Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
81
STR-DA1ES/DB780
A-4729-162-A PRE/SPOUT BOARD, COMPLETE (DA1ES)
A-4729-163-A PRE/SPOUT BOARD, COMPLETE
(DB780: SP, MY, TW, KR, CH)
A-4729-164-A PRE/SPOUT BOARD, COMPLETE
(DB780: AEP, UK)
**************************
< CAPACITOR >
C445 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1ES/DB780: AEP, UK)
C445 1-128-817-11 CERAMIC 470PF 5% 50V
(DB780: SP, MY, TW, KR, CH)
C446 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB780)
C449 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C495 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1ES/DB780: AEP, UK)
C495 1-128-817-11 CERAMIC 470PF 5% 50V
(DB780: SP, MY, TW, KR, CH)
C496 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB780)
C497 1-128-809-11 CERAMIC 100PF 5% 50V
C499 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C549 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C599 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
C649 1-126-965-11 ELECT 22uF 20% 50V
(DA1ES)
< DIODE >
D449 8-719-911-19 DIODE 1SS119-25 (DA1ES)
D450 8-719-911-19 DIODE 1SS119-25
< JACK >
J449 1-766-396-11 JACK, PIN 4P (PRE OUT FRONT/SURROUND)
(DA1ES)
J699 1-816-591-11 JACK, PIN 2P (PRE OUT CENTER,
SUB WOOFER OUT) (DA1ES)
J699 1-770-377-31 JACK, PIN 1P (SUB WOOFER OUT) (DB780)
< RESISTOR >
0 R446 1-249-393-11 CARBON 10 5% 1/4W F
(DB780)
0 R447 1-249-393-11 CARBON 10 5% 1/4W F
R448 1-249-417-11 CARBON 1K 5% 1/4W
(DA1ES)
R449 1-249-441-11 CARBON 100K 5% 1/4W
(DA1ES)
0 R496 1-249-393-11 CARBON 10 5% 1/4W F
(DB780)
0 R497 1-249-393-11 CARBON 10 5% 1/4W F
(DA1ES)
R498 1-249-417-11 CARBON 1K 5% 1/4W
(DA1ES)
R499 1-249-441-11 CARBON 100K 5% 1/4W
(DA1ES)
R548 1-249-417-11 CARBON 1K 5% 1/4W
(DA1ES)
R549 1-249-441-11 CARBON 100K 5% 1/4W
(DA1ES)
R598 1-249-417-11 CARBON 1K 5% 1/4W
(DA1ES)
R599 1-249-441-11 CARBON 100K 5% 1/4W
(DA1ES)
R648 1-249-417-11 CARBON 1K 5% 1/4W
(DA1ES)
R649 1-249-441-11 CARBON 100K 5% 1/4W
(DA1ES)
R698 1-249-417-11 CARBON 1K 5% 1/4W
(DA1ES)
R699 1-249-441-11 CARBON 100K 5% 1/4W
(DA1ES)
R748 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
RY448 1-515-920-11 RELAY (24V)
RY449 1-755-485-11 RELAY (DA1ES)
RY549 1-755-485-11 RELAY (DA1ES)
RY649 1-755-485-11 RELAY (DA1ES)
< TERMINAL >
TM449 1-694-933-11 TERMINAL BOARD (4P) (FRONT SPEAKERS)
(DA1ES)
TM449 1-694-933-21 TERMINAL BOARD (4P) (FRONT SPEAKERS)
(DB780)
**************************************************************
A-4729-130-A S-VIDEO BOARD, COMPLETE (DA1ES)
A-4729-131-A S-VIDEO BOARD, COMPLETE (DB780)
************************
< CAPACITOR >
C850 1-128-805-11 CERAMIC 47PF 5% 50V
C851 1-128-805-11 CERAMIC 47PF 5% 50V
C852 1-128-805-11 CERAMIC 47PF 5% 50V
C853 1-128-805-11 CERAMIC 47PF 5% 50V
C854 1-128-825-11 CERAMIC 2200PF 5% 50V
C855 1-136-165-00 MYLAR 0.1uF 5% 50V
C856 1-136-165-00 MYLAR 0.1uF 5% 50V
C857 1-136-165-00 MYLAR 0.1uF 5% 50V
C858 1-126-964-11 ELECT 10uF 20% 50V
C859 1-126-964-11 ELECT 10uF 20% 50V
C860 1-126-964-11 ELECT 10uF 20% 50V
C861 1-128-825-11 CERAMIC 2200PF 5% 50V
C862 1-128-825-11 CERAMIC 2200PF 5% 50V
C863 1-127-888-11 CERAMIC 0.1uF 10% 50V
C864 1-136-165-00 MYLAR 0.1uF 5% 50V
C867 1-127-888-11 CERAMIC 0.1uF 10% 50V
C869 1-127-888-11 CERAMIC 0.1uF 10% 50V
C870 1-126-964-11 ELECT 10uF 20% 50V
C872 1-127-888-11 CERAMIC 0.1uF 10% 50V
C874 1-128-805-11 CERAMIC 47PF 5% 50V
< CONNECTOR >
CN851 1-569-061-11 SOCKET, CONNECTOR 11P
* CN853 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
PRE/SPOUT S-VIDEO
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
