Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
113
STR-DA1200ES
C70 1-117-370-11 CERAMIC CHIP 10uF 10V
C71 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C73 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C74 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C75 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C76 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C77 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C78 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C79 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C80 1-100-635-21 ELECT CHIP 82uF 20% 4V
C81 1-165-628-21 ELECT CHIP 100uF 20% 2V
C85 1-117-370-11 CERAMIC CHIP 10uF 10V
C88 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C89 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C90 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C91 1-117-370-11 CERAMIC CHIP 10uF 10V
C92 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C93 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C94 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C95 1-117-370-11 CERAMIC CHIP 10uF 10V
C96 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C97 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN1 1-815-136-21 CONNECTOR, BOARD TO BOARD
CN2 1-770-160-21 PIN, CONNECTOR (PC BOARD) 2P
< FERRITE BEAD >
FB1 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB2 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB4 1-469-324-21 FERRITE, EMI (SMD) (2012)
< IC >
IC1 6-705-308-01 IC SI-3010KM-TL
IC2 6-706-764-01 IC ADSP21266SKSTZ-2C
IC3 6-706-765-01 IC SST25VF040-20-4C-QAE-T
IC4 8-759-680-48 IC TC7WH157FK (TE85R)
IC5 8-759-831-52 IC TC7WH125FK (TE85R)
IC6 6-701-373-01 IC MC74LCX16373DTR2
IC7 6-704-832-01 IC IS61LV6416-10TLT
< RESISTOR >
R1 1-243-227-91 RES-CHIP 0.33 1% 1/8W
R2 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3 1-243-227-91 RES-CHIP 0.33 1% 1/8W
R5 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9 1-216-833-11 METAL CHIP 10K 5% 1/10W
R12 1-216-833-11 METAL CHIP 10K 5% 1/10W
R13 1-216-864-11 SHORT CHIP 0
R14 1-218-854-11 METAL CHIP 2K 0.5% 1/10W
R15 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R16 1-216-864-11 SHORT CHIP 0
R17 1-216-864-11 SHORT CHIP 0
R18 1-216-864-11 SHORT CHIP 0
R20 1-216-864-11 SHORT CHIP 0
R21 1-216-833-11 METAL CHIP 10K 5% 1/10W
R23 1-216-817-11 METAL CHIP 470 5% 1/10W
R24 1-216-821-11 METAL CHIP 1K 5% 1/10W
R25 1-216-864-11 SHORT CHIP 0
R26 1-216-801-11 METAL CHIP 22 5% 1/10W
R27 1-216-801-11 METAL CHIP 22 5% 1/10W
R28 1-216-801-11 METAL CHIP 22 5% 1/10W
R29 1-216-801-11 METAL CHIP 22 5% 1/10W
R30 1-216-801-11 METAL CHIP 22 5% 1/10W
R31 1-216-833-11 METAL CHIP 10K 5% 1/10W
R32 1-216-833-11 METAL CHIP 10K 5% 1/10W
R33 1-216-833-11 METAL CHIP 10K 5% 1/10W
R34 1-216-833-11 METAL CHIP 10K 5% 1/10W
R35 1-216-857-11 METAL CHIP 1M 5% 1/10W
R36 1-216-797-11 METAL CHIP 10 5% 1/10W
R38 1-216-833-11 METAL CHIP 10K 5% 1/10W
R41 1-216-833-11 METAL CHIP 10K 5% 1/10W
R43 1-216-833-11 METAL CHIP 10K 5% 1/10W
R45 1-216-833-11 METAL CHIP 10K 5% 1/10W
R46 1-216-801-11 METAL CHIP 22 5% 1/10W
R47 1-216-864-11 SHORT CHIP 0
R48 1-216-864-11 SHORT CHIP 0
R49 1-216-864-11 SHORT CHIP 0
R50 1-216-864-11 SHORT CHIP 0
R51 1-216-864-11 SHORT CHIP 0
R52 1-216-864-11 SHORT CHIP 0
R53 1-216-801-11 METAL CHIP 22 5% 1/10W
R54 1-216-801-11 METAL CHIP 22 5% 1/10W
R55 1-216-864-11 SHORT CHIP 0
R56 1-216-864-11 SHORT CHIP 0
R57 1-216-864-11 SHORT CHIP 0
R58 1-216-864-11 SHORT CHIP 0
R59 1-216-864-11 SHORT CHIP 0
R60 1-216-801-11 METAL CHIP 22 5% 1/10W
R61 1-216-864-11 SHORT CHIP 0
R62 1-216-864-11 SHORT CHIP 0
R63 1-216-864-11 SHORT CHIP 0
R64 1-216-801-11 METAL CHIP 22 5% 1/10W
R65 1-216-801-11 METAL CHIP 22 5% 1/10W
R66 1-216-801-11 METAL CHIP 22 5% 1/10W
R67 1-216-801-11 METAL CHIP 22 5% 1/10W
R68 1-216-801-11 METAL CHIP 22 5% 1/10W
R69 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB1 1-234-523-21 RES, CHIP NETWORK 0 (3216)
RB6 1-239-409-11 RES, CHIP NETWORK 47 (3216)
RB7 1-239-409-11 RES, CHIP NETWORK 47 (3216)
RB8 1-239-409-11 RES, CHIP NETWORK 47 (3216)
RB9 1-239-409-11 RES, CHIP NETWORK 47 (3216)
RB10 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB11 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB12 1-234-524-21 RES, CHIP NETWORK 33 (3216)
RB13 1-234-524-21 RES, CHIP NETWORK 33 (3216)
< VIBRATOR >
X1 1-795-807-11 VIBRATOR, CRYSTAL (25MHz)
************************************************************
DSP
