8-18
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MF-317 NK-11
< CONNECTOR >
CN461 1-784-449-11 CONNECTOR, FFC/FPC 7P (ED40/ED70/EZ70)
* CN481 1-568-943-11 PIN, CONNECTOR 5P (ED40/ED60/ED70/EZ70)
CN482 1-784-447-11 CONNECTOR, FFC/FPC 5P (ED60/EZ40/EZ60)
< JACK >
CNJ481 1-766-861-11 JACK, PIN (3P) (LINE-2 IN) (ED60/ED70/EZ70)
CNJ481 1-784-570-11 JACK, PIN 3P (LINE-2 IN) (ED40)
< DIODE >
D461 8-719-056-07 DIODE SLR-342MCT31 (ON/STANDBY)
D462 8-719-045-62 DIODE SLR-342VCT31 (SYNCHRO REC)
(ED40/ED70/EZ70)
D480 8-719-017-09 DIODE 02DZ6.2-TPH3
(ED40/ED60/ED70/EZ70)
D481 8-719-071-15 DIODE HZM6.8ZWA1TL
(ED40/ED60/ED70/EZ70)
D490 8-719-071-15 DIODE HZM6.8ZWA1TL
(ED40/ED60/ED70/EZ70)
D491 8-719-071-15 DIODE HZM6.8ZWA1TL
(ED40/ED60/ED70/EZ70)
< ENCAPSULATED COMPONENT >
FL491 1-236-163-11 ENCAPSULATED COMPONENT (EZ70)
FL492 1-236-163-11 ENCAPSULATED COMPONENT (EZ70)
< IC >
IC461 8-749-011-05 IC GP1U28X
< JUMPER RESISTOR >
JR400 1-216-296-00 METAL CHIP 0 5% 1/8W
JR402 1-216-296-00 METAL CHIP 0 5% 1/8W
JR403 1-216-296-00 METAL CHIP 0 5% 1/8W
JR404 1-216-296-00 METAL CHIP 0 5% 1/8W
JR405 1-216-296-00 METAL CHIP 0 5% 1/8W
JS490 1-216-296-00 METAL CHIP 0 5% 1/8W
(ED40/ED60/ED70/EZ70)
JS491 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED40)
JS492 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED40/ED60/ED70)
JS493 1-216-296-00 METAL CHIP 0 5% 1/8W
(ED40/ED60/ED70)
JS494 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED60/ED70/EZ70)
< RESISTOR >
R461 1-216-029-00 METAL CHIP 150 5% 1/10W
R462 1-216-037-00 METAL CHIP 330 5% 1/10W
(ED40/ED70/EZ70)
R480 1-216-021-00 METAL CHIP 68 5% 1/10W
(ED40/ED60/ED70/EZ70)
R490 1-216-041-00 METAL CHIP 470 5% 1/10W
(ED40)
R490 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED60/ED70/EZ70)
R491 1-216-041-00 METAL CHIP 470 5% 1/10W
(ED40)
R491 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED60/ED70/EZ70)
< SWITCH >
S461 1-762-196-21 SWITCH, TACT (I/ u)
S462 1-762-196-21 SWITCH, TACT (SYNCHRO REC)
(ED40/ED70/EZ70)
* A-6791-591-A NK-11 BOARD, COMPLETE (ED70/EZ70: NZ)
*********************
(Ref.No.2,000 Series)
< CAPACITOR >
C003 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C004 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C005 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C006 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C007 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C008 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C009 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C010 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C011 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C012 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C013 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C014 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C015 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C016 1-163-222-11 CERAMIC CHIP 5PF 0.25PF 50V
C017 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C018 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C019 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C020 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C021 1-113-642-11 TANTAL. CHIP 47uF 10% 10V
C022 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C023 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
< CONNECTOR >
* CN001 1-691-183-11 CONNECTOR (BOARD TO BOARD) 13P
< DIODE >
D001 8-719-066-72 DIODE BB135
< FERRITE BEAD >
FB001 1-543-813-21 FERRITE 0uH
FB002 1-543-813-21 FERRITE 0uH
FB003 1-543-813-21 FERRITE 0uH
< IC >
IC001 8-759-526-43 IC TDA9874H/V1,118
< COIL >
L006 1-412-945-11 INDUCTOR 3.3uH
< IC LINK >
! PS001 1-576-122-21 LINK, IC (400mA)
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
