Sony STR-DE197 - Volume Board Switches, Miscellaneous, and Accessories

32
STR-DE197
Ref. No. Part No. Description Remark
S225 1-771-410-21 SWITCH, TACTILE (TREBLE +)
S226 1-771-410-21 SWITCH, TACTILE (BASS +)
S227 1-771-410-21 SWITCH, TACTILE (BALANCE L)
S228 1-771-410-21 SWITCH, TACTILE (TREBLE –)
S229 1-771-410-21 SWITCH, TACTILE (BASS –)
*************************************************************
MISCELLANEOUS
***************
55 1-773-026-11 WIRE (FLAT TYPE) (15 CORE)
59 1-773-026-11 WIRE (FLAT TYPE) (15 CORE) (US,CND)
59 1-773-060-11 WIRE (FLAT TYPE) (17 CORE) (AEP)
0105 1-777-071-23 CORD, POWER (AEP)
0105 1-783-820-11 CORD, POWER (US,CND)
107 1-769-942-11 WIRE (FLAT TYPE) (11 CORE) (US,CND)
107 1-773-006-11 WIRE (FLAT TYPE) (15 CORE) (AEP)
0F901 1-533-453-12 FUSE, GLASS TUBE (DIA.5) (5A/125V)
(US,CND)
0F901 1-533-469-12 FUSE, GLASS TUBE (DIA.5) (T2.5AL/250V)
(AEP)
0F902 1-533-453-12 FUSE, GLASS TUBE (DIA.5) (5A/125V)
(US,CND)
0F902 1-533-469-12 FUSE, GLASS TUBE (DIA.5) (T2.5AL/250V)
(AEP)
Q703 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q704 8-749-010-26 TRANSISTOR MP1620-OPY-M
Q753 8-749-010-25 TRANSISTOR MN2488-OPY-M
Q754 8-749-010-26 TRANSISTOR MP1620-OPY-M
0T901 1-443-188-11 TRANSFORMER, POWER (US,CND)
0T901 1-443-189-11 TRANSFORMER, POWER (AEP)
TN1 1-693-577-13 TUNER PACK (ANTENNA) (US,CND)
TN1 1-693-578-13 TUNER PACK (ANTENNA) (AEP)
*************************************************************
ACCESSORIES
************
1-477-133-11 COMMANDER, STANDARD (RM-U185)
1-501-374-12 ANTENNA, LOOP (AM)
1-501-807-12 ANTENNA (FM) (AEP)
1-793-184-23 CONNECTOR (F TYPE ADAPTOR) (FM)
(US,CND)
4-228-696-01 COVER, BATTERY (for RM-U185)
4-253-437-11 MANUAL, INSTRUCTION (ENGLISH)
4-253-437-21 MANUAL, INSTRUCTION (FRENCH,DUTCH,
SWEDISH,GERMAN,SPANISH,
ITALIAN,POLISH) (AEP)
4-253-437-31 MANUAL, INSTRUCTION (DANISH,FINNISH)
(AEP)
4-253-437-41 MANUAL, INSTRUCTION (PORTUGUESE) (AEP)
VOLUME
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
