SLT-A77/A77Q/A77V/A77VK/A77VQ_L3
2-4
R3722 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3723 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3726 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3727 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R3730 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R3731 1-208-671-11 METAL CHIP 330 0.5% 1/16W
R3732 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3733 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R3734 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3735 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3736 1-216-137-00 METAL CHIP 3 5% 1/8W
R3737 1-217-806-11 METAL CHIP 1 5% 1/8W
R3749 1-216-134-00 METAL CHIP 2.2 5% 1/8W
R3750 1-218-990-81 SHORT CHIP 0
R3752 1-218-990-81 SHORT CHIP 0
R3901 1-218-929-11 METAL CHIP 10 5% 1/16W
R3902 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3905 1-218-990-81 SHORT CHIP 0
R3915 1-218-937-11 METAL CHIP 47 5% 1/16W
R3916 1-218-937-11 METAL CHIP 47 5% 1/16W
R3917 1-218-937-11 METAL CHIP 47 5% 1/16W
R3918 1-218-937-11 METAL CHIP 47 5% 1/16W
R5006 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R5007 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R5009 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
* R5011 1-246-338-21 METAL CHIP 3M 1/8W
R5012 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R5013 1-208-859-81 METAL CHIP 68 0.5% 1/16W
R5019 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R5020 1-216-238-91 METAL CHIP 47K 5% 1/8W
R5021 1-216-238-91 METAL CHIP 47K 5% 1/8W
R5022 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R5024 1-218-941-81 METAL CHIP 100 5% 1/16W
R5026 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB0501 1-234-383-21 RES, NETWORK 470K (1005X4)
RB1001 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB1002 1-234-375-21 RES, NETWORK 1K (1005X4)
RB1003 1-234-380-21 RES, NETWORK 47K (1005X4)
RB 1111 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1112 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1120 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB2101 1-234-371-11 RES, NETWORK 47 (1005X4)
RB2102 1-234-371-11 RES, NETWORK 47 (1005X4)
RB2103 1-234-371-11 RES, NETWORK 47 (1005X4)
RB2104 1-234-371-11 RES, NETWORK 47 (1005X4)
RB2105 1-234-371-11 RES, NETWORK 47 (1005X4)
RB2106 1-234-371-11 RES, NETWORK 47 (1005X4)
RB2108 1-234-373-21 RES, NETWORK 220 (1005X4)
RB2109 1-234-373-21 RES, NETWORK 220 (1005X4)
RB2110 1-234-373-21 RES, NETWORK 220 (1005X4)
RB2111 1-234-373-21 RES, NETWORK 220 (1005X4)
RB2112 1-234-373-21 RES, NETWORK 220 (1005X4)
RB2113 1-234-373-21 RES, NETWORK 220 (1005X4)
RB2201 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2203 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2208 1-234-381-11 RES, NETWORK 100K (1005X4)
RB2209 1-234-375-21 RES, NETWORK 1K (1005X4)
RB2401 1-234-381-11 RES, NETWORK 100K (1005X4)
RB3001 1-234-382-21 RES, NETWORK 220K (1005X4)
RB3002 1-234-381-11 RES, NETWORK 100K (1005X4)
RB3004 1-234-375-21 RES, NETWORK 1K (1005X4)
RB3005 1-234-378-21 RES, NETWORK 10K (1005X4)
RB3101 1-234-375-21 RES, NETWORK 1K (1005X4)
RB3102 1-234-375-21 RES, NETWORK 1K (1005X4)
RB3103 1-234-381-11 RES, NETWORK 100K (1005X4)
RB3401 1-234-370-21 RES, NETWORK 22 (1005X4)
RB3402 1-234-381-11 RES, NETWORK 100K (1005X4)
RB3701 1-234-381-11 RES, NETWORK 100K (1005X4)
RB3702 1-234-375-21 RES, NETWORK 1K (1005X4)
< ACCELEROMETER >
SE2501 1-489-146-11 DIGITAL ACCELEROMETER (ADXL345)
< TRANSFORMER >
T5001 1-697-102-21 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR >
TH3701 1-804-949-11 THERMISTOR, NTC (SMD)
< VARISTOR >
* VD3702 1-802-128-11 VARISTOR (SMD)
< VIBRATOR >
X1001 1-813-403-81 QUARTZ CRYSTAL OSCILLATOR (12MHz)
X1111 1-814-552-11 VIBRATOR, CRYSTAL (25MHz)
X2201 1-814-147-11 QUARTZ CRYSTAL OSCILLATOR (50MHz)
X3001 1-795-244-11 VIBRATOR, CERAMIC (10MHz)
X3101 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
A-1849-299-A AP APERTURE UNIT (SERVICE)
(Not supplied) AP-037 FLEXIBLE BOARD, COMPLETE
******************************
(All mounted parts and AF-037 FLEXIBLE COMPLETE BOARD are not supplied, but
they are included in AP APERTURE UNIT (SERVICE).)
A-1837-336-A BL CONTACT UNIT
(Not supplied) BL-038 FLEXIBLE BOARD, COMPLETE
******************************
(BL-038 FLEXIBLE COMPLETE BOARD is not supplied, but this is included in BL
CONTACT UNIT.)
1-884-798-21 EYE-012 FLEXIBLE BOARD, COMPLETE
*******************************
(All mounted parts are not supplied, but they are included in EYE-012 FLEXIBLE
COMPLETE BOARD.)
A-1837-191-A GO-001 BOARD, COMPLETE
**********************
< CAPACITOR >
C6302 1-116-403-91 CERAMIC CHIP 10uF 10% 6.3V
C6303 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6308 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6309 1-100-252-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
CN6301 1-816-655-61 CONNECTOR, FFC/FPC 8P
< SENSOR >
* SE6301 1-489-735-21 SENSOR, ANGULAR VELOCITY
A-1837-380-A GP868 COMPL (A77V/A77VK/A77VQ)
(Not supplied) GP-042 BOARD (A77V/A77VK/A77VQ)
*****************************
(All mounted parts and GP-042 BOARD are not supplied, but they are included in GP868
COMPL.)
1-884-790-11 GRP-001 FLEXIBLE BOARD
*********************
1-884-794-11 HOJ-001 FLEXIBLE BOARD
*********************
A-1842-086-A SLIDER UNIT (870 SERVICE), AS
(Not supplied) HOL-007 FLEXIBLE BOARD
*********************
(All mounted parts and HOL-007 FLEXIBLE BOARD are not supplied, but they are
included in AS SLIDER UNIT S (870) S (T).)
A-1842-025-A IM IMAGER UNIT ASSY (870)
(Not supplied) IS-095 BOARD, COMPLETE
*********************
(All mounted parts and IS-095 COMPLETE BOARD are not supplied, but they are
included in IM IMAGER UNIT ASSY (870).)
1-884-795-11 ISL-005 FLEXIBLE BOARD
********************
1-884-796-11 ISP-004 FLEXIBLE BOARD
********************
1-839-336-11 LCD-022 FLEXIBLE BOARD
*********************
1-884-799-21 MCR-001 FLEXIBLE BOARD, COMPLETE
********************************
(All mounted parts are not supplied, but they are included in MCR-001 FLEXIBLE
COMPLETE BOARD.)
A-1837-196-A PD-444 BOARD, COMPLETE
**********************
< CAPACITOR >
C6202 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C6204 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
C6205 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
C6206 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C6207 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
C6208 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C6209 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6210 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C6211 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6212 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
C6214 1-100-415-91 CERAMIC CHIP 0.47uF 10% 6.3V
C6215 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
C6216 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6217 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6218 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6219 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
< CONNECTOR >
CN6201 1-843-042-11 CONNECTOR, COAXIAL (RECEPTACLE)
CN6202 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
* CN6203 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
< DIODE >
D6201 6-502-934-01 DIODE DB2S31100K8
D6202 6-502-934-01 DIODE DB2S31100K8
< IC >
IC6201 6-717-797-01 IC BU7962GUW-SE2
< RESISTOR >
R6208 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6216 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
A-1837-195-A RM-100 FLEXIBLE BOARD, COMPLETE
******************************
(All mounted parts are not supplied, but they are included in RM-100 FLEXIBLE
COMPLETE BOARD.)
1-884-793-41 SHD-003 (870) FLEXIBLE BOARD, COMPLETE
************************************
(All mounted parts are not supplied, but they are included in SHD-003 (870) FLEXIBLE
COMPLETE BOARD.)
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
AM-027 AP-037 BL-038 EYE-012 GO-001 GP-042 GRP-001 HOJ-001 HOL-007 IS-095 ISL-005 ISP-004 LCD-022 MCR-001 PD-444 RM-100 SHD-003
Ref. No. Part No. Description
To Next Page
