Sony STR-DA1200ES - Page 85

85
STR-DA1200ES
Pin No. Pin Name
I/O Description
103
NO USE O Source selection signal output to the HDMI receiver
104
NO USE I HDMI jack detection signal input terminal
105
CTL-A1 IN I Power key input terminal
106
CTL-A1 LAT O Serial data latch pulse signal output to the electrical volume
107
CTL-A1 OUT O Relay drive signal (for front-A) output terminal
108
STOP
I
AC off detection signal input terminal
109
MBUS STS0 O Relay drive signal (for front-B) output terminal
110
MBUS STS1 O Relay drive signal (for center) output terminal
111
MBUS STS2 O Relay drive signal (for surround back) output terminal
112
MBUS STS3 O Relay drive signal (for surround) output terminal
113
MBUS STS4 I Protect signal input terminal
114
VSS - Ground terminal
115
VCC - Power supply terminal (+3.3V)
116
DAB TX I Serial data input from the DSP or serial flash
117
DAB RX O Serial data output to the DSP or serial flash
118
DAB POWER O Serial data transfer clock signal output to the DSP
119
ILINK TX I UART communication transfer data input terminal Not used
120
ILINK RX O UART communication receive data output terminal Not used
121
ILINK RESET O System reset signal output terminal Not used
122
HDMI TX I Serial data input terminal Not used
123
HDMI RX O Serial data output terminal Not used
124
HDMI RESET O System reset signal output terminal Not used
125
FLASH SI I Serial data input terminal Not used
126
FLASH SO O Serial data output terminal Not used
127
ILINK CTS O Serial data transfer clock signal output terminal Not used
128
ILINK RTS I Serial data input terminal Not used
129
FL DATA O Serial data output to the fluorescent indicator tube
130
FL CLK O Serial data transfer clock signal output to the fluorescent indicator tube
131
NO USE - Not used
132
END FLAG O End flag output terminal Not used
133
RST TRG O Reset signal output terminal
134
NMIX - Not used
135
XA-OUT - Not used
136
VSS - Ground terminal
137
XA-IN - Not used
138 to 140
MD2 to MD0 I Model destination signal input terminal
141
X-IN I Main system clock input terminal (12.5 MHz)
142
VCC - Power supply terminal (+3.3V)
143
X-OUT O Main system clock output terminal (12.5 MHz)
144
XRESET I System reset signal input terminal "L": reset
145
VSS - Ground terminal
146
VCC - Power supply terminal (+3.3V)
147
POWER RY1 O Relay drive signal (for main power) output terminal Not used
148
POWER RY2 O Relay drive signal (for main power) output terminal "H": relay on
149, 150
FUNCTION
JOG1,
FUNCTION
JOG2
I Jog dial pulse input from the rotary encoder (for INPUT SELECTOR)
