Sony STR-DA1200ES - Page 91

91
STR-DA1200ES
Pin No.
Pin Name I/O Description
49
A31 I TMDS clock signal (positive) input terminal Not used
50
VCC - Power supply terminal (+3.3V)
51
B32 I TMDS data (negative) input terminal Not used
52
A32 I TMDS data (positive) input terminal Not used
53
GND - Ground terminal
54
B33 I TMDS data (negative) input terminal Not used
55
A33 I TMDS data (positive) input terminal Not used
56
VCC - Power supply terminal (+3.3V)
57
B34 I TMDS data (negative) input terminal Not used
58
A34 I TMDS data (positive) input terminal Not used
59
GND - Ground terminal
60
NC - Not used
61
VCC - Power supply terminal (+3.3V)
62
HPD3 O Hot plug detection signal output to the HDMI DVD IN jack
63
SDA3 I/O I2C two-way data bus with the HDMI DVD IN jack
64
SCL3 I I2C clock signal input from the HDMI DVD IN jack
65
GND - Ground terminal
66
B31 I TMDS clock signal (negative) input from the HDMI DVD IN jack
67
A31 I TMDS clock signal (positive) input from the HDMI DVD IN jack
68
VCC - Power supply terminal (+3.3V)
69
B32 I TMDS data (negative) input from the HDMI DVD IN jack
70
A32 I TMDS data (positive) input from the HDMI DVD IN jack
71
GND - Ground terminal
72
B33 I TMDS data (negative) input from the HDMI DVD IN jack
73
A33 I TMDS data (positive) input from the HDMI DVD IN jack
74
VCC - Power supply terminal (+3.3V)
75
B34 I TMDS data (negative) input from the HDMI DVD IN jack
76
A34 I TMDS data (positive) input from the HDMI DVD IN jack
77
GND - Ground terminal
78
NC - Not used
79
VCC - Power supply terminal (+3.3V)
80
HPD1 O Hot plug detection signal output to the HDMI VIDEO IN jack
