13
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
SECTION 4
ELECTRICAL PARTS LIST
INPUT CONTROL BOARD (SA-WP5000)
********************
< CAPACITOR >
C801 1-128-813-11 CERAMIC 220PF 5% 50V
< JACK >
J101 1-815-025-11 JACK, PIN 1P (INPUT)
< VARIABLE RESISTOR >
RV801 1-227-511-11 RES, VAR, CARBON 20K (LEVEL)
*************************************************************
LED BOARD (SA-WP5000)
**********
< CAPACITOR >
C601 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CNP901 1-564-517-11 PLUG, CONNECTOR 2P
< LED >
D901 6-501-077-01 LED LNH301MPU0A1 (POWER)
*************************************************************
A-1439-168-A MAIN BOARD, COMPLETE (E51) (SA-WP5000)
A-1439-204-A MAIN BOARD, COMPLETE (SP, MY, TH)
(SA-WP5000)
A-1439-205-A MAIN BOARD, COMPLETE (AUS) (SA-WP5000)
A-1439-206-A MAIN BOARD, COMPLETE (AR) (SA-WP5000)
A-1439-208-A MAIN BOARD, COMPLETE (MX) (SA-WP5000)
********************
< CAPACITOR >
C120 1-126-933-11 ELECT 100uF 20% 16V
C121 1-126-933-11 ELECT 100uF 20% 16V
C127 1-126-947-11 ELECT 47uF 20% 35V
C128 1-126-947-11 ELECT 47uF 20% 35V
C201 1-126-964-11 ELECT 10uF 20% 50V
C203 1-137-190-91 FILM 0.22uF 5% 50V
C204 1-137-190-91 FILM 0.22uF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-136-157-00 FILM 0.022uF 5% 50V
C208 1-136-175-00 FILM 0.68uF 5% 50V
C209 1-128-813-11 CERAMIC 220PF 5% 50V
C210 1-127-888-11 CERAMIC 0.1uF 10% 50V
C211 1-128-813-11 CERAMIC 220PF 5% 50V
C212 1-127-888-11 CERAMIC 0.1uF 10% 50V
C301 1-128-813-11 CERAMIC 220PF 5% 50V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-104-658-91 ELECT 100uF 20% 10V
C304 1-128-813-11 CERAMIC 220PF 5% 50V
C305 1-128-825-11 CERAMIC 2200PF 5% 50V
C306 1-102-973-00 CERAMIC 100PF 5% 50V
C307 1-128-560-11 ELECT 22uF 20% 100V
C308 1-102-947-00 CERAMIC 10PF 0.5PF 50V
C309 1-126-947-11 ELECT 47uF 20% 35V
C310 1-128-560-11 ELECT 22uF 20% 100V
C313 1-101-880-00 CERAMIC 47PF 5% 50V
C318 1-127-880-11 CERAMIC 0.022uF 10% 50V
C319 1-101-810-00 CERAMIC 100PF 5% 500V
C320 1-101-810-00 CERAMIC 100PF 5% 500V
C321 1-128-825-11 CERAMIC 2200PF 5% 50V (AUS)
C322 1-128-813-11 CERAMIC 220PF 5% 50V
C401 1-130-777-00 MYLAR 0.1uF 5% 100V
C402 1-130-777-00 MYLAR 0.1uF 5% 100V
C403 1-100-304-11 ELECT 3300uF 20% 71V
(MX, SP, MY, AR, TH, AUS)
C403 1-127-814-11 ELECT (BLOCK) 3300uF 20% 80V
(E51)
C404 1-100-304-11 ELECT 3300uF 20% 71V
(MX, SP, MY, AR, TH, AUS)
C404 1-127-814-11 ELECT (BLOCK) 3300uF 20% 80V
(E51)
C407 1-126-949-11 ELECT 220uF 20% 35V
C408 1-126-948-11 ELECT 100uF 20% 35V
C409 1-127-888-11 CERAMIC 0.1uF 10% 50V
C410 1-127-888-11 CERAMIC 0.1uF 10% 50V
C504 1-126-965-91 ELECT 22uF 20% 50V
C505 1-127-880-11 CERAMIC 0.022uF 10% 50V
C506 1-104-658-91 ELECT 100uF 20% 10V
C507 1-127-880-11 CERAMIC 0.022uF 10% 50V
C508 1-126-963-11 ELECT 4.7uF 20% 50V
C509 1-126-967-11 ELECT 47uF 20% 50V
C510 1-126-967-11 ELECT 47uF 20% 50V
C731 1-128-813-11 CERAMIC 220PF 5% 50V
< CONNECTOR >
CN201 1-784-931-11 PIN, CONNECTOR 5P
CN301 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
AUS : Australian model
E51 : Chilean and Peruvian models
MX : Mexican model
MY : Malaysia model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
SP : Singapore model
TH : Thai model
LEDINPUT CONTROL
Ver. 1.1
