13
SA-WMS356/WMS556
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1059-722-A MAIN BOARD, COMPLETE
*********************
< CONNECTOR >
BC401 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* BC801 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P
BC802 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
BC803 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< CAPACITOR >
C101 1-126-933-11 ELECT 100uF 20% 16V
C102 1-126-933-11 ELECT 100uF 20% 16V
C301 1-136-165-00 FILM 0.1uF 5% 50V
C302 1-136-165-00 FILM 0.1uF 5% 50V
C303 1-104-666-11 ELECT 220uF 20% 25V
C304 1-104-666-11 ELECT 220uF 20% 25V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-124-247-11 ELECT 10uF 20% 35V
C308 1-124-247-11 ELECT 10uF 20% 35V
C401 1-124-257-00 ELECT 2.2uF 20% 35V
C402 1-126-950-11 ELECT 330uF 20% 35V
C403 1-126-923-11 ELECT 220uF 20% 10V
C531 1-104-662-11 ELECT 22uF 20% 25V
C532 1-104-661-11 ELECT 330uF 20% 16V
C801 1-165-946-11 ELECT 6800uF 20% 71V
C802 1-165-946-11 ELECT 6800uF 20% 71V
C803 1-130-777-00 MYLAR 0.1uF 10% 100V
C804 1-130-777-00 MYLAR 0.1uF 10% 100V
C805 1-162-306-11 CERAMIC 0.01uF 20% 16V
C806 1-162-306-11 CERAMIC 0.01uF 20% 16V
< DIODE >
D301 8-719-024-99 DIODE 11ES2-NTA2B
D302 8-719-024-99 DIODE 11ES2-NTA2B
D303 8-719-024-99 DIODE 11ES2-NTA2B
D304 8-719-024-99 DIODE 11ES2-NTA2B
D305 8-719-110-31 DIODE RD12ESB2
D306 8-719-110-31 DIODE RD12ESB2
D400 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77
D531 8-719-991-33 DIODE 1SS133T-77
D532 8-719-991-33 DIODE 1SS133T-77
D533 8-719-991-33 DIODE 1SS133T-77
D805 8-719-072-05 DIODE RBV-602LF-A
< GROUND TERMINAL >
G1 1-537-738-21 TERMINAL, GROUND
G2 1-537-738-21 TERMINAL, GROUND
< IC >
IC530 6-704-502-01 IC NJM022D
< TRANSISTOR >
Q101 8-729-029-86 TRANSISTOR DTC124ESA
Q102 8-729-029-86 TRANSISTOR DTC124ESA
Q103 8-729-029-40 TRANSISTOR DTA124ESA
Q104 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q105 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q301 8-729-281-53 TRANSISTOR 2SC1815-GR
Q302 8-729-201-53 TRANSISTOR 2SA1015-GR
Q401 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q402 8-729-178-42 TRANSISTOR 2SC2784-F
Q403 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q404 8-729-029-86 TRANSISTOR DTC124ESA
Q531 8-729-029-86 TRANSISTOR DTC124ESA
Q532 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q533 8-729-029-86 TRANSISTOR DTC124ESA
Q534 8-729-900-63 TRANSISTOR DTA124ES
Q535 8-729-900-63 TRANSISTOR DTA124ES
< RESISTOR >
R101 1-247-863-11 CARBON 22K 5% 1/4W
R102 1-247-863-11 CARBON 22K 5% 1/4W
R103 1-249-427-11 CARBON 6.8K 5% 1/4W
R104 1-249-427-11 CARBON 6.8K 5% 1/4W
R105 1-247-843-11 CARBON 3.3K 5% 1/4W
R106 1-247-843-11 CARBON 3.3K 5% 1/4W
R303 1-249-421-11 CARBON 2.2K 5% 1/4W
R304 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R400 1-215-869-11 METAL OXIDE 1K 5% 1W F
R401 1-249-430-11 CARBON 12K 5% 1/4W
R402 1-247-873-11 CARBON 56K 5% 1/4W
R403 1-247-879-11 CARBON 100K 5% 1/4W
R404 1-247-879-11 CARBON 100K 5% 1/4W
R405 1-247-863-11 CARBON 22K 5% 1/4W
R406 1-247-863-11 CARBON 22K 5% 1/4W
R531 1-247-895-00 CARBON 470K 5% 1/4W
R532 1-247-883-00 CARBON 150K 5% 1/4W
R533 1-247-903-00 CARBON 1M 5% 1/4W
R534 1-247-879-11 CARBON 100K 5% 1/4W
R535 1-249-429-11 CARBON 10K 5% 1/4W
R536 1-249-429-11 CARBON 10K 5% 1/4W
R537 1-247-879-11 CARBON 100K 5% 1/4W
R538 1-247-903-00 CARBON 1M 5% 1/4W
R539 1-247-863-11 CARBON 22K 5% 1/4W
R540 1-249-421-11 CARBON 2.2K 5% 1/4W
R541 1-249-421-11 CARBON 2.2K 5% 1/4W
R542 1-247-831-11 CARBON 1K 5% 1/4W
R800 1-247-873-11 CARBON 56K 5% 1/4W
< RELAY >
RY400 1-515-920-11 RELAY (24V)
*************************************************************
POWER AMP BOARD
*****************
< CAPACITOR >
C701 1-102-978-00 CERAMIC 220PF 5% 50V
C702 1-102-978-00 CERAMIC 220PF 5% 50V
C703 1-128-562-11 ELECT 47uF 20% 100V
C704 1-102-936-00 CERAMIC 3PF 0.25PF 50V
C705 1-126-961-11 ELECT 2.2uF 20% 50V
MAIN POWER AMP
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
