Sony STR-DA1200ES - SP TERMINAL Board; ANALOG Board

STR-DA1200ES
16
3-9. ANALOG BOARD
3-8. SP TERMINAL BOARD
1 two screws
(BV/RING)
3 connector
(CNP4103)
2
4
connector
(CNP4102)
7 SP TERMINAL boar
d
5 connector
(CNP4104)
6 connector
(CNP4101)
9 ANALOG board
5 connector
(CNP401)
8 screw
(BVTP3
× 8
)
7 four screws
(BVTP3
× 8)
6 screw
(BVTP3
× 8)
4 connector
(CN601)
3 connector
(CN602)
2 connector
(CN603)
1 connector
(CN608)
