Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
102
STR-DA1200ES
< RELAY >
0RY01 1-755-266-11 RELAY, AC POWER
< TRANSFORMER >
0T02 1-435-163-21 TRANSFORMER, POWER
************************************************************
A-1182-339-A ANALOG BOARD, COMPLETE
************************
< CAPACITOR >
C411 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C412 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C413 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C416 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C417 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C418 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C419 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C420 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C421 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C431 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C432 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C434 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C435 1-126-935-11 ELECT 470uF 20% 16V
C436 1-125-896-91 MYLAR 0.0091uF 5% 50V
C437 1-136-159-00 MYLAR 0.033uF 5% 50V
C438 1-126-961-11 ELECT 2.2uF 20% 50V
C451 1-126-965-11 ELECT 22uF 20% 50V
C452 1-126-961-11 ELECT 2.2uF 20% 50V
C483 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C485 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C486 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C487 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C488 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C497 1-112-089-11 ELECT 47uF 20% 25V
C498 1-112-089-11 ELECT 47uF 20% 25V
C499 1-112-089-11 ELECT 47uF 20% 25V
C511 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C512 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C513 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C516 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C517 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C518 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C519 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C520 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C521 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C531 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C532 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C533 1-126-961-11 ELECT 2.2uF 20% 50V
C534 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C535 1-126-935-11 ELECT 470uF 20% 16V
C536 1-125-896-91 MYLAR 0.0091uF 5% 50V
C537 1-136-159-00 MYLAR 0.033uF 5% 50V
C538 1-126-961-11 ELECT 2.2uF 20% 50V
C551 1-126-965-11 ELECT 22uF 20% 50V
C552 1-126-961-11 ELECT 2.2uF 20% 50V
C583 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C585 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C586 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 50V
C587 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C588 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C597 1-112-089-11 ELECT 47uF 20% 25V
C598 1-112-089-11 ELECT 47uF 20% 25V
C599 1-112-089-11 ELECT 47uF 20% 25V
C616 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C617 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C618 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C619 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C622 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C623 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C624 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C625 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C626 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C627 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C631 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C632 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C633 1-126-947-11 ELECT 47uF 20% 35V
C634 1-126-947-11 ELECT 47uF 20% 35V
C645 1-126-947-11 ELECT 47uF 20% 35V
C646 1-126-947-11 ELECT 47uF 20% 35V
C647 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C648 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C662 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C663 1-163-025-11 CERAMIC CHIP 0.001uF 50V
C692 1-112-093-11 ELECT 2200uF 20% 25V
C693 1-112-093-11 ELECT 2200uF 20% 25V
C694 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN601 1-794-006-11 CONNECTOR 20P
CN602 1-784-922-11 PIN, CONNECTOR 5P
CN603 1-784-923-11 PIN, CONNECTOR 7P
CN606 1-784-927-11 PIN, CONNECTOR 12P
CN608 1-779-978-11 PIN, CONNECTOR 3P
CNP401 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< IC >
IC301 8-759-710-97 IC NJM4565M-D
IC401 6-709-810-01 IC TC9274CNG-015
IC501 6-709-810-01 IC TC9274CNG-015
IC611 8-759-710-97 IC NJM4565M-D
IC613 8-759-710-97 IC NJM4565M-D
IC616 8-759-710-97 IC NJM4565M-D
IC617 8-759-710-97 IC NJM4565M-D
IC619 8-759-710-97 IC NJM4565M-D
IC621 8-759-710-97 IC NJM4565M-D
IC644 8-759-710-97 IC NJM4565M-D
< JACK >
J604 1-815-045-11 JACK, PIN 2P (PHONO IN)
J605 1-784-920-11 JACK, PIN 6P
(SA-CD/CD/MD/TAPE IN, MD/TAPE OUT)
AC ANALOG
