17
SA-FT3H/WFT3/SS-CNF3H/FRF3H
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q607 8-729-029-40 TRANSISTOR DTA124ESA
Q608 8-729-029-40 TRANSISTOR DTA124ESA
< RESISTOR >
R501 1-249-430-11 CARBON 12K 5% 1/4W
R502 1-247-873-11 CARBON 56K 5% 1/4W
R503 1-247-879-11 CARBON 100K 5% 1/4W
R504 1-247-879-11 CARBON 100K 5% 1/4W
R505 1-247-863-11 CARBON 22K 5% 1/4W
R506 1-247-863-11 CARBON 22K 5% 1/4W
0 R507 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
R508 1-249-393-11 CARBON 10 5% 1/4W F
R511 1-249-393-11 CARBON 10 5% 1/4W
R601 1-247-863-11 CARBON 22K 5% 1/4W
R602 1-247-863-11 CARBON 22K 5% 1/4W
R603 1-247-895-00 CARBON 470K 5% 1/4W
R604 1-247-895-00 CARBON 470K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-247-887-00 CARBON 220K 5% 1/4W
R607 1-247-879-11 CARBON 100K 5% 1/4W
R608 1-249-429-11 CARBON 10K 5% 1/4W
R609 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-247-879-11 CARBON 100K 5% 1/4W
R611 1-247-871-11 CARBON 47K 5% 1/4W
R613 1-249-421-11 CARBON 2.2K 5% 1/4W
R614 1-247-879-11 CARBON 100K 5% 1/4W
R615 1-247-871-11 CARBON 47K 5% 1/4W
R616 1-247-871-11 CARBON 47K 5% 1/4W
R617 1-247-807-31 CARBON 100 5% 1/4W
(US, CND)
R618 1-249-415-11 CARBON 680 5% 1/4W
R620 1-249-427-11 CARBON 6.8K 5% 1/4W
R621 1-247-843-11 CARBON 3.3K 5% 1/4W
(US, CND)
R621 1-247-835-11 CARBON 1.5K 5% 1/4W
(AEP, UK, MY, SP)
R801 1-247-879-11 CARBON 100K 5% 1/4W
R802 1-247-879-11 CARBON 100K 5% 1/4W
0 R803 1-217-637-00 FUSIBLE 1 5% 1/4W F
0 R804 1-217-637-00 FUSIBLE 1 5% 1/4W F
0 R901 1-260-081-11 CARBON 33 5% 1/2W F
< RELAY >
RY501 1-515-920-11 RELAY (24V)
0 RY901 1-755-541-11 RELAY
< TRANSFORMER >
0 T202 1-443-516-11 TRANSFORMER, POWER (US,CND)
0 T202 1-443-517-11 TRANSFORMER, POWER (AEP,UK,SP,MY)
*************************************************************
POWER AMP BOARD
*****************
< CAPACITOR >
C701 1-128-817-11 CERAMIC 470PF 5% 50V
C702 1-126-964-11 ELECT 10uF 20% 50V
C703 1-126-923-11 ELECT 220uF 20% 10V
C704 1-128-560-11 ELECT 22uF 20% 100V
C705 1-128-825-11 CERAMIC 0.0022uF 5% 50V
C706 1-102-947-00 CERAMIC 10PF 0.5PF 50V
C707 1-102-978-00 CERAMIC 220PF 5% 50V
C708 1-102-973-00 CERAMIC 100PF 5% 50V
C709 1-128-560-11 ELECT 22uF 20% 100V
C710 1-126-967-11 ELECT 47uF 20% 50V
C711 1-102-973-00 CERAMIC 100PF 5% 50V
C712 1-102-973-00 CERAMIC 100PF 5% 50V
C713 1-128-805-11 CERAMIC 47PF 5% 50V
C7000 1-102-978-00 CERAMIC 220PF 5% 50V
< CONNECTOR >
* CN702 1-506-945-11 PIN, CONNECTOR 3P
CNP701 1-784-931-11 PIN, CONNECTOR 5P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
D704 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q701 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q702 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q703 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q704 8-729-214-51 TRANSISTOR 2SA1145-O
Q705 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q706 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q707 8-729-270-51 TRANSISTOR 2SC2705-O
Q710 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q711 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R701 1-247-831-11 CARBON 1K 5% 1/4W
R702 1-249-399-11 CARBON 33 5% 1/4W
R703 1-247-871-11 CARBON 47K 5% 1/4W
R704 1-249-418-11 CARBON 1.2K 5% 1/4W
R705 1-249-411-11 CARBON 330 5% 1/4W
R706 1-249-408-11 CARBON 180 5% 1/4W
R707 1-249-411-11 CARBON 330 5% 1/4W
R708 1-249-429-11 CARBON 10K 5% 1/4W
R709 1-247-863-11 CARBON 22K 5% 1/4W
R710 1-249-407-11 CARBON 150 5% 1/4W F
R711 1-249-393-11 CARBON 10 5% 1/4W F
R712 1-247-871-11 CARBON 47K 5% 1/4W
R713 1-249-408-11 CARBON 180 5% 1/4W F
R714 1-249-408-11 CARBON 180 5% 1/4W F
R715 1-249-401-11 CARBON 47 5% 1/4W F
R716 1-249-393-11 CARBON 10 5% 1/4W F
R717 1-249-414-11 CARBON 560 5% 1/4W
R718 1-247-871-11 CARBON 47K 5% 1/4W
R719 1-249-421-11 CARBON 2.2K 5% 1/4W
R720 1-249-406-11 CARBON 120 5% 1/4W F
R721 1-249-406-11 CARBON 120 5% 1/4W F
R722 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
*************************************************************
MAIN POWER AMP
