Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
82
STR-DA1ES/DB780
< DIODE >
D850 8-719-911-19 DIODE 1SS119-25
D851 8-719-911-19 DIODE 1SS119-25
< IC >
IC850 6-701-890-01 IC NJM2595D
IC852 6-701-890-01 IC NJM2595D
< CONNECTOR >
J850 1-764-676-11 CONNECTOR (ROUND TYPE)
(TV/SAT S-VIDEO IN), DVD/LD S-VIDEO IN)
J851 1-537-943-11 CONNECTOR (DIN) 1P (MONITOR S-VIDEO IN)
J852 1-764-676-11 CONNECTOR (ROUND TYPE)
(VIDEO 1 S-VIDEO IN/OUT)
< RESISTOR >
R854 1-247-804-11 CARBON 75 5% 1/4W
R855 1-247-804-11 CARBON 75 5% 1/4W
R856 1-247-804-11 CARBON 75 5% 1/4W
R857 1-247-804-11 CARBON 75 5% 1/4W
R858 1-247-804-11 CARBON 75 5% 1/4W
R859 1-247-804-11 CARBON 75 5% 1/4W
R860 1-247-804-11 CARBON 75 5% 1/4W
R861 1-247-804-11 CARBON 75 5% 1/4W
R862 1-247-804-11 CARBON 75 5% 1/4W
R863 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
1-685-501-11 SEC 1 BOARD
**************************************************************
1-683-873-11 V3-OPT BOARD
*************
< CAPACITOR >
C289 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
* CN289 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< IC >
IC289 6-600-057-01 IC TORX141PL (DIGITAL (OPTICAL))
< RESISTOR >
R289 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
A-4729-127-A VIDEO BOARD, COMPLETE (DA1ES)
A-4729-128-A VIDEO BOARD, COMPLETE
(DB780: SP, MY, TW, KR, CH)
A-4729-129-A VIDEO BOARD, COMPLETE (DB780: AEP, UK)
**********************
< CAPACITOR >
C301 1-127-868-11 CERAMIC 2200PF 10% 50V
(EXCEPT DB780: AEP, UK)
C308 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DB780: AEP, UK)
C309 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DB780: AEP, UK)
C310 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DB780: AEP, UK)
C311 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DB780: AEP, UK)
C312 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DB780: AEP, UK)
C313 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT DB780: AEP, UK)
C335 1-128-805-11 CERAMIC 47PF 5% 50V
C336 1-128-805-11 CERAMIC 47PF 5% 50V
C337 1-128-805-11 CERAMIC 47PF 5% 50V
C342 1-128-805-11 CERAMIC 47PF 5% 50V
C343 1-128-805-11 CERAMIC 47PF 5% 50V
C344 1-128-805-11 CERAMIC 47PF 5% 50V
C345 1-128-805-11 CERAMIC 47PF 5% 50V
C346 1-126-964-11 ELECT 10uF 20% 50V
C347 1-126-964-11 ELECT 10uF 20% 50V
C348 1-126-964-11 ELECT 10uF 20% 50V
C349 1-126-964-11 ELECT 10uF 20% 50V
C351 1-127-868-11 CERAMIC 2200PF 10% 50V
C352 1-127-868-11 CERAMIC 2200PF 10% 50V
C353 1-127-868-11 CERAMIC 2200PF 10% 50V
C354 1-127-888-11 CERAMIC 0.1uF 10% 50V
C358 1-127-888-11 CERAMIC 0.1uF 10% 50V
C363 1-126-964-11 ELECT 10uF 20% 50V
C373 1-127-888-11 CERAMIC 0.1uF 10% 50V
C374 1-127-888-11 CERAMIC 0.1uF 10% 50V
C379 1-127-888-11 CERAMIC 0.1uF 10% 50V
(EXCEPT DB780: AEP, UK)
C380 1-127-888-11 CERAMIC 0.1uF 10% 50V
(EXCEPT DB780: AEP, UK)
C381 1-127-888-11 CERAMIC 0.1uF 10% 50V
(EXCEPT DB780: AEP, UK)
C382 1-127-888-11 CERAMIC 0.1uF 10% 50V
(EXCEPT DB780: AEP, UK)
< CONNECTOR >
CN301 1-569-060-11 SOCKET, CONNECTOR 11P
CN302 1-564-505-11 PLUG, CONNECTOR 2P
CN303 1-569-060-11 SOCKET, CONNECTOR 11P
< DIODE >
D303 8-719-911-19 DIODE 1SS119-25
D304 8-719-911-19 DIODE 1SS119-25
< IC >
IC301 6-701-891-01 IC NJM2581D (EXCEPT DB780: AEP, UK)
IC303 8-759-231-66 IC TC74HC4053AP (EXCEPT DB780: AEP, UK)
IC308 6-701-890-01 IC NJM2595D
< JACK >
J301 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO
MONITOR OUT, TV/SAT IN, DVD/LD IN)
(EXCEPT DB1080: AEP, UK)
J302 1-794-970-11 JACK, PIN 1P (MONITOR OUT VIDEO)
J303 1-563-330-11 JACK (CONTROL A1 II)
J304 1-794-978-11 JACK, PIN 3P
(VIDEO 2 OUT VIDEO, VIDEO 1 IN/OUT VIDEO)
S-VIDEO SEC 1 V3-OPT VIDEO
