Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 39 —
< SWITCH >
S701 1-762-319-11 SWITCH, PUSH (2 KEY)(SPEAKER A/B)
************************************************************
* 1-669-271-11 SP-SW-A BOARD
*************
************************************************************
* 1-669-272-11 SP-SW-B BOARD
*************
************************************************************
* 1-669-266-11 STAND BY BOARD
**************
1-533-233-21 HOLDER, FUSE
< JACK >
! CNJ902 1-251-691-11 OUTLET (AC)
(DE225:CND/DE325:US,CND,E,EA,CH)
< CONNECTOR >
CNP802 1-779-495-11 PLUG, CONNECTOR PIN 4P
CNP901 1-564-321-00 PIN, CONNECTOR 2P
CNP903 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
(DE225:AEP,G,EE/DE325:AEP,G,AUS,EE,SP,MY)
CNP905 1-564-320-00 PIN, CONNECTOR (B2P-VH) 2P
* CNP906 1-564-687-11 PIN, CONNECTOR 3P
< DIODE >
D816 8-719-911-19 DIODE 1SS119
< FUSE >
! F902 1-532-464-51 FUSE TIME LAG 2.5A/250V
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE,SP,MY,AUS)
< TERMINAL >
* G900 1-537-738-21 TERMINAL, EARTH
(DE225:CND/DE325:US,CND)
< RESISTOR >
! R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(DE225:CND/DE325:US,CND)
< RELAY >
! RY901 1-755-018-11 RELAY
< TRANSFORMER >
! T902 1-450-361-11 TRANSFORMER, POWER
(DE225:CND/DE325:US,CND)
! T902 1-450-358-11 TRANSFORMER, POWER
(DE225:AEP,G,EE,UK/DE325:EXCEPT US,CND)
************************************************************
* 1-669-269-11 VOL-SEL BOARD(DE325:E,EA,CH)
*************
1-533-399-31 HOLDER, FUSE
< CONNECTOR >
* CNP907 1-565-395-11 PIN, CONNECTOR 3P
CNP908 1-564-321-00 PIN, CONNECTOR 2P
* CNP910 1-564-687-11 PIN, CONNECTOR 3P
< DIODE >
D235 8-759-058-64 DIODE IC TC7S32FU(TE85R)
D236 8-759-058-64 DIODE IC TC7S32FU(TE85R)
D237 8-759-058-64 DIODE IC TC7S32FU(TE85R)
D239 8-759-058-64 DIODE IC TC7S32FU(TE85R)
< FUSE >
! F904 1-532-388-51 FUSE TIME LAG 2A/250V
< SWITCH >
! S901 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE
(SELECTOR)
************************************************************
* A-4407-436-A VR-TONE BOARD, COMPLETE
***********************
(DE225:CND/DE325:EXCEPT AEP,G,EE)
* A-4407-523-A VR-TONE BOARD, COMPLETE
***********************
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
< CAPACITOR >
C420 1-162-207-31 CERAMIC 22PF 5% 50V
C421 1-137-440-11 FILM 0.018uF 5% 50V
C422 1-124-463-00 ELECT 0.1uF 20% 50V
C423 1-137-368-11 FILM 0.0047uF 5% 50V
C424 1-137-372-11 FILM 0.022uF 5% 50V
C425 1-126-795-11 ELECT 10uF 20% 25V
C426 1-126-795-11 ELECT 10uF 20% 25V
C427 1-124-252-00 ELECT 0.33uF 20% 50V
C428 1-130-489-00 MYLAR 0.033uF 5% 50V
C429 1-102-973-00 CERAMIC 100PF 5% 50V
C430 1-126-301-11 ELECT 1uF 20% 50V
C431 1-126-301-11 ELECT 1uF 20% 50V
C432 1-126-795-11 ELECT 10uF 20% 25V
C433 1-126-795-11 ELECT 10uF 20% 25V
C470 1-162-207-31 CERAMIC 22PF 5% 50V
C471 1-137-440-11 FILM 0.018uF 5% 50V
C472 1-124-463-00 ELECT 0.1uF 20% 50V
C473 1-137-368-11 FILM 0.0047uF 5% 50V
C474 1-137-372-11 FILM 0.022uF 5% 50V
C475 1-126-795-11 ELECT 10uF 20% 25V
C476 1-126-795-11 ELECT 10uF 20% 25V
C477 1-124-252-00 ELECT 0.33uF 20% 50V
C478 1-130-489-00 MYLAR 0.033uF 5% 50V
C479 1-102-973-00 CERAMIC 100PF 5% 50V
C492 1-124-464-11 ELECT 0.22uF 20% 50V
C601 1-126-163-11 ELECT 4.7uF 20% 50V
C651 1-126-163-11 ELECT 4.7uF 20% 50V
C701 1-126-163-11 ELECT 4.7uF 20% 50V
C751 1-126-163-11 ELECT 4.7uF 20% 50V
STAND BY VOL-SEL VR-TONESP-SW-A SP-SW-B
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
