Sony SA-WMS556 - ELECTRICAL PARTS LIST; POWER SUPPLY BOARD COMPONENTS; POWER SWITCH BOARD COMPONENTS

14
SA-WMS356/WMS556
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C706 1-104-666-11 ELECT 220uF 20% 25V
C707 1-128-563-11 ELECT 100uF 20% 100V
C708 1-128-582-11 ELECT 10uF 20% 100V
C709 1-104-665-11 ELECT 100uF 20% 25V
C710 1-102-824-00 CERAMIC 470PF 5% 50V
C711 1-128-582-11 ELECT 10uF 20% 100V
C712 1-136-165-00 FILM 0.1uF 5% 50V
C713 1-102-978-00 CERAMIC 220PF 5% 50V
C714 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C715 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C716 1-162-292-31 CERAMIC 680PF 10% 50V
< CONNECTOR >
* CN701 1-506-610-11 PIN, CONNECTOR 10P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
< IC >
IC701 6-600-182-01 IC STK404-140S
< TRANSISTOR >
Q701 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q702 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
< RESISTOR >
R701 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R702 1-260-110-11 CARBON 8.2K 5% 1/2W F
R703 1-260-110-11 CARBON 8.2K 5% 1/2W F
R704 1-247-873-11 CARBON 56K 5% 1/4W
R705 1-247-831-11 CARBON 1K 5% 1/4W
R706 1-215-886-11 METAL OXIDE 100 5% 2W F
R707 1-247-831-11 CARBON 1K 5% 1/4W
R708 1-247-873-11 CARBON 56K 5% 1/4W
R709 1-247-863-11 CARBON 22K 5% 1/4W
R710 1-247-831-11 CARBON 1K 5% 1/4W
R711 1-247-847-11 CARBON 4.7K 5% 1/4W
0 R712 1-202-972-61 FUSIBLE 1 5% 1/4W F
R713 1-216-357-00 METAL OXIDE 4.7 5% 1W F
R714 1-249-399-11 CARBON 33 5% 1/4W
R715 1-247-847-11 CARBON 4.7K 5% 1/4W
R716 1-247-850-11 CARBON 6.2K 5% 1/4W
R717 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
POWER SUPPLY BOARD
*******************
1-533-217-41 HOLDER, FUSE
< CONNECTOR >
BC901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* BC902 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
* BC903 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
0 C902 1-113-925-11 CERAMIC 0.01uF 20% 250V
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< RELAY >
0 RY901 1-755-458-11 RELAY
< TRANSFORMER >
0 T202 1-443-349-11 TRANSFORMER, POWER
*************************************************************
POWER SWITCH BOARD
********************
< CONNECTOR >
BC202 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< CAPACITOR >
0 C201 1-117-703-11 CERAMIC 0.0047uF 250V
< SWITCH >
0 S201 1-554-920-11 SWITCH, PUSH (AC POWER) (1 KEY) (POWER)
*************************************************************
MISCELLANEOUS
**************
0 55 1-829-415-11 CORD, POWER
0 F901 1-532-502-31 FUSE (T1.25AL/250V)
SP401 1-825-844-11 SPEAKER (15cm) (WOOFER)
SP402 1-825-844-11 SPEAKER (15cm) (WOOFER)
0 T102 1-443-276-11 TRANSFORMER, POWER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER AMP POWER SUPPLY POWER SWITCH
