Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 40 —
< CONNECTOR >
CNP202 1-770-391-11 PIN, CONNECTOR (PC BOARD) 7P
CNS402 1-568-439-11 SOCKET, CONNECTOR 7P
CNS403 1-568-442-11 SOCKET, CONNECTOR 9P
< DIODE >
D238 8-719-046-39 DIODE SEL5821A-TH15 (MUTING)
D421 8-719-911-19 DIODE 1SS119
< IC >
IC404 8-759-636-74 IC M5218AP-22
< TRANSISTOR >
Q401 8-729-202-67 TRANSISTOR 2SK246-GR3
Q402 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q451 8-729-202-67 TRANSISTOR 2SK246-GR3
Q452 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R229 1-249-406-11 CARBON 120 5% 1/4W F
R420 1-249-415-11 CARBON 680 5% 1/4W F
R421 1-249-430-11 CARBON 12K 5% 1/4W
R422 1-249-422-11 CARBON 2.7K 5% 1/4W F
R423 1-247-903-00 CARBON 1M 5% 1/4W
R424 1-247-903-00 CARBON 1M 5% 1/4W
R425 1-249-429-11 CARBON 10K 5% 1/4W
R426 1-249-439-11 CARBON 68K 5% 1/4W
R427 1-249-417-11 CARBON 1K 5% 1/4W F
R430 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-247-843-11 CARBON 3.3K 5% 1/4W
R432 1-247-883-00 CARBON 150K 5% 1/4W
R433 1-249-427-11 CARBON 6.8K 5% 1/4W F
R434 1-249-413-11 CARBON 470 5% 1/4W F
R438 1-249-441-11 CARBON 100K 5% 1/4W
R441 1-249-441-11 CARBON 100K 5% 1/4W
R444 1-247-903-00 CARBON 1M 5% 1/4W
R464 1-247-903-00 CARBON 1M 5% 1/4W
R469 1-247-903-00 CARBON 1M 5% 1/4W
R470 1-249-415-11 CARBON 680 5% 1/4W F
R471 1-249-430-11 CARBON 12K 5% 1/4W
R472 1-249-422-11 CARBON 2.7K 5% 1/4W F
R473 1-247-903-00 CARBON 1M 5% 1/4W
R474 1-247-903-00 CARBON 1M 5% 1/4W
R475 1-249-429-11 CARBON 10K 5% 1/4W
R476 1-249-439-11 CARBON 68K 5% 1/4W
R477 1-249-417-11 CARBON 1K 5% 1/4W F
R480 1-249-437-11 CARBON 47K 5% 1/4W
R481 1-247-843-11 CARBON 3.3K 5% 1/4W
R482 1-247-883-00 CARBON 150K 5% 1/4W
R483 1-249-427-11 CARBON 6.8K 5% 1/4W F
R484 1-249-413-11 CARBON 470 5% 1/4W F
R491 1-249-441-11 CARBON 100K 5% 1/4W
R492 1-247-903-00 CARBON 1M 5% 1/4W
R494 1-247-903-00 CARBON 1M 5% 1/4W
< VARIABLE RESISTOR >
RV404 1-225-229-11 RES, VAR, CARBON 100KX4
(MASTER VOLUME)
RV421 1-223-362-11 RES, VAR, CARBON 100K/100K (BASS)
RV422 1-223-363-11 RES, VAR, CARBON 125K/125K (TREBLE)
RV423 1-225-447-11 RES, VAR, CARBON 100K/100K (BALANCE)
< SWITCH >
S240 1-762-751-11 SWITCH, TACTILE (MUTING)
************************************************************
* 1-669-263-11 10 KEY BOARD
************
< CONNECTOR >
CNS205 1-770-397-11 HOUSING, CONNECTOR(PC BOARD)4P
< RESISTOR >
R232 1-249-411-11 CARBON 330 5% 1/4W
R233 1-249-413-11 CARBON 470 5% 1/4W F
R234 1-249-415-11 CARBON 680 5% 1/4W F
R235 1-249-417-11 CARBON 1K 5% 1/4W F
R236 1-249-419-11 CARBON 1.5K 5% 1/4W F
R237 1-249-421-11 CARBON 2.2K 5% 1/4W F
R238 1-247-843-11 CARBON 3.3K 5% 1/4W
R239 1-249-411-11 CARBON 330 5% 1/4W
R240 1-249-413-11 CARBON 470 5% 1/4W F
R241 1-249-415-11 CARBON 680 5% 1/4W F
R242 1-249-417-11 CARBON 1K 5% 1/4W F
R243 1-249-419-11 CARBON 1.5K 5% 1/4W F
R244 1-249-421-11 CARBON 2.2K 5% 1/4W F
R245 1-247-843-11 CARBON 3.3K 5% 1/4W
R246 1-249-411-11 CARBON 330 5% 1/4W
R247 1-249-413-11 CARBON 470 5% 1/4W F
R248 1-249-415-11 CARBON 680 5% 1/4W F
R249 1-249-417-11 CARBON 1K 5% 1/4W F
R250 1-249-419-11 CARBON 1.5K 5% 1/4W F
R251 1-249-421-11 CARBON 2.2K 5% 1/4W F
R252 1-247-843-11 CARBON 3.3K 5% 1/4W
< SWITCH >
S217 1-554-303-21 SWITCH, TACTILE (EFFECT/DELAY)
S218 1-554-303-21 SWITCH, TACTILE (SURROUND ON/OFF)
S219 1-554-303-21 SWITCH, TACTILE (BASS BOOST)
S220 1-554-303-21 SWITCH, TACTILE (PHONO)(DE325:AEP,G,EE)
S221 1-554-303-21 SWITCH, TACTILE (TUNER)(DE325:AEP,G,EE)
S222 1-554-303-21 SWITCH, TACTILE (TV/LD)
S223 1-554-303-21 SWITCH, TACTILE (VIDEO)
S224 1-554-303-21 SWITCH, TACTILE (SHIFT)
S225 1-554-303-21 SWITCH, TACTILE (6)
S226 1-554-303-21 SWITCH, TACTILE (7)
S227 1-554-303-21 SWITCH, TACTILE (8)
S228 1-554-303-21 SWITCH, TACTILE (9)
S229 1-554-303-21 SWITCH, TACTILE (0)
S230 1-554-303-21 SWITCH, TACTILE (SET UP)
S231 1-554-303-21 SWITCH, TACTILE (CD)(DE325:AEP,G,EE)
