8-20
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
RJ-82
CNJ951 1-784-817-11 JACK, PIN 3P (LINE-3 IN (SAT IN)) (ED40)
CNJ952 1-784-816-11 JACK, PIN 2P (LINE-2 OUT (AUDIO))
(ED60/ED70/EZ60/EZ70)
CNJ953 1-784-818-11 JACK, PIN 2P (SAT DEC) (EZ70: NZ)
< DIODE >
D951 1-216-295-00 METAL CHIP 0 5% 1/10W (EZ70: NZ)
D951 8-719-017-09 DIODE 02DZ6.2-TPH3
(ED40/ED60/ED70/EZ70: AS)
D952 8-719-017-09 DIODE 02DZ6.2-TPH3 (EZ70: NZ)
< ENCAPSULATED COMPONENT >
FL951 1-236-163-11 ENCAPSULATED COMPONENT (EZ70: AS)
FL952 1-236-163-11 ENCAPSULATED COMPONENT (EZ70: AS)
< IC >
IC951 8-759-433-44 IC MM1031XML (EZ70: NZ)
< JUMPER RESISTOR >
JR951 1-216-295-00 METAL CHIP 0 5% 1/10W
JR953 1-216-296-00 METAL CHIP 0 5% 1/8W
JR954 1-216-296-00 METAL CHIP 0 5% 1/8W
JS951 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED40/ED60/ED70)
JS952 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED40/ED60/ED70)
JS954 1-216-295-00 METAL CHIP 0 5% 1/10W
(EZ70: NZ)
JS955 1-216-296-00 METAL CHIP 0 5% 1/8W
(ED40/ED60/ED70/EZ60/EZ70: AS)
JS956 1-216-295-00 METAL CHIP 0 5% 1/10W
(EZ70: NZ)
JS957 1-216-296-00 METAL CHIP 0 5% 1/8W
(ED40)
< RESISTOR >
R951 1-216-021-00 METAL CHIP 68 5% 1/10W
(ED40/ED60/ED70/EZ70: AS)
R952 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED40/ED60/ED70/EZ70: AS)
R953 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED40/ED60/ED70/EZ70: AS)
R954 1-216-041-00 METAL CHIP 470 5% 1/10W
(ED60/ED70/EZ60/EZ70)
R955 1-216-041-00 METAL CHIP 470 5% 1/10W
(ED60/ED70/EZ60/EZ70)
R956 1-216-021-00 METAL CHIP 68 5% 1/10W
(EZ70: NZ)
R957 1-216-021-00 METAL CHIP 68 5% 1/10W
(EZ70: NZ)
R958 1-216-097-00 METAL CHIP 100K 5% 1/10W
(ED40/ED60/ED70/EZ70: AS)
R959 1-216-097-00 METAL CHIP 100K 5% 1/10W
(ED40/ED60/ED70/EZ70: AS)
MISCELLANEOUS
**************
10 1-790-537-11 CABLE, FLAT (FFC) (FDS-5) (ED10/EZ10)
52 1-790-536-11 CABLE, FLAT (FFC) (FMD-13) (ED10/EZ10)
! 56 1-777-854-21 CORD, POWER (ED10)
! 56 1-777-855-22 CORD, POWER (EZ10)
111 1-790-533-11 CABLE, FLAT (FFC) (FDM-6)
114 1-790-534-11 CABLE, FLAT (FFC) (FMF-36)
(ED60/EZ40/EZ60)
114 1-790-535-11 CABLE, FLAT (FFC) (FMF-33)
(ED40/ED70/EZ70)
123 1-762-844-21 SWITCH, ROTARY (ED70/EZ70)
! 157 1-777-854-21 CORD, POWER (ED40/ED60/ED70)
! 157 1-777-855-22 CORD, POWER (EZ40/EZ60/EZ70)
704 1-500-144-11 HEAD, FE
768 1-759-453-11 DRUM ASSY DZH-89A-R (ED10/EZ10)
768 8-839-037-04 DRUM ASSY DZH-74E/Z-RP (ED40/EZ40)
768 8-839-045-02 DRUM ASSY DZH-95A/Z-RP
(ED60/ED70/EZ60/EZ70)
M902 1-698-971-11 MOTOR, DC (CAPSTAN)
M903 X-3947-577-1 MOTOR ASSY, CAM
**************
HARDWARE LIST
**************
#1 7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
#2 7-682-147-01 SCREW +P 3X6
#3 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#4 7-685-133-19 SCREW (DIA. 2.6) (IT3B)
ACCESSORIES & PACKING MATERIALS
*******************************
1-418-159-11 COMMANDER, STANDARD (RMT-V245C)
(EZ60)
1-418-160-11 COMMANDER, STANDARD (RMT-V248C)
(ED10)
1-418-161-11 COMMANDER, STANDARD (RMT-V247C)
(ED60)
1-418-161-21 COMMANDER, STANDARD (RMT-V247D)
(ED70)
1-475-614-11 COMMANDER, STANDARD (RMT-V245) (EZ70)
1-475-614-21 COMMANDER, STANDARD (RMT-V245A)
(EZ10/EZ40)
1-475-616-11 COMMANDER, STANDARD (RMT-V247)
(ED40)
! 1-569-008-21 ADAPTOR, CONVERSION 2P
(ED10: ME, SG/ED40: ME, SG/ED60: ME, SG)
1-696-593-11 CORD, CONNECTION (PAL) (ANT) 1.5m
3-709-128-01 COVER, BATTERY (for RMT-V245/V245A/
V245C) (EZ10/EZ40/EZ60/EZ70)
3-709-133-11 COVER, BATTERY (for RMT-V247/V245C/
V247D) (ED40/ED60/ED70)
3-709-322-01 COVER, BATTERY (for RMT-V248C) (ED10)
3-865-382-11 MANUAL, INSTRUCTION (ENGLISH) (ED70)
3-865-383-11 MANUAL, INSTRUCTION (ENGLISH) (EZ70)
3-865-384-11 MANUAL, INSTRUCTION (ENGLISH) (ED60)
3-865-384-21 MANUAL, INSTRUCTION (ARABIC)
(ED60: ME, SG)
3-865-384-31 MANUAL, INSTRUCTION (PERSIAN)
(ED60: SG)
3-865-384-41 MANUAL, INSTRUCTION (URDU) (ED60: SG)
3-865-384-51 MANUAL, INSTRUCTION (RUSSIAN)
(ED60: PS, SG)
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
