31
STR-DE197
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R787 1-247-847-11 CARBON 4.7K 5% 1/4W
R788 1-249-427-11 CARBON 6.8K 5% 1/4W
R789 1-247-871-11 CARBON 47K 5% 1/4W
R790 1-247-831-11 CARBON 1K 5% 1/4W
R791 1-247-871-11 CARBON 47K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
0 R793 1-215-868-00 METAL OXIDE 680 5% 1W F
R794 1-249-429-11 CARBON 10K 5% 1/4W
R795 1-249-404-00 CARBON 82 5% 1/4W F
R901 1-247-847-11 CARBON 4.7K 5% 1/4W
R902 1-249-381-11 CARBON 1 5% 1/4W F
0 R903 1-219-237-11 SOLID 3.3M 20% 1/2W F
(US,CND)
R904 1-249-435-11 CARBON 33K 5% 1/4W
R905 1-247-863-11 CARBON 22K 5% 1/4W
R906 1-249-421-11 CARBON 2.2K 5% 1/4W
R907 1-249-428-11 CARBON 8.2K 5% 1/4W
R908 1-249-422-11 CARBON 2.7K 5% 1/4W
R909 1-249-431-11 CARBON 15K 5% 1/4W
R910 1-249-429-11 CARBON 10K 5% 1/4W
R911 1-247-843-11 CARBON 3.3K 5% 1/4W
R912 1-247-831-11 CARBON 1K 5% 1/4W
R913 1-249-404-00 CARBON 82 5% 1/4W F
R914 1-247-847-11 CARBON 4.7K 5% 1/4W
0 R915 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
R916 1-249-389-11 CARBON 4.7 5% 1/4W F
R917 1-249-429-11 CARBON 10K 5% 1/4W
R918 1-247-831-11 CARBON 1K 5% 1/4W
R919 1-247-871-11 CARBON 47K 5% 1/4W
R920 1-247-871-11 CARBON 47K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
R926 1-247-791-11 CARBON 22 5% 1/4W
R929 1-249-401-11 CARBON 47 5% 1/4W F
R930 1-249-401-11 CARBON 47 5% 1/4W F
R941 1-249-409-11 CARBON 220 5% 1/4W
(AEP)
R942 1-249-429-11 CARBON 10K 5% 1/4W
(AEP)
R943 1-249-419-11 CARBON 1.5K 5% 1/4W
(AEP)
R944 1-247-863-11 CARBON 22K 5% 1/4W
(AEP)
R945 1-249-429-11 CARBON 10K 5% 1/4W
(AEP)
R946 1-249-429-11 CARBON 10K 5% 1/4W
(AEP)
R947 1-249-429-11 CARBON 10K 5% 1/4W
(AEP)
RR701 1-249-393-11 CARBON 10 5% 1/4W F
(AEP)
RR702 1-249-393-11 CARBON 10 5% 1/4W F
(AEP)
RR751 1-249-393-11 CARBON 10 5% 1/4W F
(AEP)
RR752 1-249-393-11 CARBON 10 5% 1/4W F
(AEP)
< RELAY >
RY781 1-755-416-12 RELAY
RY782 1-755-416-12 RELAY
RY783 1-755-416-12 RELAY
RY981 1-755-013-11 RELAY
0 RY982 1-755-276-31 RELAY, POWER
< TRANSFORMER >
0 T902 1-435-281-11 TRANSFORMER, POWER (US,CND)
0 T902 1-435-282-11 TRANSFORMER, POWER (AEP)
< TERMINAL BOARD >
TM801 1-537-376-11 TERMINAL BOARD (8P) (SPEAKERS)
*************************************************************
POWER BOARD
*************
< CONNECTOR >
CNP201 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D205 8-719-061-96 LED SLR-325DCT31 (SPEAKER A)
D206 8-719-061-96 LED SLR-325DCT31 (SPEAKER B)
< TRANSISTOR >
Q204 8-729-029-86 TRANSISTOR DTC124ESA
Q205 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R289 1-249-413-11 CARBON 470 5% 1/4W
R290 1-249-413-11 CARBON 470 5% 1/4W
R297 1-247-831-11 CARBON 1K 5% 1/4W
< SWITCH >
S201 1-771-410-21 SWITCH, TACTILE (?/1)
S202 1-771-410-21 SWITCH, TACTILE (SPEAKER A)
S203 1-771-410-21 SWITCH, TACTILE (SPEAKER B)
*************************************************************
VOLUME BOARD
**************
< CONNECTOR >
CN202 1-750-195-11 CONNECTOR, BOARD TO BOARD 6P
< RESISTOR >
R265 1-247-831-11 CARBON 1K 5% 1/4W
R266 1-249-421-11 CARBON 2.2K 5% 1/4W
R267 1-249-421-11 CARBON 2.2K 5% 1/4W
R268 1-247-847-11 CARBON 4.7K 5% 1/4W
R269 1-249-429-11 CARBON 10K 5% 1/4W
R270 1-247-863-11 CARBON 22K 5% 1/4W
< ROTARY ENCODER >
RV201 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S224 1-771-410-21 SWITCH, TACTILE (BALANCE R)
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
POWER VOLUME
To Next Page
