8-19
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< RESISTOR >
R001 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R002 1-216-073-00 METAL CHIP 10K 5% 1/10W
R003 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R004 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R005 1-216-041-00 METAL CHIP 470 5% 1/10W
R006 1-216-041-00 METAL CHIP 470 5% 1/10W
R007 1-216-001-00 METAL CHIP 10 5% 1/10W
R008 1-216-001-00 METAL CHIP 10 5% 1/10W
R009 1-216-001-00 METAL CHIP 10 5% 1/10W
R010 1-216-001-00 METAL CHIP 10 5% 1/10W
R011 1-216-304-11 METAL CHIP 3.3 5% 1/10W
R012 1-216-304-11 METAL CHIP 3.3 5% 1/10W
R013 1-216-001-00 METAL CHIP 10 5% 1/10W
R014 1-216-295-00 METAL CHIP 0 5% 1/10W
R015 1-216-295-00 METAL CHIP 0 5% 1/10W
R016 1-216-033-00 METAL CHIP 220 5% 1/10W
< VIBRATOR >
X001 1-767-897-11 VIBRATOR, CRYSTAL (24.576MHz)
1-468-312-12 POWER BLOCK (HS-921SF) (ED10)
1-468-312-22 POWER BLOCK (HS-921SF1)
(ED40/ED60/ED70)
***********************
(Ref.No. 3,000 Series)
< CAPACITOR >
!C101 1-115-165-11 FILM 0.1uF 250V
! C102 1-115-165-11 FILM 0.1uF 250V
! C108 9-980-012-01 ELECT 150uF 450V
C207 1-126-964-11 ELECT 10uF 50V
C401 1-126-967-11 ELECT 47uF 50V
< DIODE >
! D102 8-719-312-16 DIODE EG01
! D104 8-719-026-52 DIODE 10ELS2
! D106 8-719-100-30 DIODE RD12ES
! D201 8-719-018-83 DIODE D2S4M
! D401 8-719-052-89 DIODE D1NL40
! D501 8-719-026-52 DIODE 10ELS2
< FUSE >
! F101 1-532-388-31 FUSE (2.0A/250V)
< IC >
! IC101 9-939-634-01 IC MIP-164
! IC201 8-759-420-19 IC AN1431T
< PHOTO COUPLER >
! PC101 8-749-924-84 COUPLER, PHOTO PS2561
1-468-311-11 POWER BLOCK (SR-718) (EZ10)
1-468-311-21 POWER BLOCK (SR-708) (EZ40/EZ60/EZ70)
********************
(Ref.No. 4,000 Series)
< CAPACITOR >
C112 1-130-495-51 FILM 0.1uF 50V
C114 1-130-495-51 FILM 0.1uF 50V
C115 1-130-495-51 FILM 0.1uF 50V
< DIODE >
! D107 9-900-534-01 DIODE ERA18-02
! D108 9-900-534-01 DIODE ERA18-02
D205 9-900-534-01 DIODE ERA18-02
< FUSE >
! F101 1-532-388-31 FUSE (2.0A/250V)
< IC >
! IC201 8-759-420-19 IC AN1431T
< PHOTO COUPLER >
! PC101 8-749-924-84 COUPLER, PHOTO PS2561
< RESISTOR >
! R208 9-908-233-01 FUSIBLE 0.47 1/4W
* A-6791-858-A RJ-82 BOARD, COMPLETE (ED60/ED70)
* A-6791-864-A RJ-82 BOARD, COMPLETE (EZ60)
* A-6791-867-A RJ-82 BOARD, COMPLETE (ED40)
* A-6791-876-A RJ-82 BOARD, COMPLETE (EZ70: AS)
* A-6791-879-A RJ-82 BOARD, COMPLETE (EZ70: NZ)
*********************
(Ref.No.1,000 Series)
< CAPACITOR >
C951 1-126-160-11 ELECT 1uF 20% 50V
(ED40/ED60/ED70/EZ70: AS)
C952 1-126-160-11 ELECT 1uF 20% 50V
(ED40/ED60/ED70/EZ70: AS)
C960 1-126-925-11 ELECT 470uF 20% 10V
(EZ70: NZ)
C961 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
(EZ70: NZ)
C962 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(EZ70: NZ)
C963 1-124-589-11 ELECT 47uF 20% 16V
(EZ70: NZ)
< CONNECTOR >
* CN951 1-568-948-11 PIN, CONNECTOR 10P (ED60/ED70/EZ70: AS)
* CN952 1-568-942-21 PIN, CONNECTOR 4P (ED40)
* CN953 1-568-942-11 PIN, CONNECTOR 4P (EZ60/EZ70: NZ)
* CN954 1-568-943-11 PIN, CONNECTOR 5P (EZ70: NZ)
< JACK >
CNJ951 1-565-726-11 JACK, PIN 3P (LINE-3 IN (SAT IN))
(ED60/ED70/EZ70: AS)
NK-11 POWER BLOCK RJ-82
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
