Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
33
ST-S9
R541 1-249-437-11 CARBON 47K 5% 1/4W
R542 1-249-437-11 CARBON 47K 5% 1/4W
R543 1-249-415-11 CARBON 680 5% 1/4W
R544 1-249-425-11 CARBON 4.7K 5% 1/4W
R545 1-249-417-11 CARBON 1K 5% 1/4W
(E, MX)
R545 1-249-425-11 CARBON 4.7K 5% 1/4W
(AUS, EA, KR, SP, TH)
R545 1-249-429-11 CARBON 10K 5% 1/4W
(AEP, UK)
R546 1-249-407-11 CARBON 150 5% 1/4W
(AUS, KR, SP, TH)
R546 1-249-417-11 CARBON 1K 5% 1/4W
(EA)
R546 1-249-425-11 CARBON 4.7K 5% 1/4W
(E, MX)
R548 1-249-425-11 CARBON 4.7K 5% 1/4W
R549 1-247-843-11 CARBON 3.3K 5% 1/4W
R550 1-249-441-11 CARBON 100K 5% 1/4W
R551 1-249-413-11 CARBON 470 5% 1/4W
R552 1-249-429-11 CARBON 10K 5% 1/4W
R553 1-249-437-11 CARBON 47K 5% 1/4W
R554 1-249-437-11 CARBON 47K 5% 1/4W
R555 1-249-425-11 CARBON 4.7K 5% 1/4W
R556 1-249-437-11 CARBON 47K 5% 1/4W
R557 1-249-433-11 CARBON 22K 5% 1/4W
R558 1-247-903-00 CARBON 1M 5% 1/4W
0 R903 1-219-153-11 FUSIBLE 10 5% 1/4W F
R904 1-249-429-11 CARBON 10K 5% 1/4W
R905 1-247-807-31 CARBON 100 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R908 1-249-417-11 CARBON 1K 5% 1/4W
R911 1-249-409-11 CARBON 220 5% 1/4W
R912 1-249-442-11 CARBON 510 5% 1/4W
R941 1-249-417-11 CARBON 1K 5% 1/4W
R942 1-249-417-11 CARBON 1K 5% 1/4W
R943 1-247-843-11 CARBON 3.3K 5% 1/4W
R951 1-249-413-11 CARBON 470 5% 1/4W
R952 1-249-413-11 CARBON 470 5% 1/4W
R956 1-247-807-31 CARBON 100 5% 1/4W
R957 1-247-807-31 CARBON 100 5% 1/4W
R958 1-247-807-31 CARBON 100 5% 1/4W
R959 1-247-807-31 CARBON 100 5% 1/4W
R961 1-249-421-11 CARBON 2.2K 5% 1/4W
R962 1-249-421-11 CARBON 2.2K 5% 1/4W
R963 1-249-426-11 CARBON 5.6K 5% 1/4W
R964 1-249-426-11 CARBON 5.6K 5% 1/4W
< VIBRATOR >
X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X502 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
A-4727-699-A PANEL BOARD, COMPLETE (AEP, UK)
A-4727-701-A PANEL BOARD, COMPLETE (TH)
A-4727-702-A PANEL BOARD, COMPLETE
(AUS, EA, E, KR, MX, SP)
**********************
4-232-328-01 HOLDER, FL TUBE
4-949-935-41 CUSHION (FL)
< CAPACITOR >
C601 1-162-306-11 CERAMIC 0.01uF 30% 16V
C603 1-164-159-11 CERAMIC 0.1uF 50V
C605 1-162-306-11 CERAMIC 0.01uF 30% 16V
C606 1-124-261-00 ELECT 10uF 20% 50V
C607 1-126-382-11 ELECT 100uF 20% 6.3V
C608 1-164-159-11 CERAMIC 0.1uF 50V
C610 1-124-261-00 ELECT 10uF 20% 50V
C614 1-162-286-31 CERAMIC 220PF 10% 50V
C615 1-162-286-31 CERAMIC 220PF 10% 50V
C649 1-162-306-11 CERAMIC 0.01uF 30% 16V
C650 1-162-306-11 CERAMIC 0.01uF 30% 16V
C651 1-162-282-31 CERAMIC 100PF 10% 50V
C652 1-162-282-31 CERAMIC 100PF 10% 50V
C653 1-162-282-31 CERAMIC 100PF 10% 50V
C654 1-162-282-31 CERAMIC 100PF 10% 50V
C655 1-162-282-31 CERAMIC 100PF 10% 50V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C658 1-162-282-31 CERAMIC 100PF 10% 50V
C659 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-162-282-31 CERAMIC 100PF 10% 50V
C661 1-162-282-31 CERAMIC 100PF 10% 50V
C662 1-162-282-31 CERAMIC 100PF 10% 50V
C663 1-162-306-11 CERAMIC 0.01uF 30% 16V
C664 1-164-159-11 CERAMIC 0.1uF 50V
C665 1-119-943-91 ELECT 47uF 20% 50V
C666 1-119-943-91 ELECT 47uF 20% 50V
C667 1-164-159-11 CERAMIC 0.1uF 50V
C668 1-164-159-11 CERAMIC 0.1uF 50V
C669 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN602 1-784-741-11 CONNECTOR, FFC 19P
< DIODE >
D601 8-719-911-19 DIODE 1SS199-25
< FLUORESCENT INDICATOR TUBE >
FL601 1-518-744-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 6-800-722-01 IC MB90M407PF-G-109-BND
< RESISTOR >
R601 1-249-429-11 CARBON 10K 5% 1/4W
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-247-807-31 CARBON 100 5% 1/4W
R605 1-247-807-31 CARBON 100 5% 1/4W
R606 1-249-429-11 CARBON 10K 5% 1/4W
R607 1-249-429-11 CARBON 10K 5% 1/4W
R608 1-249-429-11 CARBON 10K 5% 1/4W
R616 1-249-441-11 CARBON 100K 5% 1/4W
R617 1-249-410-11 CARBON 270 5% 1/4W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
