59
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4476-670-A AMP BOARD, COMPLETE (DA3ES,DA5ES)
A-4476-671-A AMP BOARD, COMPLETE (VA555ES)
*****************************************
<CAPACITOR>
C501 1-119-825-41 ELECT 22uF 20% 50V
C502 1-137-505-11 MYLAR 220PF 5% 50V
C503 1-102-233-00 CERAMIC 33PF 10% 500V
C504 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C505 1-119-779-11 ELECT 220uF 20% 10V
C507 1-128-879-11 ELECT 2.2uF 20% 100V
C520 1-128-860-11 ELECT 47uF 20% 50V
C523 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C524 1-137-372-11 MYLAR 0.022uF 5% 50V
C539 1-137-503-11 MYLAR 0.0001uF 5% 50V
C541 1-128-858-11 ELECT 22uF 20% 50V
C542 1-128-834-11 ELECT 470uF 20% 10V
C551 1-119-825-41 ELECT 22uF 20% 50V
C552 1-137-505-11 MYLAR 220PF 5% 50V
C553 1-102-233-00 CERAMIC 33PF 10% 500V
C554 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C555 1-119-779-11 ELECT 220uF 20% 10V
C570 1-128-860-11 ELECT 47uF 20% 50V
C573 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C574 1-137-372-11 MYLAR 0.022uF 5% 50V
C589 1-137-503-11 MYLAR 0.0001uF 5% 50V
C591 1-128-883-11 ELECT 22uF 20% 100V
C592 1-128-883-11 ELECT 22uF 20% 100V
C601 1-119-825-41 ELECT 22uF 20% 50V
C602 1-137-505-11 MYLAR 220PF 5% 50V
C603 1-102-233-00 CERAMIC 33PF 10% 500V
C604 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C605 1-119-779-11 ELECT 220uF 20% 10V
C608 1-128-578-11 ELECT 1uF 20% 100V
C609 1-128-578-11 ELECT 1uF 20% 100V
C620 1-128-860-11 ELECT 47uF 20% 50V
C623 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C624 1-137-372-11 MYLAR 0.022uF 5% 50V
C639 1-137-503-11 MYLAR 0.0001uF 5% 50V
C651 1-119-825-41 ELECT 22uF 20% 50V
C652 1-137-505-11 MYLAR 220PF 5% 50V
C653 1-102-233-00 CERAMIC 33PF 10% 500V
C654 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C655 1-119-779-11 ELECT 220uF 20% 10V
C670 1-128-860-11 ELECT 47uF 20% 50V
C673 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C674 1-137-372-11 MYLAR 0.022uF 5% 50V
C689 1-137-503-11 MYLAR 0.0001uF 5% 50V
C701 1-119-825-41 ELECT 22uF 20% 50V
C702 1-137-505-11 MYLAR 220PF 5% 50V
C703 1-102-233-00 CERAMIC 33PF 10% 500V
C704 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C705 1-119-779-11 ELECT 220uF 20% 10V
C720 1-128-860-11 ELECT 47uF 20% 50V
C723 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C724 1-137-372-11 MYLAR 0.022uF 5% 50V
C739 1-137-503-11 MYLAR 0.0001uF 5% 50V
C751 1-119-825-41 ELECT 22uF 20% 50V
C752 1-137-505-11 MYLAR 220PF 5% 50V
C753 1-102-233-00 CERAMIC 33PF 10% 500V
C754 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C755 1-119-779-11 ELECT 220uF 20% 10V
C770 1-128-860-11 ELECT 47uF 20% 50V
C773 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C774 1-137-372-11 MYLAR 0.022uF 5% 50V
C789 1-137-503-11 MYLAR 0.0001uF 5% 50V
<CONNECTOR>
CN504 1-785-102-31 PIN, CONNECTOR 4P
CNP501 1-784-921-11 PIN, CONNECTOR 4P
* CNP503 1-564-241-11 PIN, CONNECTOR (B4P-VH) 4P
CNP504 1-784-923-11 PIN, CONNECTOR 7P
CNP505 1-785-102-21 PIN, CONNECTOR 4P
CNP509 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
CNP601 1-784-922-11 PIN, CONNECTOR 5P
CNP602 1-779-978-11 PIN, CONNECTOR 3P
CNP701 1-784-922-11 PIN, CONNECTOR 5P
CNP702 1-785-103-11 PIN, CONNECTOR 5P
<DIODE>
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-036-66 DIODE RD2.2SB-T1
D503 8-719-036-66 DIODE RD2.2SB-T1
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D547 8-719-988-61 DIODE 1SS355TE-17
D548 8-719-988-61 DIODE 1SS355TE-17
D549 8-719-988-61 DIODE 1SS355TE-17
D551 8-719-988-61 DIODE 1SS355TE-17
D552 8-719-036-66 DIODE RD2.2SB-T1
D553 8-719-036-66 DIODE RD2.2SB-T1
D554 8-719-988-61 DIODE 1SS355TE-17
D555 8-719-988-61 DIODE 1SS355TE-17
D599 8-719-988-61 DIODE 1SS355TE-17
D601 8-719-988-61 DIODE 1SS355TE-17
D602 8-719-036-66 DIODE RD2.2SB-T1
D603 8-719-036-66 DIODE RD2.2SB-T1
D604 8-719-988-61 DIODE 1SS355TE-17
D605 8-719-988-61 DIODE 1SS355TE-17
D651 8-719-988-61 DIODE 1SS355TE-17
D652 8-719-036-66 DIODE RD2.2SB-T1
D653 8-719-036-66 DIODE RD2.2SB-T1
D654 8-719-988-61 DIODE 1SS355TE-17
D655 8-719-988-61 DIODE 1SS355TE-17
D701 8-719-988-61 DIODE 1SS355TE-17
D702 8-719-036-66 DIODE RD2.2SB-T1
D703 8-719-036-66 DIODE RD2.2SB-T1
D704 8-719-988-61 DIODE 1SS355TE-17
D705 8-719-988-61 DIODE 1SS355TE-17
D751 8-719-988-61 DIODE 1SS355TE-17
D752 8-719-036-66 DIODE RD2.2SB-T1
D753 8-719-036-66 DIODE RD2.2SB-T1
D754 8-719-988-61 DIODE 1SS355TE-17
D755 8-719-988-61 DIODE 1SS355TE-17
AMP
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
