58
STR-DA3ES/DA5ES/VA555ES
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
3RD ROOM SPTM
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
CH : Chinese model
KR : Korea model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
The components identified
by mark 0 or dotted line
with mark 0 are critical for
safety.
Replace only with part num-
ber specified.
Les composants identifiés
par une marque 0 sont cri-
tiques pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
1-681-474-11 3RD ROOM SPTM BOARD (DA3ES,DA5ES)
******************************
<TERMINAL>
TM671 1-694-841-11 TERMINAL BOARD (SP) (SPEAKERS 3RD ROOM)
******************************************************
1-681-471-11 4/8 BOARD
********
<CONNECTOR>
CNP903 1-785-103-11 PIN, CONNECTOR 5P
<SWITCH>
S902 1-771-876-11 SWITCH, POWER
******************************************************
A-4476-677-A AC BOARD, COMPLETE (DA5ES)
A-4476-678-A AC BOARD, COMPLETE (VA555ES:AEP)
A-4476-679-A AC BOARD, COMPLETE (VA555ES:CH,KR)
A-4476-681-A AC BOARD, COMPLETE (VA555ES:E)
A-4476-759-A AC BOARD, COMPLETE (DA3ES)
*****************************
1-533-399-31 HOLDER, FUSE
<CAPACITOR>
C903 1-128-547-11 ELECT 6800uF 20% 16V
C905 1-119-820-11 ELECT 1uF 20% 50V
C906 1-130-472-00 MYLAR 0.0012uF 5% 50V
(VA555ES:AEP,CH,KR)
C906 1-137-432-91 MYLAR 820PF 5% 50V
(DA3ES,DA5ES,VA555ES:E)
C907 1-137-350-11 FILM 0.015uF 5% 50V
(VA555ES:AEP,CH,KR)
C907 1-137-150-11 FILM 0.01uF 5% 50V
(DA5ES,VA555ES:E)
<CONNECTOR>
CNP901 1-564-321-00 PIN, CONNECTOR 2P (DA3ES,VA555ES:KR)
* CNP902 1-565-792-11 PIN, CONNECTOR 2P
0 CNP904 1-816-148-11 INLET, AC (DA5ES/VA555ES:AEP,E,CH)
CNP907 1-568-106-11 PIN, CONNECTOR 4P (VA555ES:E)
<DIODE>
D901 8-719-085-36 DIODE 11EQS04-TB5
D902 8-719-085-36 DIODE 11EQS04-TB5
D903 8-719-085-36 DIODE 11EQS04-TB5
D904 8-719-085-36 DIODE 11EQS04-TB5
D905 8-719-988-61 DIODE 1SS355TE-17
D906 8-719-988-61 DIODE 1SS355TE-17
D907 8-719-988-61 DIODE 1SS355TE-17
<TERMINAL>
* EP901 1-537-738-21 TERMINAL, EARTH (DA3ES,DA5ES)
<FUSE>
0 F901 1-533-312-11 FUSE,GLASS CYLINDRICAL (DIA.5) 10A 125V
(DA3ES,DA5ES)
0 F901 1-533-465-51 FUSE,TIME LAG T2.5AL 250V (VA555ES)
0 F902 1-533-464-51 FUSE, T2.5AL 250V (VA555ES:AEP,CH)
<JACK>
0 J901 1-540-060-11 OUTLET, AC (POLAR) (AC OUTLET)
(EXCEPT VA555ES:AEP,KR)
0 J901 1-785-285-11 OUTLET, AC (1P) (AC OUTLET) (VA555ES:AEP)
<TRANSISTOR>
Q901 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
0 R901 1-219-237-11 SOLID 3.3M 20% 1/2W
(DA3ES,DA5ES)
R902 1-216-073-91 RES-CHIP 10K 5% 1/10W
R903 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R904 1-216-093-91 RES-CHIP 68K 5% 1/10W
R905 1-216-085-91 RES-CHIP 33K 5% 1/10W
R906 1-216-049-11 METAL CHIP 1K 5% 1/10W
(VA555ES:AEP,CH,KR)
R906 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(DA3ES,DA5ES,VA555ES:E)
<RELAY>
0 RY901 1-755-388-11 RELAY (AC POWER)
<TRANSFORMER>
0 T902 1-435-162-11 TRANSFORMER, POWER (DA3ES,DA5ES)
0 T902 1-435-163-11 TRANSFORMER, POWER (VA555ES:AEP,CH,KR)
0 T902 1-435-164-11 TRANSFORMER, POWER (VA555ES:E)
******************************************************
4/8 AC
When indicating parts by reference
number, please include the board
name.
