11 PIN, CONNECTOR 6P
< DIODE >
D101 8-719-110-31 DIODE RD12ESB2
D102 8-719-110-31 DIODE RD12ESB2
< IC >
IC101 8-759-167-88 IC NJM4565D
IC102 8-759-167-88 IC NJM4565D
IC103 8-759-167-88 IC NJM4565D
< JACK >
J101 1-815-025-11 JACK, PIN 1P (LINE IN)
< TRANSISTOR >
Q101 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q102 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q103 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R10 1-247-863-11 CARBON 22K 5% 1/4W
R100 1-247-879-11 CARBON 100K 5% 1/4W
R101 1-247-831-11 CARBON 1K 5% 1/4W
R103 1-247-863-11 CARBON 22K 5% 1/4W
R104 1-249-428-11 CARBON 8.2K 5% 1/4W
R105 1-249-428-11 CARBON 8.2K 5% 1/4W
R108 1-249-435-11 CARBON 33K 5% 1/4W
R109 1-249-427-11 CARBON 6.8K 5% 1/4W
R110 1-249-427-11 CARBON 6.8K 5% 1/4W
R111 1-249-435-11 CARBON 33K 5% 1/4W
R112 1-247-831-11 CARBON 1K 5% 1/4W
R113 1-247-871-11 CARBON 47K 5% 1/4W
R114 1-249-429-11 CARBON 10K 5% 1/4W
R115 1-247-831-11 CARBON 1K 5% 1/4W
R116 1-247-881-00 CARBON 120K 5% 1/4W
R117 1-247-831-11 CARBON 1K 5% 1/4W
R118 1-247-895-00 CARBON 470K 5% 1/4W
R119 1-247-847-11 CARBON 4.7K 5% 1/4W
R120 1-249-429-11 CARBON 10K 5% 1/4W
R121 1-249-429-11 CARBON 10K 5% 1/4W
R122 1-249-429-11 CARBON 10K 5% 1/4W
R123 1-249-429-11 CARBON 10K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R126 1-247-871-11 CARBON 47K 5% 1/4W
