Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
32
ST-S9
MAIN
C968 1-162-306-11 CERAMIC 0.01uF 30% 16V
C970 1-162-306-11 CERAMIC 0.01uF 30% 16V
C971 1-164-159-11 CERAMIC 0.1uF 50V
C972 1-164-159-11 CERAMIC 0.1uF 50V
C977 1-126-964-11 ELECT 10uF 20% 50V
C978 1-126-964-11 ELECT 10uF 20% 50V
C993 1-126-964-11 ELECT 10uF 20% 50V
C994 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN501 1-506-469-11 PIN, CONNECTOR 4P
CN502 1-784-780-11 CONNECTOR, FFC 19P
* CN503 1-568-937-11 PIN, CONNECTOR 10P
* CN505 1-569-624-11 SOCKET, CONNECTOR 17P
(SYSTEM CONTROL 3)
CN506 1-784-776-11 CONNECTOR, FFC 15P (AEP, UK)
CN506 1-568-830-11 CONNECTOR, FFC 11P (EXCEPT AEP, UK)
CN508 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CN509 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN510 1-794-569-11 PIN, CONNECTOR 5P
CN5031 1-794-569-11 PIN, CONNECTOR 5P
CN5032 1-691-907-11 PIN, CONNECTOR 15P
CN5041 1-580-176-11 PIN, CONNECTOR 10P
* CN5042 1-568-419-11 PIN, CONNECTOR 9P
< DIODE >
D551 8-719-911-19 DIODE 1SS199-25
D552 8-719-911-19 DIODE 1SS199-25
D901 8-719-500-56 DIODE D3SBA20
D902 8-719-024-99 DIODE 11ES2-NTA2B (AEP, UK)
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-110-72 DIODE RDS30ESB2
D913 8-719-109-89 DIODE RDS5.6ESB2
D920 8-719-024-99 DIODE 11ES2-NTA2B
D921 8-719-911-19 DIODE 1SS199-25
D922 8-719-024-99 DIODE 11ES2-NTA2B
D923 8-719-024-99 DIODE 11ES2-NTA2B
D924 8-719-050-84 DIODE RB441Q-40T-77
D941 8-719-911-19 DIODE 1SS199-25
D942 8-719-911-19 DIODE 1SS199-25
D943 8-719-911-19 DIODE 1SS199-25
D944 8-719-911-19 DIODE 1SS199-25
D945 8-719-911-19 DIODE 1SS199-25
< GROUND TERMINAL >
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
EPT902 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC501 6-801-211-01 IC M30622MGA-A77FP
IC551 8-759-635-63 IC M51943BSL
IC901 8-759-158-62 IC TA78057S
IC903 8-759-473-41 IC BA10T
IC904 8-759-039-69 IC uPC7805AHF
IC951 8-749-923-05 IC TORX178B (OPTICAL IN)
IC952 8-749-923-05 IC TORX178B (OPTICAL IN)
IC953 8-759-684-00 IC BA8274K
IC991 8-759-701-79 IC NJM7812FA
< COIL >
L14 1-408-080-00 INDUCTOR 100uH
L951 1-410-525-11 INDUCTOR 220uH
L955 1-410-682-31 INDUCTOR 470uH
< TRANSISTOR >
Q502 8-729-422-57 TRANSISTOR UN4111
Q503 8-729-422-57 TRANSISTOR UN4111
Q551 8-729-620-05 TRANSISTOR 2SC2603-EF
Q901 8-729-140-97 TRANSISTOR 2SB734-34
Q902 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2
< RESISTOR >
R44 1-247-807-31 CARBON 100 5% 1/4W
R92 1-247-807-31 CARBON 100 5% 1/4W
R501 1-247-807-31 CARBON 100 5% 1/4W
R502 1-247-807-31 CARBON 100 5% 1/4W
R503 1-247-807-31 CARBON 100 5% 1/4W
R504 1-247-807-31 CARBON 100 5% 1/4W
R505 1-247-807-31 CARBON 100 5% 1/4W
R506 1-247-807-31 CARBON 100 5% 1/4W
R507 1-247-807-31 CARBON 100 5% 1/4W
R508 1-249-429-11 CARBON 10K 5% 1/4W
R509 1-247-891-00 CARBON 330K 5% 1/4W
R510 1-249-411-11 CARBON 330 5% 1/4W
R511 1-249-429-11 CARBON 10K 5% 1/4W
R512 1-247-807-31 CARBON 100 5% 1/4W
R513 1-247-807-31 CARBON 100 5% 1/4W
R514 1-247-807-31 CARBON 100 5% 1/4W
R515 1-249-417-11 CARBON 1K 5% 1/4W
R516 1-247-807-31 CARBON 100 5% 1/4W
R517 1-247-807-31 CARBON 100 5% 1/4W
R518 1-247-807-31 CARBON 100 5% 1/4W
R519 1-249-429-11 CARBON 10K 5% 1/4W
R520 1-249-429-11 CARBON 10K 5% 1/4W
R521 1-247-807-31 CARBON 100 5% 1/4W
R522 1-249-429-11 CARBON 10K 5% 1/4W
R523 1-247-807-31 CARBON 100 5% 1/4W
R524 1-249-437-11 CARBON 47K 5% 1/4W
R525 1-247-807-31 CARBON 100 5% 1/4W
R526 1-247-807-31 CARBON 100 5% 1/4W
R527 1-247-807-31 CARBON 100 5% 1/4W
R528 1-247-807-31 CARBON 100 5% 1/4W
R529 1-247-807-31 CARBON 100 5% 1/4W
R530 1-247-807-31 CARBON 100 5% 1/4W
R531 1-247-807-31 CARBON 100 5% 1/4W
R532 1-249-437-11 CARBON 47K 5% 1/4W
R533 1-247-807-31 CARBON 100 5% 1/4W
R534 1-247-807-31 CARBON 100 5% 1/4W
R535 1-247-807-31 CARBON 100 5% 1/4W
R536 1-247-807-31 CARBON 100 5% 1/4W
R537 1-247-807-31 CARBON 100 5% 1/4W
R538 1-247-807-31 CARBON 100 5% 1/4W
R539 1-247-807-31 CARBON 100 5% 1/4W
R540 1-247-807-31 CARBON 100 5% 1/4W
