7-7
7-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
DM-82 FR-152
* A-6794-673-A DM-82A BOARD, COMPLETE (50/80:EG,EN)
***********************
* A-6794-667-A DM-82A BOARD, COMPLETE
***********************
(80:EXCEPT EG,EN/X80)
* A-6794-664-A DM-82B BOARD, COMPLETE
***********************
(60/70:EXCEPT EE,EG,EN/X60/X70:B,VC)
* A-6794-669-A DM-82B BOARD, COMPLETE
***********************
(35/70:EE,EG,EN/X70:EN)
(Ref.No.:4,000 series)
< CONNECTOR >
CN450 1-784-484-11 CONNECTOR, FFC/FPC 5P (50,80,X80)
CN451 1-784-451-11 CONNECTOR, FFC/FPC 9P
< DIODE >
D450 8-719-056-06 DIODE SLR-342DC3F (JOG) (50,80,X80)
D451 8-719-988-61 DIODE 1SS355TE-17 (50,80,X80)
< RESISTOR >
R426 1-216-041-00 METAL CHIP 470 5% 1/10W
(50,80,X80)
R451 1-216-049-91 RES,CHIP 1K 5% 1/10W
R452 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R453 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R454 1-216-037-00 METAL CHIP 330 5% 1/10W
R455 1-216-049-91 RES,CHIP 1K 5% 1/10W
R456 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R457 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S450 1-771-410-21 SWITCH, TACT(FF) (35,60,70,X60,X70)
S451 1-771-410-21 SWITCH, TACT(FF) (50,80,X80)
S452 1-771-410-21 SWITCH, TACT(PLAY) (35,60,70,X60,X70)
S453 1-771-410-21 SWITCH, TACT(STOP) (35,60,70,X60,X70)
S454 1-771-410-21 SWITCH, TACT(REW) (35,60,70,X60,X70)
S455 1-771-410-21 SWITCH, TACT (REW) (50,80,X80)
S456 1-771-410-21 SWITCH, TACT (JOG) (50,80,X80)
S457 1-771-410-21 SWITCH, TACT (REC)
S458 1-771-410-21 SWITCH, TACT (PAUSE)
S459 1-771-410-21 SWITCH, TACT (EJECT)
************************************************************
* A-6791-794-A FR-152A BOARD, COMPLETE (70:EE/80:EG,EN)
***********************
* A-6791-786-A FR-152B BOARD, COMPLETE
***********************
(80:EXCEPT EG,EN/X80)
* A-6791-790-A FR-152C BOARD, COMPLETE
***********************
(70:EG,EN/X70:EN)
* A-6791-801-A FR-152D BOARD, COMPLETE (35)
***********************
* A-6791-775-A FR-152D BOARD, COMPLETE
***********************
(60/70:EXCEPT EE,EG,EN/X60/X70:B,VC)
* A-6791-792-A FR-152E BOARD, COMPLETE (50:EG)
***********************
* A-6791-798-A FR-152F BOARD, COMPLETE (50:EE)
***********************
(Ref.No.:2,000 series)
3-053-372-01 HOLDER(FF), FL (EE,EG,EN)
3-053-372-11 HOLDER(FF), FL (EXCEPT EE,EG,EN)
< CAPACITOR >
C400 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C420 1-124-589-11 ELECT 47uF 20% 16V
C421 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C422 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C423 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C424 1-126-157-11 ELECT 10uF 20% 16V
C481 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(50/70:EE,EG,EN/80/X70:EN/X80)
C491 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(50/70:EE,EG,EN/80/X70:EN/X80)
C493 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
(70:EE,EG,EN/80/X70:EN/X80)
< CONNECTOR >
CN400 1-784-451-11 CONNECTOR, FFC/FPC 9P
CN401 1-784-483-A CONNECTOR, FFC/FPC 4P
(50:EE/80:EXCEPT EG,EN/X80)
CN420 1-784-461-11 CONNECTOR, FFC/FPC 19P
CN480 1-506-469-11 PIN, CONNECTOR 4P(50)
* CN480 1-568-954-11 PIN, CONNECTOR 5P
(70:EE,EG,EN/80/X70:EN/X80)
To Next Page
