Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-WP5000/SS-CNP5000/CRP5000/CRP7001/MSP5000/SRP5000
14
CN402 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
* CN601 1-506-944-11 PIN, CONNECTOR 2P
< DIODE >
D101 8-719-947-60 DIODE MTZJ-T-72-15A
D102 8-719-947-60 DIODE MTZJ-T-72-15A
D303 8-719-991-33 DIODE 1SS133T-77
D304 8-719-991-33 DIODE 1SS133T-77
D305 8-719-991-33 DIODE 1SS133T-77
D306 8-719-991-33 DIODE 1SS133T-77
D307 8-719-991-33 DIODE 1SS133T-77
D308 8-719-991-33 DIODE 1SS133T-77
D309 8-719-991-33 DIODE 1SS133T-77
D402 8-719-510-68 DIODE D5SBA204101
D504 6-500-522-11 DIODE 10EDB40-TA2B5
D505 8-719-991-33 DIODE 1SS133T-77
D506 8-719-991-33 DIODE 1SS133T-77
D801 6-500-522-11 DIODE 10EDB40-TA2B5
D802 6-500-522-11 DIODE 10EDB40-TA2B5
D803 6-500-522-11 DIODE 10EDB40-TA2B5
D804 6-500-522-11 DIODE 10EDB40-TA2B5
< GROUND TERMINAL >
G1 1-537-738-21 TERMINAL, GROUND
< IC >
IC202 8-759-167-88 IC NJM4565D
IC203 8-759-167-88 IC NJM4565D
IC500 6-708-609-01 IC uPC1237C-A
< TRANSISTOR >
Q102 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q103 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q301 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q302 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q303 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q304 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q305 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q306 8-729-270-51 TRANSISTOR 2SC2705-O
Q309 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q310 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q311 8-729-214-51 TRANSISTOR 2SA1145-O
Q505 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q731 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R123 1-249-429-11 CARBON 10K 5% 1/4W
R124 1-249-429-11 CARBON 10K 5% 1/4W
R202 1-247-831-91 CARBON 1K 5% 1/4W
R205 1-247-871-91 CARBON 47K 5% 1/4W
R206 1-249-439-11 CARBON 68K 5% 1/4W
R207 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-247-847-91 CARBON 4.7K 5% 1/4W
R209 1-249-429-11 CARBON 10K 5% 1/4W
R210 1-247-871-91 CARBON 47K 5% 1/4W
R211 1-249-428-11 CARBON 8.2K 5% 1/4W
R212 1-249-428-11 CARBON 8.2K 5% 1/4W
R213 1-249-428-11 CARBON 8.2K 5% 1/4W
R214 1-247-883-00 CARBON 150K 5% 1/4W
R216 1-247-831-91 CARBON 1K 5% 1/4W
MAIN
R217 1-247-879-91 CARBON 100K 5% 1/4W
R301 1-247-831-91 CARBON 1K 5% 1/4W
R304 1-247-871-91 CARBON 47K 5% 1/4W
R305 1-249-418-11 CARBON 1.2K 5% 1/4W
R307 1-249-411-11 CARBON 330 5% 1/4W
R308 1-249-411-11 CARBON 330 5% 1/4W
R309 1-249-408-11 CARBON 180 5% 1/4W
R310 1-249-408-11 CARBON 180 5% 1/4W
0 R311 1-215-888-51 METAL OXIDE 220 5% 2W F
R314 1-247-871-91 CARBON 47K 5% 1/4W
R315 1-249-389-11 CARBON 4.7 5% 1/4W
(AUS)
R316 1-249-408-11 CARBON 180 5% 1/4W
R317 1-249-393-11 CARBON 10 5% 1/4W
R318 1-249-414-11 CARBON 560 5% 1/4W
R319 1-247-871-91 CARBON 47K 5% 1/4W
R320 1-249-393-11 CARBON 10 5% 1/4W
R321 1-249-407-11 CARBON 150 5% 1/4W
R322 1-247-863-91 CARBON 22K 5% 1/4W
R323 1-249-429-11 CARBON 10K 5% 1/4W
R324 1-249-408-11 CARBON 180 5% 1/4W
R325 1-249-401-11 CARBON 47 5% 1/4W
R326 1-249-393-11 CARBON 10 5% 1/4W
0 R327 1-234-572-11 ENCAPSULATED COMPONENT 0.22 5W F
R328 1-249-408-11 CARBON 180 5% 1/4W
R329 1-249-421-11 CARBON 2.2K 5% 1/4W
R330 1-249-399-11 CARBON 33 5% 1/4W
R331 1-247-831-91 CARBON 1K 5% 1/4W
R332 1-247-831-91 CARBON 1K 5% 1/4W
0 R403 1-217-637-91 FUSIBLE 1 5% 1/4W F
0 R404 1-217-637-91 FUSIBLE 1 5% 1/4W F
R500 1-247-863-91 CARBON 22K 5% 1/4W
R501 1-249-429-11 CARBON 10K 5% 1/4W
R507 1-247-883-00 CARBON 150K 5% 1/4W
R508 1-247-863-91 CARBON 22K 5% 1/4W
R510 1-247-879-91 CARBON 100K 5% 1/4W
R511 1-249-429-11 CARBON 10K 5% 1/4W
R512 1-249-439-11 CARBON 68K 5% 1/4W
R513 1-249-431-11 CARBON 15K 5% 1/4W
R515 1-249-429-11 CARBON 10K 5% 1/4W
0 R601 1-215-871-51 METAL OXIDE 2.2K 5% 1W F
R731 1-247-847-91 CARBON 4.7K 5% 1/4W
R732 1-249-431-11 CARBON 15K 5% 1/4W
< RELAY >
RY301 1-755-170-11 RELAY (12V)
*************************************************************
POWER TRANS BOARD (SA-WP5000)
*******************
< CONNECTOR >
* CN1 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< FUSE HOLDER >
FH901 1-533-217-31 FUSE HOLDER (E51)
FH902 1-533-217-31 FUSE HOLDER (E51)
FH903 1-533-217-31 FUSE HOLDER
FH904 1-533-217-31 FUSE HOLDER
FH905 1-533-217-31 FUSE HOLDER (E51)
POWER TRANS
