Sony STR-DA3ES - Page 75

75
STR-DA3ES/DA5ES/VA555ES
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
<RESISTOR>
R165 1-216-029-00 METAL CHIP 150 5% 1/10W
R166 1-216-049-11 RES-CHIP 1K 5% 1/10W
R167 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
<VALIABLE RESISTOR>
RV101 1-467-808-21 ENCODER, ROTARY (FUNCTION)
<SWITCH>
S132 1-771-349-21 SWITCH, KEYBOARD (AUDIO SPLIT)
S133 1-771-349-21 SWITCH, KEYBOARD (INPUT MODE)
S134 1-771-349-21 SWITCH, KEYBOARD (MUTING)
*****************************************************
1-681-470-11 HP BOARD
********
<CONNECTOR>
CNP109 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
CNP111 1-779-978-11 PIN, CONNECTOR 3P
<JACK>
J101 1-815-313-21 JACK (PHONES)
*****************************************************
A-4476-720-A INPUT BOARD, COMPLETE (DA5ES)
A-4476-721-A INPUT BOARD, COMPLETE (VA555ES)
A-4476-762-A INPUT BOARD, COMPLETE (DA3ES)
**************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 I T-3
<CAPACITOR>
C301 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C302 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C303 1-128-832-11 ELECT 220uF 20% 10V
C304 1-125-896-91 MYLAR 0.0091uF 5% 50V
C305 1-136-159-00 MYLAR 0.033uF 5% 50V
C306 1-126-045-11 ELECT 2.2uF 20% 50V
C308 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C309 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C310 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C311 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C312 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C313 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C314 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C315 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C316 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C317 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C318 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C319 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C320 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C321 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C322 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C323 1-128-858-11 ELECT 22uF 20% 50V
C324 1-128-858-11 ELECT 22uF 20% 50V
C325 1-119-825-41 ELECT 22uF 20% 50V
C326 1-119-825-41 ELECT 22uF 20% 50V
C327 1-128-858-11 ELECT 22uF 20% 50V
(DA3ES,DA5ES)
C328 1-128-858-11 ELECT 22uF 20% 50V
(DA3ES,DA5ES)
C345 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C346 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C347 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C348 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C349 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C350 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C351 1-119-821-11 ELECT MELF 2.2uF 20% 50V
C352 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C353 1-128-832-11 ELECT 220uF 20% 10V
C354 1-125-896-91 MYLAR 0.0091uF 5% 50V
C355 1-136-159-00 MYLAR 0.033uF 5% 50V
C356 1-126-045-11 ELECT 2.2uF 20% 50V
C358 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C359 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C360 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C361 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C362 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C363 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C364 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C365 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C366 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C367 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C368 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C369 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C370 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C371 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C372 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA555ES)
C373 1-128-858-11 ELECT 22uF 20% 50V
C374 1-128-858-11 ELECT 22uF 20% 50V
C375 1-119-825-41 ELECT 22uF 20% 50V
C376 1-119-825-41 ELECT 22uF 20% 50V
C377 1-128-858-11 ELECT 22uF 20% 50V
(DA3ES,DA5ES)
C378 1-128-858-11 ELECT 22uF 20% 50V
(DA3ES,DA5ES)
C379 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C380 1-163-038-91 CERAMIC CHIP 0.1uF 25V
INPUTHP
FUNCTION
