Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
83
STR-DA1ES/DB780
VIDEO VIDEO 3 VIDEO.AU
J305 1-794-978-11 JACK, PIN 3P (TV/SAT IN VIDEO,
DVD/LD IN VIDEO, VIDEO 2 OUT VIDEO)
< TRANSISTOR >
Q302 8-729-116-02 TRANSISTOR BA1A4M-TP
(EXCEPT DB780: AEP, UK)
< RESISTOR >
R301 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R302 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R303 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R304 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R305 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R306 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R307 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R309 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R310 1-247-804-11 CARBON 75 5% 1/4W
(EXCEPT DB780: AEP, UK)
R325 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT DB780: AEP, UK)
R338 1-247-804-11 CARBON 75 5% 1/4W
R339 1-247-804-11 CARBON 75 5% 1/4W
R340 1-247-804-11 CARBON 75 5% 1/4W
R341 1-247-804-11 CARBON 75 5% 1/4W
R342 1-247-804-11 CARBON 75 5% 1/4W
R344 1-247-804-11 CARBON 75 5% 1/4W
R346 1-247-804-11 CARBON 75 5% 1/4W
R357 1-247-807-31 CARBON 100 5% 1/4W
(EXCEPT DB780: AEP, UK)
**************************************************************
1-683-776-11 VIDEO 3 BOARD
*************
< CAPACITOR >
C293 1-127-876-11 CERAMIC 0.01uF 10% 50V
C294 1-127-880-11 CERAMIC 0.022uF 10% 50V
< CONNECTOR >
CN201 1-784-923-11 PIN, CONNECTOR 7P
< TERMINAL >
* EB299 1-537-738-21 TERMINAL, EARTH
< JACK >
J298 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P
(VIDEO 3 INPUT AUDIO/VIDEO)
J299 1-784-808-11 TERMINAL, S (VIDEO 3 INPUT S-VIDEO)
< RESISTOR >
R295 1-247-804-11 CARBON 75 5% 1/4W
R296 1-247-804-11 CARBON 75 5% 1/4W
R297 1-247-804-11 CARBON 75 5% 1/4W
R298 1-249-417-11 CARBON 1K 5% 1/4W
R299 1-249-417-11 CARBON 1K 5% 1/4W
**************************************************************
A-4729-132-A VIDEO.AU BOARD, COMPLETE (DA1ES)
A-4729-133-A VIDEO.AU BOARD, COMPLETE (DB780)
*************************
< CAPACITOR >
C201 1-127-868-11 CERAMIC 2200PF 10% 50V
C202 1-127-868-11 CERAMIC 2200PF 10% 50V
C211 1-127-868-11 CERAMIC 2200PF 10% 50V
C212 1-127-868-11 CERAMIC 2200PF 10% 50V
C213 1-128-809-11 CERAMIC 100PF 5% 50V
C214 1-127-876-11 CERAMIC 0.01uF 10% 50V
< CONNECTOR >
CN201 1-568-441-11 SOCKET, CONNECTOR 9P
* CN202 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< IC >
IC201 8-759-582-65 IC TC9273N-014
< JACK >
J201 1-774-411-11 JACK, PIN 6P (TV/SAT AUDIO IN,
DVD/LD AUDIO IN, VIDEO 2 AUDIO OUT)
J202 1-774-411-11 JACK, PIN 6P
(VIDEO 2 AUDIO IN, VIDEO 1 AUDIO IN/OUT)
< RESISTOR >
R201 1-249-417-11 CARBON 1K 5% 1/4W
R202 1-249-417-11 CARBON 1K 5% 1/4W
R203 1-249-421-11 CARBON 2.2K 5% 1/4W
R204 1-249-417-11 CARBON 1K 5% 1/4W
R205 1-249-421-11 CARBON 2.2K 5% 1/4W
R206 1-249-417-11 CARBON 1K 5% 1/4W
R211 1-249-417-11 CARBON 1K 5% 1/4W
R251 1-249-417-11 CARBON 1K 5% 1/4W
R252 1-249-417-11 CARBON 1K 5% 1/4W
R253 1-249-421-11 CARBON 2.2K 5% 1/4W
R254 1-249-417-11 CARBON 1K 5% 1/4W
R255 1-249-421-11 CARBON 2.2K 5% 1/4W
R256 1-249-417-11 CARBON 1K 5% 1/4W
0 R842 1-249-399-11 CARBON 33 5% 1/4W F
0 R843 1-249-399-11 CARBON 33 5% 1/4W F
**************************************************************
MISCELLANEOUS
**************
64 1-773-342-11 WIRE (FLAT TYPE) (31 CORE)
155 1-769-939-11 WIRE (FLAT TYPE) (11 CORE)
157 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
201 1-773-001-11 WIRE (FLAT TYPE) (15 CORE)
(DB780: AEP, UK)
201 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
(EXCEPT DB780: AEP, UK)
202 1-769-905-11 WIRE (FLAT TYPE) (9 CORE)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
