Sony SS-CPX1 - Page 64

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
62
HCD-CPX1
R450 1-216-809-11 METAL CHIP 100 5% 1/10W
R451 1-216-809-11 METAL CHIP 100 5% 1/10W
R452 1-216-809-11 METAL CHIP 100 5% 1/10W
R453 1-216-809-11 METAL CHIP 100 5% 1/10W
R454 1-216-809-11 METAL CHIP 100 5% 1/10W
R455 1-216-809-11 METAL CHIP 100 5% 1/10W
R456 1-216-809-11 METAL CHIP 100 5% 1/10W
R457 1-216-809-11 METAL CHIP 100 5% 1/10W
R458 1-216-809-11 METAL CHIP 100 5% 1/10W
R459 1-216-809-11 METAL CHIP 100 5% 1/10W
R460 1-216-809-11 METAL CHIP 100 5% 1/10W
R461 1-216-809-11 METAL CHIP 100 5% 1/10W
R469 1-216-809-11 METAL CHIP 100 5% 1/10W
R470 1-216-809-11 METAL CHIP 100 5% 1/10W
R471 1-216-809-11 METAL CHIP 100 5% 1/10W
R472 1-216-809-11 METAL CHIP 100 5% 1/10W
R473 1-216-809-11 METAL CHIP 100 5% 1/10W
R474 1-216-857-11 METAL CHIP 1M 5% 1/10W
R476 1-216-809-11 METAL CHIP 100 5% 1/10W
R477 1-216-809-11 METAL CHIP 100 5% 1/10W
R479 1-216-809-11 METAL CHIP 100 5% 1/10W
R480 1-216-809-11 METAL CHIP 100 5% 1/10W
R482 1-216-809-11 METAL CHIP 100 5% 1/10W
R483 1-216-809-11 METAL CHIP 100 5% 1/10W
R484 1-216-809-11 METAL CHIP 100 5% 1/10W
R489 1-216-809-11 METAL CHIP 100 5% 1/10W
R490 1-216-809-11 METAL CHIP 100 5% 1/10W
R491 1-216-809-11 METAL CHIP 100 5% 1/10W
R494 1-216-797-11 METAL CHIP 10 5% 1/10W
R495 1-216-797-11 METAL CHIP 10 5% 1/10W
R497 1-216-797-11 METAL CHIP 10 5% 1/10W
R500 1-216-809-11 METAL CHIP 100 5% 1/10W
R501 1-216-813-11 METAL CHIP 220 5% 1/10W
R502 1-216-833-11 METAL CHIP 10K 5% 1/10W
R503 1-216-841-11 METAL CHIP 47K 5% 1/10W
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
R505 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R506 1-216-833-11 METAL CHIP 10K 5% 1/10W
R541 1-216-864-11 SHORT CHIP 0
R543 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(US, CND)
R543 1-216-864-11 SHORT CHIP 0 (SP, KR, AUS)
R544 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(US, CND)
R551 1-216-864-11 SHORT CHIP 0
R552 1-216-864-11 SHORT CHIP 0
R553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R554 1-216-833-11 METAL CHIP 10K 5% 1/10W
R555 1-216-833-11 METAL CHIP 10K 5% 1/10W
R556 1-216-833-11 METAL CHIP 10K 5% 1/10W
R557 1-216-833-11 METAL CHIP 10K 5% 1/10W
R558 1-216-833-11 METAL CHIP 10K 5% 1/10W
R559 1-216-833-11 METAL CHIP 10K 5% 1/10W
R560 1-216-833-11 METAL CHIP 10K 5% 1/10W
R561 1-216-833-11 METAL CHIP 10K 5% 1/10W
R562 1-216-833-11 METAL CHIP 10K 5% 1/10W
R563 1-216-833-11 METAL CHIP 10K 5% 1/10W
R564 1-216-833-11 METAL CHIP 10K 5% 1/10W
R565 1-216-833-11 METAL CHIP 10K 5% 1/10W
R566 1-216-833-11 METAL CHIP 10K 5% 1/10W
R567 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X401 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
X402 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
**************************************************************
SP OUT BOARD
*************
< CAPACITOR >
C701 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C702 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C703 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C704 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
< CONNECTOR >
CN701 1-564-505-21 PLUG, CONNECTOR 2P
CN711 1-564-505-11 PLUG, CONNECTOR 2P
< SHORT >
FB706 1-216-296-11 SHORT CHIP 0
FB707 1-216-296-11 SHORT CHIP 0
FB708 1-216-296-11 SHORT CHIP 0
FB709 1-216-296-11 SHORT CHIP 0
< TERMINAL >
J701 1-537-114-21 TERMINAL BOARD (SPEAKER)
**************************************************************
1-686-794-11 SUB POWER BOARD
*****************
< CAPACITOR >
0C991 1-113-925-11 CERAMIC 0.01uF 20% 250V
(SP, KR, AUS)
0C992 1-113-925-11 CERAMIC 0.01uF 20% 250V
C993 1-126-768-11 ELECT 2200uF 20% 16V
C994 1-104-665-11 ELECT 100uF 20% 10V
< CONNECTOR >
CN990 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D990 8-719-988-61 DIODE 1SS355TE-17 (SP, KR, AUS)
D991 8-719-988-61 DIODE 1SS355TE-17
D992 6-500-522-21 DIODE 10EDB40-TB3
D993 6-500-522-21 DIODE 10EDB40-TB3
D994 6-500-522-21 DIODE 10EDB40-TB3
D995 6-500-522-21 DIODE 10EDB40-TB3
< IC >
IC991 6-703-627-01 IC NJU7201L40 (T3)
MAIN SP OUT SUB POWER
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
