16
SA-FT3H/WFT3/SS-CNF3H/FRF3H
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< VARIABLE RESISTOR >
RV101 1-227-511-11 RES, VAR, CARBON 20K (LEVEL)
RV102 1-227-511-11 RES, VAR, CARBON 20K (BASS BOOST)
< SWITCH >
S101 1-786-490-11 SWITCH, SLIDE (POWER SAVE)
S102 1-786-490-11 SWITCH, SLIDE (PHASE)
0 S201 1-572-267-51 SWITCH, PUSH (AC POWER) (1 KEY) (POWER)
*************************************************************
LED BOARD
**********
< CONNECTOR >
* BC202 1-564-519-11 PLUG, CONNECTOR 4P
< CAPACITOR >
C609 1-127-888-11 CERAMIC 0.1uF 10% 50V
C610 1-127-888-11 CERAMIC 0.1uF 10% 50V
< DIODE >
D202 8-719-064-11 LED SPR-325MVW (ON/STANDBY)
< RESISTOR >
R619 1-249-429-11 CARBON 10K 5% 1/4W
(US, CND)
R619 1-249-414-11 CARBON 560 5% 1/4W
(AEP, UK, MY, SP)
*************************************************************
A-1122-632-A MAIN BOARD, COMPLETE (US,CND)
A-1139-695-A MAIN BOARD, COMPLETE (AEP,UK,SP,MY)
***********
1-533-399-31 HOLDER, FUSE
< CONNECTOR >
BC401 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
BC601 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
* BC903 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
* BC905 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< CAPACITOR >
C301 1-127-888-11 CERAMIC 0.1uF 10% 50V
C302 1-126-936-11 ELECT 3300uF 20% 16V
C303 1-128-813-11 CERAMIC 220PF 5% 50V
0 C401 1-130-777-00 MYLAR 0.1uF 5% 100V
0 C402 1-130-777-00 MYLAR 0.1uF 5% 100V
C403 1-165-946-11 ELECT 6800uF 20% 71V
C404 1-165-946-11 ELECT 6800uF 20% 71V
C501 1-126-964-11 ELECT 10uF 20% 50V
C502 1-126-950-11 ELECT 330uF 20% 35V
C503 1-126-923-11 ELECT 220uF 20% 10V
C504 1-128-813-11 CERAMIC 220PF 5% 50V
C511 1-136-165-00 FILM 0.1uF 5% 50V
C512 1-136-165-00 FILM 0.1uF 5% 50V
C601 1-126-964-11 ELECT 10uF 20% 50V
C602 1-126-964-11 ELECT 10uF 20% 50V
C603 1-128-821-11 CERAMIC 0.001uF 5% 50V
C604 1-128-821-11 CERAMIC 0.001uF 5% 50V
C605 1-104-661-11 ELECT 330uF 20% 16V
C606 1-127-888-11 CERAMIC 0.1uF 10% 50V
C607 1-126-934-11 ELECT 220uF 20% 16V
C608 1-127-888-11 CERAMIC 0.1uF 10% 50V
C611 1-128-813-11 CERAMIC 220PF 5% 50V
C612 1-126-916-11 ELECT 1000uF 20% 6.3V
C801 1-136-165-00 FILM 0.1uF 5% 50V
C802 1-136-165-00 FILM 0.1uF 5% 50V
C803 1-126-949-11 ELECT 220uF 20% 35V
C804 1-126-949-11 ELECT 220uF 20% 35V
0 C901 1-117-703-11 CERAMIC 0.0047uF 250V
0 C902 1-117-703-11 CERAMIC 0.0047uF 250V
< CONNECTOR >
CN402 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
CN601 1-785-088-11 PIN, CONNECTOR 6P
CNP702 1-784-931-11 PIN, CONNECTOR 5P
< DIODE >
D301 6-500-522-11 DIODE 10EDB40-TA2B5
D302 6-500-522-11 DIODE 10EDB40-TA2B5
D303 6-500-522-11 DIODE 10EDB40-TA2B5
D304 6-500-522-11 DIODE 10EDB40-TA2B5
D401 8-719-072-05 DIODE RBV-602LF-A
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D531 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
D603 8-719-991-33 DIODE 1SS133T-77
D604 8-719-947-13 DIODE MTZJ-T-72-4.7B
D801 6-500-522-11 DIODE 10EDB40-TA2B5
D802 6-500-522-11 DIODE 10EDB40-TA2B5
D803 6-500-522-11 DIODE 10EDB40-TA2B5
D804 6-500-522-11 DIODE 10EDB40-TA2B5
D901 8-719-991-33 DIODE 1SS133T-77
< GROUND TERMINAL >
EP1 1-537-738-21 TERMINAL, GROUND
< IC >
IC601 8-759-700-42 IC NJM2904D
IC602 8-759-700-42 IC NJM2904D
< TRANSISTOR >
Q501 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q502 8-729-178-42 TRANSISTOR 2SC2784-F
Q503 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q504 8-729-029-86 TRANSISTOR DTC124ESA
Q601 8-729-029-40 TRANSISTOR DTA124ESA
Q602 8-729-029-86 TRANSISTOR DTC124ESA
Q603 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q604 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q605 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q606 8-729-029-40 TRANSISTOR DTA124ESA
CONTROL LED MAIN
