81
STR-DA3ES/DA5ES/VA555ES
<CONNECTOR>
CNP107 1-564-711-11 PIN, CONNECTOR 9P
<JACK>
J102 1-764-190-21 JACK, PIN 3P (VIDEO 3 INPUT)
<RESISTOR>
R168 1-216-022-00 METAL CHIP 75 5% 1/10W
R169 1-216-022-00 METAL CHIP 75 5% 1/10W
R170 1-216-022-00 METAL CHIP 75 5% 1/10W
R171 1-216-049-11 RES-CHIP 1K 5% 1/10W
R172 1-216-049-11 RES-CHIP 1K 5% 1/10W
******************************************************
1-681-462-11 VOL SEL BOARD(VA555ES:E)
*********************
1-533-399-31 HOLDER, FUSE
<CONNECTOR>
CN901 1-568-106-11 PIN, CONNECTOR 4P
CNP905 1-568-106-11 PIN, CONNECTOR 4P
<FUSE>
0 F904 1-532-465-51 FUSE T3.15AL, 250V
<SWITCH>
0 S901 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)
******************************************************
MISCELLANEOUS
*************
33 1-773-162-11 WIRE (FLAT TYPE) (21 CORE)
34 1-773-021-11 WIRE (FLAT TYPE) (15 CORE)
0 71 1-551-631-22 CORD, POWER (VA555ES:AEP,E)
0 71 1-559-479-11 CORD, POWER (DA3ES)
0 71 1-757-130-11 CORD, POWER (VA555ES:CH)
0 71 1-769-079-21 CORD, POWER (VA555ES:KR)
0 71 1-823-512-11 CORD, POWER (DA5ES/VA555ES:E)
0 72 1-569-008-21 ADAPTOR, CONVERSION 2P (VA555ES:E)
77 1-769-937-11 WIRE (FLAT TYPE) (11 CORE)
78 1-769-971-11 WIRE (FLAT TYPE) (13 CORE)
79 1-769-975-11 WIRE (FLAT TYPE) (13 CORE)
80 1-773-011-11 WIRE (FLAT TYPE) (15 CORE) (VA555ES:KR)
80 1-823-582-11 WIRE (FLAT TYPE) (15 CORE)
(EXCEPT VA555ES:KR)
81 1-773-021-11 WIRE (FLAT TYPE) (15 CORE)
82 1-773-141-11 WIRE (FLAT TYPE) (21 CORE)
84 1-769-879-11 WIRE (FLAT TYPE) (7 CORE) (DA3ES,DA5ES)
0 T901 1-437-270-11 TRANSFORMER, POWER (DA5ES:US)
0 T901 1-437-271-11 TRANSFORMER, POWER (DA5ES:CND)
0 T901 1-437-273-11 TRANSFORMER, POWER (VA555ES:AEP,E)
0 T901 1-437-274-11 TRANSFORMER, POWER (VA555ES:CH,KR)
0 T901 1-437-276-11 TRANSFORMER, POWER (DA3ES:US)
0 T901 1-437-277-11 TRANSFORMER, POWER (DA3ES:CND)
TU301 1-693-539-21 TUNER (DA3ES,DA5ES,VA555ES:E)
TU301 1-693-540-21 TUNER (VA555ES:AEP,CH,KR)
******************************************************
Ref. No. Part No. Description Remark
VIDEO 3
VOL SEL
Ref. No. Part No. Description Remark
ACCESSORIES
***********
1-476-607-21 REMOTE COMMANDER (RM-PP505L) (DA3ES)
1-476-644-11 COMMANDER, STANDARD (RM-US105) ( DA5ES)
1-476-646-11 REMOTE COMMANDER (RM-LJ305)
(DA5ES/VA555ES)
1-501-374-11 ANTENNA, LOOP(AM)
1-501-594-11 ANTENNA (FM) (VA555ES:AEP,CH)
1-501-721-11 ANTENNA (LOOP)
0 1-506-411-21 ADAPTOR, AC PLUG 3P-2P (DA3ES)
0 1-569-008-21 ADAPTOR,CONVERSION 2P(VA555ES:E)
1-777-172-11 CORD, CONNECTION (DA3ES,DA5ES)
1-777-560-11 CORD, AVC CONNECTION (DA3ES,DA5ES)
1-793-184-21 CONNECTOR (F TYPE ADAPTOR)
(DA3ES,DA5ES,VA555ES:E,KR)
4-210-990-01 LID, BATTERY CASE (FOR RM-LJ305)
(DA5ES,VA555ES)
4-228-696-01 LID, BATTERY CASE (FOR RM-US105)(DA5ES)
4-235-282-11 MANUAL, INSTRUCTION (ENGLISH)
(DA3ES,DA5ES)
4-235-282-21 MANUAL, INSTRUCTION (FRENCH)
(DA3ES:CND,DA5ES:CND)
4-235-283-11 MANUAL, INSTRUCTION (ENGLISH) (VA555ES)
4-235-283-21 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(VA555ES:AEP,E)
4-235-283-31 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (VA555ES:E)
4-235-283-41 MANUAL, INSTRUCTION (SIMPLIFIED CHINESE)
(VA555ES:CH)
4-235-283-51 MANUAL, INSTRUCTION
(GERMAN, DUTCH, SWEDISH) (VA555ES:AEP)
4-235-283-61 MANUAL, INSTRUCTION
(ITALIAN, PORTUGUESE) (VA555ES:AEP)
4-236-328-11 MANUAL, INSTRUCTION (RM-PP505L)
(ENGLISH) (DA3ES)
4-236-328-21 MANUAL, INSTRUCTION (RM-PP505L)
(FRENCH) (DA3ES:CND)
4-236-337-01 LID, BATTERY CASE (FOR RM-PP505L)(DA3ES)
4-237-333-11 MANUAL (3CHIP DSP),INSTRUCTION (ENGLISH)
(DA3ES,DA5ES)
4-237-333-21 MANUAL (3CHIP DSP),INSTRUCTION
(FRENCH) (DA3ES:CND,DA5ES:CND)
******************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
