SLT-A77/A77Q/A77V/A77VK/A77VQ_L3
2-5E
1-884-792-21 SHM-002 FLEXIBLE BOARD, COMPLETE
*******************************
(All mounted parts are not supplied, but they are included in SHM-002 FLEXIBLE
COMPLETE BOARD.)
A-1837-199-A SL-070 BOARD, COMPLETE
**********************
< CAPACITOR >
C6501 1-100-252-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
CN6501 1-816-655-61 CONNECTOR, FFC/FPC 8P
< DIODE >
D6601 6-600-623-01 DIODE SML-A12WTT86J
D6603 6-600-623-01 DIODE SML-A12WTT86J
< IC >
IC6501 6-717-750-01 IC BU9798KV-E2
< TRANSISTOR >
* Q6603 6-552-348-01 TRANSISTOR DRC3114E0L
< RESISTOR >
R6502 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6505 1-218-965-11 METAL CHIP 10K 5% 1/16W
R6602 1-218-947-11 METAL CHIP 330 5% 1/16W
R6606 1-218-947-11 METAL CHIP 330 5% 1/16W
A-1837-333-A SLK FPC UNIT 870 BOARD, COMPLETE
(Not supplied) SLK-009 FLEXIBLE BOARD
*********************
(All mounted parts and SLK-009 FLEXIBLE COMPLETE BOARD are not supplied, but
they are included in SLK FPC UNIT 870 COMPLETE BOARD.)
Ref. No. Part No. Description
SHM-002 SL-070 SLK-009
Ref. No. Part No. Description
