7-8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
FR-152 KK-17
< DIODE >
D400 8-719-056-07 DIODE SLR-342MC3F(POWER)
D403 8-719-056-06 DIODE SLR-342DC3F
(REALITY REGENERATOR)
(50/70:EE/80/X80)
D404 8-719-988-61 DIODE 1SS355TE-17 (50/70:EE/80/X80)
D480 8-719-070-59 DIODE PDZ6.8B-115
(50/70:EE,EG,EN/80/X70:EN/X80)
D481 8-719-067-40 DIODE STZ6.8N-T146
(50/70:EE,EG,EN/80/X70:EN/X80)
D490 8-719-067-40 DIODE STZ6.8N-T146
(50/70:EE,EG,EN/80/X70:EN/X80)
D491 8-719-067-40 DIODE STZ6.8N-T146
(70:EE,EG,EN/80/X70:EN/X80)
< IC >
IC400 8-749-011-05 IC GP1U28X (REMOTE SENSOR)
IC420 8-759-547-59 IC M35500BGP
< JACK >
J480 1-785-622-11 JACK, PIN 2P (LINE-2 IN) (50)
J480 1-770-021-11 JACK, PIN 3P (LINE-2 IN)
(70:EE,EG,EN/80/X70:EN/X80)
< JUMPER RESISTOR >
JR400 1-216-296-91 SHORT 0
JR401 1-216-296-91 SHORT 0
JR402 1-216-295-91 SHORT 0
JR403 1-216-296-91 SHORT 0
JR404 1-216-296-91 SHORT 0
JR405 1-216-296-91 SHORT 0
JR406 1-216-296-91 SHORT 0
< JUMPER RESISTOR >
JS403 1-216-295-91 SHORT 0 (80:EXCEPT EG,EN/X80)
JS404 1-216-295-91 SHORT 0 (50:EE)
JS405 1-216-295-91 SHORT 0 (50:EE)
< COIL >
L400 1-414-934-21 INDUCTOR 10uH
< FLUORECENT INDICATOR >
ND420 1-517-832-21 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q400 8-729-043-29 TRANSISTOR PDTC144EK-115
< RESISTOR >
R400 1-216-022-00 METAL CHIP 75 5% 1/10W
R401 1-216-089-91 RES,CHIP 47K 5% 1/10W
R402 1-216-037-00 METAL CHIP 330 5% 1/10W
R405 1-216-022-00 METAL CHIP 75 5% 1/10W
R406 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R407 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R408 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(50/70:EE/80/X80)
R412 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R413 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R414 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R415 1-216-077-00 METAL CHIP 15K 5% 1/10W
R420 1-216-295-91 SHORT 0
R421 1-216-295-91 SHORT 0
R422 1-216-049-91 RES,CHIP 1K 5% 1/10W
R423 1-216-295-91 SHORT 0
R424 1-216-041-00 METAL CHIP 470 5% 1/10W
(50:EE)
R425 1-216-041-00 METAL CHIP 470 5% 1/10W
(50/70:EE/80/X80)
R480 1-216-022-00 METAL CHIP 75 5% 1/10W
(50/70:EE,EG,EN/80/X70:EN/X80)
R490 1-216-041-00 METAL CHIP 470 5% 1/10W
(50/70:EE,EG,EN/80/X70:EN/X80)
R491 1-216-041-00 METAL CHIP 470 5% 1/10W
(70:EE,EG,EN/80/X70:EN/X80)
R492 1-216-073-00 METAL CHIP 10K 5% 1/10W
R493 1-216-073-00 METAL CHIP 10K 5% 1/10W
< SWITCH >
S400 1-771-410-21 SWITCH, TACT (POWER)
S401 1-771-410-21 SWITCH, TACT (CH +)
(EXCEPT 80:B,NP,UX,VC1,VC2/X80)
S403 1-771-410-21 SWITCH, TACT(REALITY REGENERATOR)
(50/70:EE/80/X80)
S404 1-771-410-21 SWITCH, TACT (CH –)
(EXCEPT 50/70:EE/80/X80)
S405 1-771-410-21 SWITCH, TACT (RF CHANNEL)
(EXCEPT 50/70:EE,EG,EN/80/X70:EN/X80)
S406 1-771-410-21 SWITCH, TACT(PROGRAM/TRACKING+)
(80:B,NP,UX,VC1,VC2/X80)
S407 1-771-410-21 SWITCH, TACT(PROGRAM/TRACKING–)
(50/70:EE/80/X80)
S408 1-771-410-21 SWITCH, TACT(AUTO SETUP/RF CHANNEL)
(50/70:EE,EG,EN/80/X70:EN/X80)
************************************************************
* A-6794-668-A KK-17A BOARD, COMPLETE
**********************
(80:EXCEPT EG,EN/X80)
(Ref.No.:3,000 series)
< CONNECTOR >
CN402 1-784-483-A CONNECTOR, FFC/FPC 4P
(80:EXCEPT EG,EN/X80)
< JUMPER RESISTOR >
JR410 1-216-296-91 SHORT 0 (80:EXCEPT EG,EN/X80)
< SWITCH >
S410 1-418-156-11 ENCODER, ROTARYRY(DIAL TIMER)
(80:EXCEPT EG,EN/X80)
************************************************************
