Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 38 —
R825 1-249-407-11 CARBON 150 5% 1/4W F
! R830 1-249-405-11 CARBON 100 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:EXCEPT CND)
! R830 1-249-402-11 CARBON 56 5% 1/4W F
(DE225:CND/DE325:CND)
! R831 1-249-403-11 CARBON 68 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:EXCEPT CND)
! R831 1-249-402-11 CARBON 56 5% 1/4W F
(DE225:CND/DE325:CND)
R950 1-249-421-11 CARBON 2.2K 5% 1/4W F
R951 1-249-428-11 CARBON 8.2K 5% 1/4W F
R952 1-249-422-11 CARBON 2.7K 5% 1/4W F
R953 1-249-433-11 CARBON 22K 5% 1/4W
R954 1-249-439-11 CARBON 68K 5% 1/4W
R955 1-249-429-11 CARBON 10K 5% 1/4W
R956 1-247-843-11 CARBON 3.3K 5% 1/4W
R957 1-249-417-11 CARBON 1K 5% 1/4W F
R958 1-249-401-11 CARBON 47 5% 1/4W F
R960 1-249-431-11 CARBON 15K 5% 1/4W
RR01 1-249-418-11 CARBON 1.2K 5% 1/4W F
(DE325:AEP,G,EE)
RR04 1-249-393-11 CARBON 10 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
RR05 1-249-393-11 CARBON 10 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
RR51 1-249-418-11 CARBON 1.2K 5% 1/4W F
(DE325:AEP,G,EE)
RR54 1-249-393-11 CARBON 10 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
RR55 1-249-393-11 CARBON 10 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
< RELAY >
RY601 1-515-921-11 RELAY (12V)
RY701 1-515-921-11 RELAY (12V)
RY801 1-755-013-11 RELAY
(DE225:AEP,G,EE,UK/DE325:EXCEPT CND)
RY851 1-755-209-11 RELAY (DE225:CND/DE325:CND)
RY852 1-755-209-11 RELAY (DE225:CND/DE325:CND)
< TERMINAL >
TM601 1-537-510-11 TERMINAL BOARD (6P)(SURRPUND SPEAKER)
TM701 1-537-376-11 TERMINAL BOARD (FRONT SPEAKER)
< VIBRATOR >
X1 1-579-900-21 VIBRATOR, CRYSTAL 4.33MHz
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
X301 1-579-952-21 VIBRATOR,CERAMIC 8MHz
(DE225:AEP,G,EE,UK)
X301 1-579-952-11 VIBRATOR,CERAMIC 8MHz(DE225:CND/DE325)
************************************************************
* 1-669-273-11 MIX-OUT BOARD
*************
< JACK >
J254 1-774-843-11 JACK, PIN 1P (MIX AUDIO OUT)
************************************************************
* 1-669-267-11 PRIMARY BOARD
*************
1-533-233-21 HOLDER, FUSE
< CONNECTOR >
* CNP902 1-564-321-21 PIN, CONNECTOR 2P
< FUSE >
! F901 1-576-109-11 FUSE TIME LAG 5A/125V
(DE225:CND/DE325:US,CND)
! F901 1-532-388-51 FUSE TIME LAG 2A/250V
(DE325:E,EA,CH,AUS,SP,MY)
! F901 1-532-464-51 FUSE TIME LAG 2.5A/250V (DE325:AEP,G,EE)
! F901 1-532-503-51 FUSE TIME LAG 1.6A/250V
(DE225:AEP,G,EE,UK)
************************************************************
* 1-669-268-11 SECONDARY BOARD
***************
< CONNECTOR >
CNP801 1-764-480-11 PIN, CONNECTOR (PC BOARD) 11P
< RESISTOR >
! R810 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
(DE225:CND/DE325:CND)
! R810 1-249-381-11 CARBON 1 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:EXCEPT CND)
! R811 1-219-124-11 FUSIBLE 0.68 5% 1/4W F
(DE225:CND/DE325:CND)
! R811 1-249-381-11 CARBON 1 5% 1/4W F
(DE225:AEP,G,EE,UK/DE325:EXCEPT CND)
************************************************************
* 1-669-270-11 SP-SW BOARD
***********
< CONNECTOR >
CNP703 1-764-474-11 PIN, CONNECTOR (PC BOARD) 5P
CNP704 1-764-473-11 PIN, CONNECTOR (PC BOARD) 3P
CNS702 1-770-378-11 CONNECTOR, BOARD TO BOARD 5P
< JACK >
J741 1-750-733-11 JACK (LARGE TYPE)(PHONES)
< RESISTOR >
R741 1-247-753-11 CARBON 1.2K 5% 1/2W(DE225:CND/DE325)
R741 1-260-097-11 CARBON 680 5% 1/2W(DE225:AEP,G,EE,UK)
R742 1-247-753-11 CARBON 1.2K 5% 1/2W(DE225:CND/DE325)
R742 1-260-097-11 CARBON 680 5% 1/2W(DE225:AEP,G,EE,UK)
R791 1-247-753-11 CARBON 1.2K 5% 1/2W(DE225:CND/DE325)
R791 1-260-097-11 CARBON 680 5% 1/2W(DE225:AEP,G,EE,UK)
R792 1-247-753-11 CARBON 1.2K 5% 1/2W(DE225:CND/DE325)
R792 1-260-097-11 CARBON 680 5% 1/2W(DE225:AEP,G,EE,UK)
MAIN PRIMARY SECONDARYMIX-OUT SP-SW
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
