8-17
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R426 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R428 1-216-041-00 METAL CHIP 470 5% 1/10W
R429 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R432 1-249-429-11 CARBON 10K 5% 1/4W
R450 1-216-029-00 METAL CHIP 150 5% 1/10W
(ED10/EZ10)
R451 1-216-021-00 METAL CHIP 68 5% 1/10W
R452 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R453 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(ED10/EZ10)
R454 1-249-421-11 CARBON 2.2K 5% 1/4W
(ED10/EZ10)
R455 1-216-021-00 METAL CHIP 68 5% 1/10W
R456 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R457 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R458 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R459 1-216-089-00 METAL CHIP 47K 5% 1/10W
R460 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R461 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R462 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R463 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R464 1-216-081-00 METAL CHIP 22K 5% 1/10W
(ED10/ED40/ED60/ED70/EZ70)
R465 1-216-089-00 METAL CHIP 47K 5% 1/10W
R466 1-216-089-00 METAL CHIP 47K 5% 1/10W
R468 1-249-431-11 CARBON 15K 5% 1/4W
R469 1-249-437-11 CARBON 47K 5% 1/4W
R470 1-249-437-11 CARBON 47K 5% 1/4W
R602 1-216-073-00 METAL CHIP 10K 5% 1/10W
R608 1-216-471-11 METAL OXIDE 27 5% 3W F
R609 1-215-857-11 METAL OXIDE 10 5% 1W F
R616 1-249-419-11 CARBON 1.5K 5% 1/4W
! R702 1-212-893-00 FUSIBLE 330 5% 1/4W F
R703 1-216-041-00 METAL CHIP 470 5% 1/10W
R704 1-216-041-00 METAL CHIP 470 5% 1/10W
R705 1-216-049-00 METAL CHIP 1K 5% 1/10W
R706 1-216-113-00 METAL CHIP 470K 5% 1/10W
R707 1-216-049-00 METAL CHIP 1K 5% 1/10W
(ED70/EZ70)
R709 1-247-807-31 CARBON 100 5% 1/4W
R901 1-216-021-00 METAL CHIP 68 5% 1/10W
R902 1-249-407-11 CARBON 150 5% 1/4W
R904 1-249-408-11 CARBON 180 5% 1/4W
R905 1-216-025-91 RES, CHIP 100 5% 1/10W
R906 1-216-021-00 METAL CHIP 68 5% 1/10W
R907 1-216-041-00 METAL CHIP 470 5% 1/10W
R908 1-216-041-00 METAL CHIP 470 5% 1/10W
(ED60/ED70/EZ60/EZ70)
R913 1-216-295-00 METAL CHIP 0 5% 1/10W
R914 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED60/ED70/EZ60/EZ70)
< SWITCH >
S100 1-771-155-11 SWITCH, ROTARY (CAM ENCODER)
S101 1-762-108-11 SWITCH, PUSH (1 KEY) (REC PROOF)
S450 1-771-574-21 SWITCH, TACTILE (I/u) (ED10/EZ10)
S451 1-771-574-21 SWITCH, TACTILE (§EJECT) (ED10/EZ10)
S452 1-771-574-21 SWITCH, TACTILE (r REC) (ED10/EZ10)
S453 1-771-574-21 SWITCH, TACTILE (PROGRAM/TRACKING +)
(ED10/EZ10)
S454 1-771-574-21 SWITCH, TACTILE (PROGRAM/TRACKING +)
(ED40/ED60/ED70/EZ40/EZ60/EZ70)
S455 1-771-574-21 SWITCH, TACTILE (COLOR SYSTEM)
(ED40/ED60/ED70/EZ40/EZ60/EZ70)
S456 1-771-574-21 SWITCH, TACTILE (COLOR SYSTEM)
(ED10/EZ10)
S457 1-771-574-21 SWITCH, TACTILE (P PAUSE) (ED10/EZ10)
S458 1-771-574-21 SWITCH, TACTILE (PROGRAM/TRACKING -)
(ED10/EZ10)
S459 1-771-574-21 SWITCH, TACTILE (PROGRAM/TRACKING -)
(ED40/ED60/ED70/EZ40/EZ60/EZ70)
S460 1-771-574-21 SWITCH, TACTILE (ONE TOUCH TUNING/
RF CHANNEL)(ED10/EZ10)
S461 1-771-574-21 SWITCH, TACTILE
(ONE TOUCH TUNING/RF CHANNEL)
(ED40/ED60/ED70/EZ40/EZ60/EZ70)
S462 1-771-574-21 SWITCH, TACTILE (SP/LP (SP/EP))
(ED40/ED60/ED70/EZ40/EZ60/EZ70)
S463 1-571-308-11 SWITCH, SLIDE (NTSC PB)
(ED10/ED40/ED60/ED70/EZ70)
S464 1-571-588-11 SWITCH, SLIDE (NTSC PB) (EZ10/EZ40/EZ60)
S466 1-771-574-21 SWITCH, TACTILE (INPUT SELECT)
(ED4 0/ED60/ED70/EZ40/EZ60/EZ70)
< TRANSFORMER >
T330 1-423-415-11 TRANSFORMER, BIAS OSCILLATION
(ED40/ED70/EZ70)
T331 1-423-413-11 TRANSFORMER, BIAS OSCILLATION
(ED40/ED70/EZ70)
T331 1-423-414-11 TRANSFORMER, BIAS OSCILLATION
(ED10/ED60/EZ10/EZ40/EZ60)
< TUNER >
TU701 1-693-415-11 TUNER, MOD/IF SOLID TYPE (AERIAL)
(ED10/ED40/ED60/ED70)
TU701 1-693-416-11 TUNER, MOD/IF SOLID TYPE (AERIAL)
(EZ10/EZ40/EZ60/EZ70)
< VIBRATOR >
X161 1-767-855-11 VIBRATOR, CRYSTAL (10MHz)
X162 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz)
X201 1-760-708-11 VIBRATOR, CRYSTAL (4.433619MHz)
* X202 1-760-709-11 VIBRATOR, CRYSTAL (3.579545MHz)
(ED10/ED40/ED60/ED70/EZ70)
X401 1-767-856-11 VIBRATOR, CRYSTAL (17.734475MHz)
* A-6791-860-A MF-317 BOARD, COMPLETE (ED60)
* A-6791-865-A MF-317 BOARD, COMPLETE (EZ40/EZ60)
* A-6791-868-A MF-317 BOARD, COMPLETE (ED40)
* A-6791-874-A MF-317 BOARD, COMPLETE (ED70)
* A-6791-877-A MF-317 BOARD, COMPLETE (EZ70)
**********************
(Ref.No.2,000 Series)
< CAPACITOR >
C461 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C481 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(ED40/ED60/ED70/EZ70)
MA-350 MF-317
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
